Fortinet FortiGate 700G Next-Generation Firewall

Product image 1
Product image 2
Product image 3

Fortinet FortiGate 700G Next-Generation Firewall

Fortinet FortiGate 700G Next-Generation Firewall

[shortdesc]Firewall, 1RU, 164/163/145 Gbps firewall, 29 Gbps NGFW, 38 Gbps IPS, 4x 25GE SFP28, 4x 10GE SFP+, 8x 5GE RJ45[/shortdesc]

[properties]

Product Name FortiGate 700G
SKU FG-700G
Form Factor Rack Mount, 1RU
Firewall Throughput (IPv4) 164 / 163 / 145 Gbps (1518 / 512 / 64 byte, UDP)
Interfaces 4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5/2.5/GE RJ45, 1x 2.5 GE/GE HA, 1x GE Management
Power Input 100-240VAC, 50/60 Hz
Dimensions 1.75 x 17.0 x 13.5 inches (44.45 x 432 x 342 mm)
Weight 7.72 lbs (3.5 kg)
Operating Temperature 32°F to 113°F (0°C to 45°C)
Certifications FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput 38 Gbps
NGFW Throughput 29 Gbps
Threat Protection Throughput 26 Gbps
System Performance and Capacity
IPv6 Firewall Throughput 164 / 163 / 145 Gbps (1518/512/86 byte, UDP)
Firewall Latency 3.87 μs (64 byte, UDP)
Firewall Throughput (Packet per Second) 217.5 Mpps
Concurrent Sessions (TCP) 16 Million
New Sessions/Second (TCP) 700000
Firewall Policies 10,000
IPsec VPN Throughput (512 byte) 55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 2,000
Client-to-Gateway IPsec VPN Tunnels 50,000
SSL-VPN Throughput 8 Gbps
Concurrent SSL-VPN Users (Recommended Max) 10,000 (Tunnel Mode)
SSL Inspection Throughput 14 Gbps (IPS, avg. HTTPS)
SSL Inspection CPS 13,000 (IPS, avg. HTTPS)
SSL Inspection Concurrent Session 1.6 Million (IPS, avg. HTTPS)
Application Control Throughput 50 Gbps (HTTP 64K)
CAPWAP Throughput 133 Gbps (HTTP 64K)
Virtual Domains (Default/Maximum) 10 / 50
Maximum Number of FortiSwitches Supported 96
Maximum Number of FortiAPs (Total/Tunnel) 1024 / 512
Maximum Number of FortiTokens 5,000
High Availability Configurations Active-Active, Active-Passive, Clustering
Hardware and Interfaces
Hardware Accelerated 25 GE SFP28/10 GE SFP+ Slots 4
Hardware Accelerated 10 GE SFP+/GE SFP Slots 4
Hardware Accelerated GE SFP Slots 16
Hardware Accelerated GE RJ45 Slots 8 (5 / 2.5 / GE)
2.5 GE/GE HA Port 1
GE Management Port 1
USB Ports (Client/Server) 2
Console Port 1
Onboard Storage No
Trusted Platform Module (TPM) Yes
FortiSentry Yes
Dimensions and Power
Power Consumption (Average/Maximum) 230 W / 283 W
AC Current (Maximum) 6A @ 100VAC
Heat Dissipation 965 BTU/h
Redundant Power Supplies Default dual non-swappable AC PSU for 1+1 Redundancy
Operating Environment and Certifications
Storage Temperature -31°F to 158°F (-35°C to 70°C)
Humidity 10% to 90% non-condensing
Noise Level 59 dBA
Forced Airflow Side and Front to Back
Operating Altitude Up to 10,000 ft (3,048 m)
Compliance FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB

[/specifications]

[accesories]

Included Accessories 2x SFP SX Transceivers, Default Dual Internal Power Supplies
Optional Accessories 1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), Direct Attach Cables (10 GE SFP+, 25 GE SFP28)

[/accesories]

The Fortinet FortiGate 700G Series next-generation firewall (NGFW) utilizes advanced artificial intelligence (AI) and machine learning (ML) to provide scalable threat protection and deep visibility across enterprise networks. Driven by Fortinet's patented Network Processor 7 (NP7) and the new Content Processor 10 (CP10), this appliance delivers high performance, including 38 Gbps of IPS throughput and 50 Gbps of Application Control throughput. The inclusion of the CP10 processor accelerates resource-intensive security functions such as pattern matching and fast inspection of real-time traffic.

The FortiGate 700G is designed for connectivity and resilience, featuring a diverse range of interfaces including four 25 GE SFP28 slots, four 10 GE SFP+ slots, and eight 5 GE RJ45 ports to accommodate modern network demands. It also incorporates FortiSentry, an out-of-band module that continuously monitors the integrity of the FortiOS filesystem to detect and prevent unauthorized modifications. With dual non-swappable AC power supplies included for redundancy, the FG-700G supports mission-critical deployments for data centers, hybrid mesh firewalls, and secure SD-WAN.

Advanced AI-Powered Security with 25GE Connectivity and CP10 Acceleration

Key Benefits

  • Unparalleled Performance: Delivers 38 Gbps IPS and 29 Gbps NGFW throughput powered by NP7 and CP10 processors.
  • Future-Proof Connectivity: Equipped with 4x 25 GE SFP28 and 8x 5 GE RJ45 ports for high-speed network integration.
  • System Integrity: Features FortiSentry, a dedicated module that monitors FortiOS integrity to help prevent unauthorized modifications.
  • AI-Driven Protection: Uses AI/ML-powered security capabilities to help detect and prevent known, zero-day, and unknown attacks.
  • Deep Visibility: Provides 14 Gbps of SSL inspection throughput (IPS, avg. HTTPS) to inspect encrypted traffic.
  • Operational Reliability: Includes default dual internal power supplies for 1+1 redundancy.
  • Unified Management: Supports an integrated security fabric approach for consistent policy enforcement across hybrid environments.

Ideal Use Cases

  • Enterprise Edge Protection: Securing the network perimeter with high-performance inspection and AI-driven threat defense.
  • Hybrid Mesh Firewall: Providing consistent security and policy enforcement across on-premise and cloud segments.
  • Secure SD-WAN: Transforming WAN edges with a unified platform that combines networking and security capabilities.
  • Internal Segmentation: Using VXLAN segmentation and high-speed interfaces to help reduce lateral threat movement.

Technical Specifications Summary

  • IPS Throughput: 38 Gbps
  • NGFW Throughput: 29 Gbps
  • Threat Protection Throughput: 26 Gbps
  • IPv4 Firewall Throughput: 164 / 163 / 145 Gbps (1518 / 512 / 64 byte, UDP)
  • IPv6 Firewall Throughput: 164 / 163 / 145 Gbps (1518 / 512 / 86 byte, UDP)
  • IPsec VPN Throughput (512 byte): 55 Gbps
  • SSL Inspection Throughput: 14 Gbps (IPS, avg. HTTPS)
  • Concurrent Sessions (TCP): 16 Million
  • New Sessions/Second (TCP): 700000
  • Interfaces: 4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5/2.5/GE RJ45, 1x 2.5 GE/GE HA, 1x GE Management
  • Power Consumption (Average/Maximum): 230 W / 283 W
  • Dimensions: 1.75 x 17.0 x 13.5 inches (44.45 x 432 x 342 mm)

Upgrade Your Network Security

Secure your enterprise with the AI-powered performance of the FortiGate 700G.

$6,283.20

Original: $17,952.00

-65%
