[shortdesc] Desktop firewall, secure SD-WAN, embedded 5G WAN, 64GB SSD, including 3 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]

[properties]

Feature	Details
Product SKU	FG-51G-5G-BDL-950-36
Bundle Contents	FortiGate appliance plus FortiCare Premium and FortiGuard Unified Threat Protection (UTP) (3Yr Contract)
Form Factor	Desktop
Integrated Modem	Embedded 3G/4G/LTE/5G wireless WAN module
Internal Storage	64 GB SSD
Firewall Throughput	5 / 5 / 4 Gbps (1518/512/64 byte UDP packets)
Interfaces	5x GE RJ45 Ports (1x WAN, 1x FortiLink, 3x Internal Ethernet), 5x SMA WWAN Antenna Ports
Threat Protection	1.1 Gbps
Power Input	12VDC, 3A
Dimensions (H x W x L)	1.6 x 8.5 x 6.3 inches (40.5 x 216 x 160 mm)
Weight	2.2 lbs (1.0 kg)

[/properties]

[specifications]

System Performance & Capacity
IPS Throughput	2.25 Gbps
NGFW Throughput	1.25 Gbps
Firewall Latency	2.42 μs
Concurrent Sessions (TCP)	720,000
New Sessions/Second (TCP)	85,000
Firewall Policies	2,000
Wireless WAN (5G/LTE) Specifications
Modem Model	Telit Cinterion FN990A28-HP
5G Bands	n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29 (SDL), n30, n38, n40, n41, n48, n66, n71, n75 (SDL), n76 (SDL), n77, n78, n79 (PC1.5 support on n41, n77, n78, n79 bands)
LTE Bands	B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29 (SDL), B30, B32 (SDL), B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
SIM Slots	2x Nano SIM (Active/Passive)
Carrier Certifications	PTCRB (Yes), AT&T (Yes), T-Mobile (Target Q4), Verizon (Target Q4), Public Safety Network (Yes; FirstNet Capable)
VPN Performance
IPsec VPN Throughput (512 byte)	4.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	250
SSL Inspection Throughput	1.3 Gbps
Hardware & Environment
USB Port	1x USB
Console Port	1x RJ45
Power Consumption (Average / Max)	8.3 W / 8.9 W
Heat Dissipation	30.35 BTU/h
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	10% to 90% non-condensing
Noise Level	Fanless 0 dBA
Compliance & Certifications	Compliance: FCC, ISED, CE, UL/cUL, CB; Certifications: USGv6/IPv6

[/specifications]

[accesories]

Accessory Type	Description
Included	5x External SMA WWAN Antennas
Optional	Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-40F-PA-10 (-XX))

[/accesories]

The FortiGate 51G-5G series transforms distributed enterprise connectivity with a powerful combination of Next-Generation Firewall security, embedded high-speed 5G connectivity, and onboard storage. Built on the patented SD-WAN-based ASIC (SP5), this appliance delivers strong performance, while the integrated cellular module provides a robust primary or failover connection to help maintain business continuity at remote or branch locations. This bundle includes FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for a 3-year contract term.

This compact desktop appliance features a Telit Cinterion FN990A28-HP modem supporting a wide range of 5G and LTE bands. With dual Nano SIM slots, it enables carrier redundancy, allowing organizations to maintain uptime even if one cellular network fails. Additionally, the FG-51G-5G includes 64GB of internal SSD storage.

High-Performance 5G SD-WAN Gateway with Storage

Key Benefits

• Embedded 5G Connectivity: Integrated 5G/LTE wireless WAN module supports flexible deployment as a primary or failover WAN connection.
• Integrated SSD Storage: 64GB onboard SSD storage.
• SP5 ASIC Performance: Built on Fortinet's patented SD-WAN-based ASIC (SP5) to accelerate secure networking and security functions.
• Carrier Redundancy: Dual Nano SIM slots (Active/Passive) allow for flexible carrier switching to maximize uptime and network resilience.
• Converged Security and SD-WAN: Integrates firewalling, SD-WAN, and security in one appliance for distributed enterprise sites.

Ideal Use Cases

• 5G Branch Connectivity: Provides high-speed primary connectivity for locations where wired broadband is unavailable, expensive, or slow.
• Mission-Critical Failover: Acts as a reliable backup connection for retail and enterprise branches to prevent downtime during wired outage events.
• Local Storage Requirements: Supports deployments requiring onboard SSD storage on the appliance.
• Pop-Up & Mobile Sites: Rapidly deploys secure, high-bandwidth networking for temporary kiosks, construction sites, or mobile workstations.

Technical Specifications Summary

• Firewall Throughput: 5 / 5 / 4 Gbps (1518/512/64 byte UDP packets)
• Enterprise Mix Security Performance: IPS 2.25 Gbps, NGFW 1.25 Gbps, Threat Protection 1.1 Gbps
• Firewall Performance: 2.42 μs latency (64 byte UDP), 6 Mpps firewall throughput (packets per second)
• Session Capacity: 720,000 concurrent sessions (TCP), 85,000 new sessions/second (TCP), 2,000 firewall policies
• IPsec VPN: 4.5 Gbps (512 byte), 200 gateway-to-gateway tunnels, 250 client-to-gateway tunnels
• SSL Inspection: 1.3 Gbps (IPS, avg. HTTPS), 699 CPS, 74,000 concurrent sessions
• Application and CAPWAP Throughput: 2.8 Gbps application control (HTTP 64K), 3.8 Gbps CAPWAP (HTTP 64K)
• Ports, SIM, and Antennas: 1x GE RJ45 WAN, 1x GE RJ45 FortiLink (default), 3x GE RJ45 Ethernet, 1x USB, 1x RJ45 console; 2x Nano SIM (Active/Passive); 5x SMA WWAN antenna ports
• Storage: 64 GB SSD
• Power, Environment, and Compliance: 12VDC, 3A; 8.3 W avg / 8.9 W max; fanless 0 dBA; 32°F to 104°F (0°C to 40°C); FCC, ISED, CE, UL/cUL, CB; USGv6/IPv6

Upgrade Your Network Security

Deploy the FortiGate 51G-5G Bundle (FG-51G-5G-BDL-950-36) today for a secure, resilient, and storage-enhanced network utilizing the power of 5G, including FortiCare Premium and FortiGuard Unified Threat Protection (UTP) coverage for 3 years.
