[shortdesc]FortiGate 4800F-DC Firewall, 4RU, 3.1 Tbps IPv4, 87 Gbps IPS, 8x 400GE QSFP-DD, -72V to -40V DC[/shortdesc]

[properties]

Property	Value
Model / SKU	FG-4800F-DC
Form Factor	Rack Mount 4 RU
Firewall Throughput (IPv4 1518 byte)	3.1 Tbps
IPS Throughput	87 Gbps
Interfaces (Summary)	8x 400GE/200GE/100GE/40GE QSFP-DD, 12x 200GE/100GE/40GE QSFP56/28, 8x 50GE/25GE/10GE/GE SFP56/28, 4x 50GE/25GE/10GE/GE SFP56/28 (HA/Aux), 2x 10GE/GE RJ45 Management Ports, 1x USB 3.0, 1x Console
Power Input	-72V to -40V DC
Dimensions (H x W x L)	175 x 435 x 663 mm (6.89 x 17.13 x 26.10 inches)
Weight	41.2 kg (90.83 lbs)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Compliance & Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

Category	Specification	Value
System Performance	NGFW Throughput	77 Gbps
System Performance	Threat Protection Throughput	75 Gbps
System Performance	IPv4 Firewall Throughput (1518/512/64 byte, UDP)	3.1/3.1/0.93 Tbps
System Performance	IPv6 Firewall Throughput (1518/512/86 byte, UDP)	3.1/3.1/0.93 Tbps
System Performance	Firewall Latency (64 byte, UDP)	3.6 μs
System Performance	Firewall Throughput (Packet per Second)	1396 Mpps
System Performance	Concurrent Sessions (TCP)	280 Million / 1.8 Billion*
System Performance	New Sessions/Second (TCP)	915,000 / 25 Million*
System Performance	Firewall Policies	200,000
System Performance	IPsec VPN Throughput (512 byte)	1,800 Gbps
System Performance	Gateway-to-Gateway IPsec VPN Tunnels	40,000
System Performance	Client-to-Gateway IPsec VPN Tunnels	200,000
System Performance	SSL-VPN Throughput	18 Gbps
System Performance	SSL Inspection Throughput	63 Gbps
System Performance	Application Control Throughput (HTTP 64K)	180 Gbps
System Capacity	Virtual Domains (Default/Maximum)	10/500
System Capacity	Maximum Number of FortiSwitches Supported	300
System Capacity	Maximum Number of FortiAPs (Total/Tunnel)	8192/4096
System Capacity	Maximum Number of FortiTokens	20,000
System Capacity	SSL VPN Concurrent Users (Recommended Maximum, Tunnel Mode)	30,000
System Capacity	SSL Inspection CPS (IPS, avg. HTTPS)	60,000
System Capacity	SSL Inspection Concurrent Session (IPS, avg. HTTPS)	30 Million
Networking Interfaces	Hardware Accelerated 400GE/200GE/100GE/40GE QSFP-DD/QSFP56/QSFP28/QSFP+ Slots	8
Networking Interfaces	Hardware Accelerated 200GE/100GE/40GE QSFP56/QSFP28/QSFP+ slots	12
Networking Interfaces	Hardware Accelerated 50GE/25GE/10GE/GE SFP56/SFP28/SFP+/SFP slots	8
Networking Interfaces	Hardware Accelerated 50GE/25GE/10GE/GE SFP56/SFP28/SFP+/SFP High Availability and Aux Slots	4
Networking Interfaces	10GE/GE RJ45 Management Ports	2
Networking Interfaces	USB Port (3.0)	1
Networking Interfaces	Console Port	1
Environment	Storage Temperature	-35°C to 70°C (-31°F to 158°F)
Environment	Humidity	10% to 90% non-condensing
Environment	Noise Level	63.794 dBA
Environment	Heat Dissipation	6544.9 BTU/h
Environment	Forced Airflow	Front to Back
Environment	Operating Altitude	Up to 3048 m (10,000 ft)
Power	DC Current (Maximum)	40.94A @ 48VDC
Power	Power Consumption (Average/Maximum)	1602 W / 1918.2 W
Power	Redundant Power Supplies	Hot Swappable, 2+2
Power	Power Supply Efficiency Rating	80Plus Compliant
Hardware Features	Processors	SPU NP7 and CP9 hardware accelerated
Hardware Features	High Availability Configurations	Active-Active, Active-Passive, Clustering

[/specifications]

[accesories]

