[shortdesc]Firewall, 1RU rack mount, 4x 25GE SFP28, 4x 10GE SFP+, 164 Gbps firewall, including 3 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP)[/shortdesc]

[properties]

Product Name	FortiGate 700G
SKU	FG-700G-BDL-950-36
Bundle / Subscription	BDL-950 (Hardware + FortiCare Premium + FortiGuard Unified Threat Protection (UTP)), 3 Year
Form Factor	Rack Mount, 1RU
Firewall Throughput (IPv4)	164 / 163 / 145 Gbps (1518 / 512 / 64 byte, UDP)
Interfaces	4x 25/10GE SFP28/SFP+, 4x 10GE SFP+ FortiLink, 16x 1GE SFP, 8x 5/2.5/GE RJ45, 1x 2.5/GE RJ45 HA, 1x GE RJ45 Management
Power Input	100-240VAC, 50/60 Hz
Dimensions	1.75 x 17.0 x 13.5 inches (44.45 x 432 x 342 mm)
Weight	7.72 lbs (3.5 kg)
Operating Temperature	32°F to 113°F (0°C to 45°C)
Certifications	Compliance: FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; Certifications: USGv6/IPv6

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	38 Gbps
NGFW Throughput	29 Gbps
Threat Protection Throughput	26 Gbps
System Performance and Capacity
IPv6 Firewall Throughput	164 / 163 / 145 Gbps (1518/512/86 byte, UDP)
Firewall Latency	3.87 μs (64 byte, UDP)
Firewall Throughput (Packet per Second)	217.5 Mpps
Concurrent Sessions (TCP)	16 Million
New Sessions/Second (TCP)	700,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)	55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	8 Gbps
Concurrent SSL-VPN Users (Recommended Max)	10,000 (Tunnel Mode)
SSL Inspection Throughput	14 Gbps (IPS, avg. HTTPS)
SSL Inspection CPS	13,000 (IPS, avg. HTTPS)
SSL Inspection Concurrent Session	1.6 Million (IPS, avg. HTTPS)
Application Control Throughput	50 Gbps (HTTP 64K)
CAPWAP Throughput	133 Gbps (HTTP 64K)
Virtual Domains (Default/Maximum)	10 / 50
Maximum Number of FortiSwitches Supported	96
Maximum Number of FortiAPs (Total/Tunnel)	1024 / 512
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware and Interfaces
Hardware Accelerated 25 GE SFP28/10 GE SFP+ Slots	4
Hardware Accelerated 10 GE SFP+/GE SFP Slots	4
Hardware Accelerated GE SFP Slots	16
Hardware Accelerated GE RJ45 Slots	8 (5 / 2.5 / GE)
2.5 GE/GE HA Port	1
GE Management Port	1
USB Ports (Client/Server)	2
Console Port	1
Onboard Storage	No
Trusted Platform Module (TPM)	Yes
FortiSentry	Yes
Dimensions and Power
Power Consumption (Average/Maximum)	230 W / 283 W
AC Current (Maximum)	6A @ 100VAC
Heat Dissipation	965 BTU/h
Redundant Power Supplies	Default dual non-swappable AC PSU for 1+1 Redundancy
Operating Environment and Certifications
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	59 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3,048 m)

[/specifications]

[accesories]

Included Accessories	2x SFP SX Transceivers, Default Dual Internal Power Supplies
Optional Accessories	1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), Direct Attach Cables (10 GE SFP+, 25 GE SFP28)

[/accesories]

The Fortinet FortiGate 700G Series next-generation firewall (NGFW) combines artificial intelligence (AI)-powered security and machine learning (ML) to deliver threat protection at any scale. Powered by Fortinet's patented Network Processor 7 (NP7) and Content Processor 10 (CP10), this appliance delivers ultra-fast threat protection and SSL inspection without impacting performance. The CP10 processor accelerates resource-intensive security functions such as pattern matching and fast inspection of real-time traffic.

This FG-700G-BDL-950-36 bundle includes Hardware + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) for a 3-year term, aligning support coverage with integrated security services. The FortiGate 700G is designed for connectivity and resilience, featuring a diverse range of interfaces including four 25/10GE SFP28/SFP+ slots, four 10GE SFP+ FortiLink slots, and eight 5/2.5/GE RJ45 ports to accommodate modern network demands. It also incorporates FortiSentry, an out-of-band hardware module that continuously monitors the integrity of the FortiOS file system to detect and prevent unauthorized modifications. With default dual internal power supplies for 1+1 redundancy, the FG-700G is built for mission-critical deployments including hybrid mesh firewall architectures and secure SD-WAN.

Advanced AI-Powered Security with 25GE Connectivity and CP10 Acceleration

Key Benefits

• Unparalleled Performance: Delivers 38 Gbps IPS and 29 Gbps NGFW throughput powered by NP7 and CP10 processors.
• Future-Proof Connectivity: Equipped with 4x 25/10GE SFP28/SFP+ and 4x 10GE SFP+ FortiLink slots for high-speed integration.
• System Integrity: Features FortiSentry, a dedicated module that monitors FortiOS file system integrity to prevent unauthorized modifications.
• Real-Time Visibility: Provides 14 Gbps SSL inspection throughput to inspect encrypted traffic at scale.
• Access Layer Security: FortiLink-enabled ports integrate FortiSwitch as a logical extension of the firewall and can be reconfigured as regular ports.
• Operational Reliability: Default dual non-swappable AC power supplies support 1+1 redundancy for continuous operation.
• Unified Security Fabric: Extends AI/ML-powered protection into an integrated security fabric platform for broad, automated enforcement.

Ideal Use Cases

• Enterprise Edge Protection: High-performance inspection with AI-powered security services for web, content, and device security.
• Hybrid Mesh Firewall: Consistent policy enforcement and threat protection across all network segments.
• Secure SD-WAN: Secure networking with FortiOS for converged networking and security at the WAN edge.
• Segmentation: Network segmentation and coordinated protection to reduce risk and lateral movement in hybrid IT environments.

Technical Specifications Summary

• IPS Throughput (Enterprise Traffic Mix): 38 Gbps
• NGFW Throughput (Enterprise Traffic Mix): 29 Gbps
• Threat Protection Throughput (Enterprise Traffic Mix): 26 Gbps
• IPv4 Firewall Throughput: 164 / 163 / 145 Gbps (1518 / 512 / 64 byte, UDP)
• IPv6 Firewall Throughput: 164 / 163 / 145 Gbps (1518 / 512 / 86 byte, UDP)
• IPsec VPN Throughput (512 byte): 55 Gbps
• SSL Inspection Throughput: 14 Gbps (IPS, avg. HTTPS)
• Concurrent Sessions (TCP): 16 Million
• Interfaces: 4x 25/10GE SFP28/SFP+, 4x 10GE SFP+ FortiLink, 16x 1GE SFP, 8x 5/2.5/GE RJ45
• Power Consumption (Average/Maximum): 230 W / 283 W
• Dimensions: 1.75 x 17.0 x 13.5 inches (44.45 x 432 x 342 mm)
• Operating Temperature: 32°F to 113°F (0°C to 45°C)

Upgrade Your Network Security

Secure your enterprise with the AI-powered performance of the FortiGate 700G with the FG-700G-BDL-950-36 bundle.
