[shortdesc]Firewall, 1RU, 4x 25GE SFP28, 4x 10GE SFP+, 8x 5G BASE-T RJ45, IPS 38 Gbps, 960GB onboard SSD[/shortdesc]

[properties]

Product Name	FortiGate 701G
SKU	FG-701G
Form Factor	Rack Mount, 1RU
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	164 / 163 / 145 Gbps
Interfaces	4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5G BASE-T RJ45, 2x RJ45 (HA/MGMT)
Onboard Storage	2x 480 GB (960 GB Total)
AC Power Supply	100-240VAC, 50/60 Hz
Dimensions	1.75 x 17.0 x 13.5 inches (44.45 x 432 x 342 mm)
Weight	7.72 lbs (3.5 kg)
Operating Temperature	32°F to 113°F (0°C to 45°C)
Compliance / Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	38 Gbps
NGFW Throughput	29 Gbps
Threat Protection Throughput	26 Gbps
System Performance and Capacity
IPv6 Firewall Throughput	164 / 163 / 145 Gbps (1518/512/86 byte, UDP)
Firewall Latency	3.87 µs (64 byte, UDP)
Firewall Throughput (Packet per Second)	217.5 Mpps
Concurrent Sessions (TCP)	16 Million
New Sessions/Second (TCP)	700,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)	55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	8 Gbps
Concurrent SSL-VPN Users (Recommended Max)	10,000 (Tunnel Mode)
SSL Inspection Throughput	14 Gbps (IPS, avg. HTTPS)
SSL Inspection CPS	13,000 (IPS, avg. HTTPS)
SSL Inspection Concurrent Session	1.6 Million (IPS, avg. HTTPS)
Application Control Throughput	50 Gbps (HTTP 64K)
CAPWAP Throughput	133 Gbps (HTTP 64K)
Virtual Domains (Default/Maximum)	10 / 50
Maximum Number of FortiSwitches Supported	96
Maximum Number of FortiAPs (Total/Tunnel)	1024 / 512
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware and Interfaces
Hardware Accelerated 25 GE SFP28/10 GE SFP+ Slots	4
Hardware Accelerated 10 GE SFP+/GE SFP Slots	4
Hardware Accelerated GE SFP Slots	16
Hardware Accelerated GE RJ45 Slots	8 (5 / 2.5 / GE)
2.5 GE/GE HA Port	1
GE Management Port	1
USB Ports (Client/Server)	2
Console Port	1
Trusted Platform Module (TPM)	Yes
FortiSentry	Yes
Dimensions and Power
Power Consumption (Average/Maximum)	240 W / 295 W
AC Current (Maximum)	6A @ 100VAC
Heat Dissipation	1006 BTU/h
Redundant Power Supplies	Default dual non-swappable AC PSU for 1+1 Redundancy
Operating Environment and Certifications
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	59 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3,048 m)

[/specifications]

[accesories]

Included Accessories	2x SFP SX Transceivers, Default Dual Internal Power Supplies
Optional Accessories	1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), Direct Attach Cables (10 GE SFP+, 25 GE SFP28)

[/accesories]

The Fortinet FortiGate 701G Series Next-Generation Firewall (NGFW) combines artificial intelligence (AI)-powered security and machine learning (ML) to deliver threat protection at any scale. Powered by Fortinet's patented SPU NP7 and the tenth-generation content processor (CP10), the FG-701G delivers ultra-fast threat protection and SSL inspection without impacting performance.

Designed for modern, high-bandwidth networks, the FortiGate 701G features a versatile array of interfaces, including four 25 GE SFP28 slots, four 10 GE SFP+ slots, and eight 5G BASE-T RJ45 ports. It incorporates FortiSentry, an out-of-band hardware module designed to enhance system integrity by continuously monitoring the FortiOS file system integrity. With dual internal AC power supplies included by default, the FG-701G supports resilient deployments in enterprise environments.

Data-Driven Security with 960GB Storage and CP10 Acceleration

Key Benefits

• High-Speed Processing: Delivers 38 Gbps IPS throughput and 29 Gbps NGFW throughput powered by NP7 and CP10.
• Integrated Storage: Includes 2x 480 GB (960 GB total) onboard SSD storage.
• Versatile Connectivity: Equipped with 4x 25 GE SFP28, 4x 10 GE SFP+, and 8x 5G BASE-T RJ45 ports for flexible deployment.
• System Integrity: FortiSentry hardware module continuously monitors FortiOS file system integrity to detect and prevent unauthorized modifications.
• Encrypted Traffic Inspection: Provides 14 Gbps of SSL inspection throughput (IPS, avg. HTTPS) for securing encrypted traffic.
• Operational Resilience: Includes default dual internal power supplies (1+1 redundancy) to maximize uptime.
• AI-Powered Defense: Leverages FortiGuard AI/ML-powered security services for consolidated threat protection.

Ideal Use Cases

• Enterprise Edge Security: High-performance inspection and threat protection for enterprise networks.
• Secure SD-WAN: Converged networking and security for WAN edge transformation and hybrid working models.
• Segmentation: Network segmentation to reduce lateral threats and support hybrid IT environments.
• Hybrid Mesh Firewall: Consistent policy enforcement and threat protection across network segments.

Technical Specifications Summary

• IPS Throughput: 38 Gbps
• NGFW Throughput: 29 Gbps
• Threat Protection Throughput: 26 Gbps
• IPv4 Firewall Throughput (UDP): 164 / 163 / 145 Gbps (1518/512/64 byte)
• IPv6 Firewall Throughput (UDP): 164 / 163 / 145 Gbps (1518/512/86 byte)
• IPsec VPN Throughput (512 byte): 55 Gbps
• SSL-VPN Throughput: 8 Gbps
• SSL Inspection Throughput (IPS, avg. HTTPS): 14 Gbps
• Concurrent Sessions (TCP): 16 Million
• Interfaces: 4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5G BASE-T RJ45, 2x RJ45 (HA/MGMT)
• Onboard Storage: 2x 480 GB (960 GB total)

Upgrade Your Network Security

Enhance your enterprise defense with the high-performance FortiGate 701G.
