[shortdesc]Firewall, 1RU rack mount, 960GB SSD, 4x 25GE SFP28, including 1 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP).[/shortdesc]

[properties]

Product Name	FortiGate 701G
SKU	FG-701G-BDL-950-12
Bundle / Subscription	BDL-950 (Hardware + FortiCare Premium + FortiGuard Unified Threat Protection (UTP)) - 1 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput (IPv4)	164 Gbps (1518 byte UDP)
Interfaces	4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5G BASE-T RJ45, 2x RJ45 (HA/MGMT)
Onboard Storage	2x 480 GB (960 GB Total)
AC Power Supply	100-240VAC, 50/60 Hz
Dimensions	1.75 x 17.0 x 13.5 inches (44.45 x 432 x 342 mm)
Weight	7.72 lbs (3.5 kg)
Operating Temperature	32°F to 113°F (0°C to 45°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	38 Gbps
NGFW Throughput	29 Gbps
Threat Protection Throughput	26 Gbps
System Performance and Capacity
IPv4 Firewall Throughput	164 / 163 / 145 Gbps (1518/512/64 byte, UDP)
IPv6 Firewall Throughput	164 / 163 / 145 Gbps (1518/512/86 byte, UDP)
Firewall Latency	3.87 μs (64 byte, UDP)
Firewall Throughput (Packet per Second)	217.5 Mpps
Concurrent Sessions (TCP)	16 Million
New Sessions/Second (TCP)	700,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)	55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	8 Gbps
Concurrent SSL-VPN Users (Recommended Max)	10,000 (Tunnel Mode)
SSL Inspection Throughput	14 Gbps (IPS, avg. HTTPS)
SSL Inspection CPS	13,000 (IPS, avg. HTTPS)
SSL Inspection Concurrent Session	1.6 Million (IPS, avg. HTTPS)
Application Control Throughput	50 Gbps (HTTP 64K)
CAPWAP Throughput	133 Gbps (HTTP 64K)
Virtual Domains (Default/Maximum)	10 / 50
Maximum Number of FortiSwitches Supported	96
Maximum Number of FortiAPs (Total/Tunnel)	1024 / 512
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware and Interfaces
Hardware Accelerated 25 GE SFP28/10 GE SFP+ Slots	4
Hardware Accelerated 10 GE SFP+/GE SFP Slots	4
Hardware Accelerated GE SFP Slots	16
Hardware Accelerated GE RJ45 Slots	8 (5 / 2.5 / GE)
2.5 GE/GE HA Port	1
GE Management Port	1
USB Ports (Client/Server)	2
Console Port	1
Trusted Platform Module (TPM)	Yes
FortiSentry	Yes
Dimensions and Power
Power Consumption (Average/Maximum)	240 W / 295 W
AC Current (Maximum)	6A @ 100VAC
Heat Dissipation	1006 BTU/h
Redundant Power Supplies	Default dual non-swappable AC PSU for 1+1 Redundancy
Operating Environment and Certifications
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	59 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3,048 m)

[/specifications]

[accesories]

Included Accessories	2x SFP SX Transceivers, Default Dual Internal Power Supplies
Optional Accessories	1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), Direct Attach Cables (10 GE SFP+, 25 GE SFP28)

[/accesories]

The Fortinet FortiGate 701G Series Next-Generation Firewall (NGFW) utilizes advanced artificial intelligence (AI) and machine learning (ML) to provide comprehensive threat protection at scale. Driven by Fortinet's patented Network Processor 7 (NP7) and the tenth-generation Content Processor (CP10), this appliance delivers superior performance, including 38 Gbps of IPS throughput and 50 Gbps of Application Control throughput. The inclusion of 960GB of onboard SSD storage allows for extensive local logging, providing deep visibility and data retention critical for compliance and forensic analysis.

This FG-701G-BDL-950-12 bundle pairs the FortiGate 701G hardware with FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for a 1-year term, helping keep enterprise deployments protected and supported throughout the subscription period. Designed for modern, high-bandwidth networks, the FortiGate 701G features a versatile array of interfaces, including four 25 GE SFP28 slots, four 10 GE SFP+ slots, and eight 5 GE RJ45 ports. It incorporates FortiSentry, a specialized hardware module that continuously monitors the integrity of the FortiOS filesystem to protect against unauthorized modifications and malicious tampering. With redundant dual internal AC power supplies included by default, the FG-701G offers the resilience needed for mission-critical deployments in data centers, campus edges, and hybrid environments.

Data-Driven Security with 960GB Storage and CP10 Acceleration

Key Benefits

• High-Speed Processing: Delivers 38 Gbps IPS throughput and 29 Gbps NGFW throughput via NP7 and CP10 processors.
• Integrated Storage: Features 2x 480 GB (960 GB total) onboard SSDs for local logging and reporting.
• Versatile Connectivity: Equipped with 4x 25 GE SFP28, 4x 10 GE SFP+, and 8x 5G BASE-T RJ45 ports for flexible deployment.
• System Integrity: FortiSentry hardware module proactively detects and prevents unauthorized OS modifications.
• Encrypted Traffic Inspection: Provides 14 Gbps of SSL inspection throughput to secure encrypted data without latency.
• Operational Resilience: Includes default dual internal power supplies (1+1 redundancy) to maximize uptime.
• AI-Powered Defense: Leverages FortiGuard AI/ML services to protect against known, zero-day, and emerging threats.

Ideal Use Cases

• Enterprise Edge Security: Securing the network perimeter with high-performance inspection and local log retention.
• Secure SD-WAN: Delivering converged networking and security with operational efficiency and deep analytics.
• Internal Segmentation: Using VXLAN segmentation to isolate network segments and prevent lateral threat movement.
• Hybrid Mesh Firewall: Ensuring consistent policy enforcement across on-premise and cloud environments.

Technical Specifications Summary

• IPS Throughput: 38 Gbps
• NGFW Throughput: 29 Gbps
• Threat Protection Throughput: 26 Gbps
• IPv4 Firewall Throughput (UDP): 164 / 163 / 145 Gbps (1518/512/64 byte)
• IPsec VPN Throughput (512 byte): 55 Gbps
• SSL Inspection Throughput (IPS, avg. HTTPS): 14 Gbps
• Concurrent Sessions (TCP): 16 Million
• New Sessions/Second (TCP): 700,000
• Interfaces: 4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5G BASE-T RJ45, 2x RJ45 (HA/MGMT)
• Onboard Storage: 2x 480 GB (960 GB total)
• Power Consumption (Average/Maximum): 240 W / 295 W
• Dimensions (H x W x L): 1.75 x 17.0 x 13.5 in (44.45 x 432 x 342 mm)

Upgrade Your Network Security

Upgrade to the FG-701G-BDL-950-12 bundle to deploy FortiGate 701G performance with BDL-950 coverage for your 1-year term.