Category	Item	Description
Included	Transceivers	2x SFP+ (SR 10 GE)
Optional	Hyperscale Firewall License (LIC-FGT-HYPSC)	Hyperscale Firewall License for hardware session setup acceleration and logging; enables hardware acceleration of CGNAT features and is required for starred session metrics.
Optional	DC Power Supply (SP-FG4000F-DC-PS)	DC power supply for FG-4200F-DC/4400F-DC/4800F-DC/6000F-DC, comes with 3m DC cable.
Optional	Fan Tray (SP-FG4K6K-FAN)	Spare Hotswappable Fan Module for FG-420xF/440xF/480xF/6000F.
Optional	Transceiver Modules	Examples include FN-TRAN-GC (1 GE SFP RJ45), FN-TRAN-SFP+SR (10 GE SFP+ SR), FN-TRAN-SFP28-SR (25 GE SFP28 SR), FN-TRAN-QSFP28-SR (100 GE QSFP28 SR), FN-TRAN-QSFP56-FR4 (200 GE QSFP56 FR4), and FN-TRAN-QSFPDD-LR4 (400 GE QSFPDD LR4).
Optional	Cables	400 GE QSFPDD Passive Direct Attach Cable options include FN-CABLE-QSFPDD-DAC-01 (1m) and FN-CABLE-QSFPDD-DAC-B5 (2.5m).

[/accesories]

The Fortinet FortiGate 4800F-DC enables organizations to build security-driven networks, forming the foundation of a robust Hybrid Mesh Firewall architecture. Designed for environments with DC power infrastructure, this firewall weaves security deep into the datacenter and across hybrid IT environments, protecting any edge at any scale. Powered by a rich set of AI/ML-based FortiGuard Services and an integrated security fabric platform, the FortiGate 4800F-DC delivers coordinated, automated, end-to-end threat protection across all use cases.

Secure Networking with Hyperscale Performance and DC Power Support

• Experience Unparalleled Performance with Fortinet's patented SPU NP7 and CP9 processors, delivering industry-leading throughput and ultra-low latency for DC-powered data centers.
• Achieve Hyperscale Security with purpose-built SPUs that power FortiOS to consolidate networking and security, offering the industry's highest number of connections and connections per second.
• Leverage Enterprise Security through consolidated AI/ML-powered FortiGuard services, protecting against ransomware, zero days, and sophisticated cyberattacks.
• Enable Integrated Zero Trust Network Access (ZTNA) enforcement within the NGFW solution, reducing lateral threats by ensuring only validated users can access applications.
• Support 400GE Connectivity with multiple QSFP-DD slots, simplifying network designs for high-speed security segmentation at the core of data networks.
• Ensure Future-Proof Convergence with FortiOS, providing a unified framework for managing and securing IT, OT, and IoT environments across the hybrid network.

Ideal Use Cases

• Hyperscale Data Centers: Deploying ultra-scalable secure networks in DC-powered facilities that consolidate networking and security functions with unparalleled performance.
• Next-Generation Firewall (NGFW): Securing web, content, and devices with real-time SSL inspection (including TLS 1.3) and AI-powered security services.
• Segmentation: Implementing dynamic, ultra-scalable, low latency VXLAN segmentation to prevent lateral movement across the network from branch to data center.
• Secure SD-WAN: Transforming and securing WANs with superior quality of experience and effective security posture for hybrid working models.
• Mobile Security for 4G, 5G, and IoT: Utilizing SPU-accelerated, high-performance CGNAT, IPv6 migration options, and comprehensive security for emerging mobile networks.
• Data Center Edge: Protecting critical applications and data in data center environments with ultra-high throughput and low latency firewalling and threat prevention.

FortiGate 4800F-DC Technical Specifications Summary

• IPS Throughput: 87 Gbps
• NGFW Throughput: 77 Gbps
• Threat Protection Throughput: 75 Gbps
• IPv4 Firewall Throughput (1518/512/64 byte, UDP): 3.1/3.1/0.93 Tbps
• IPsec VPN Throughput (512 byte): 1,800 Gbps
• SSL Inspection Throughput (IPS, avg. HTTPS): 63 Gbps
• Application Control Throughput (HTTP 64K): 180 Gbps
• Concurrent Sessions (TCP): 280 Million / 1.8 Billion* (requires Hyperscale Firewall License)
• Interfaces: 8x 400GE/200GE/100GE/40GE QSFP-DD, 12x 200GE/100GE/40GE QSFP56/28, 8x 50GE/25GE/10GE/GE SFP56/28, 4x 50GE/25GE/10GE/GE SFP56/28 (HA/Aux), 2x 10GE/GE RJ45 Management Ports
• DC Power Input: -72V to -40V
• Power Consumption (Average/Maximum): 1602 W / 1918.2 W
• Dimensions / Weight: 175 x 435 x 663 mm, 41.2 kg (90.83 lbs)

The FortiGate 4800F-DC also supports advanced integration with FortiGuard AI-powered security services, including malware protection, web filtering, intrusion prevention, and application control. Fortinet's SPU architecture enables extreme scalability and high connection rates, ensuring reliable performance in demanding environments.

Upgrade Your Network Security

Choose the Fortinet FortiGate 4800F-DC to secure your hyperscale data center or DC-powered environment with unmatched performance and cutting-edge threat protection. Whether you are deploying next-gen firewalling, hybrid mesh architectures, or secure SD-WAN, FortiGate 4800F-DC provides the power and flexibility you need. Contact us today to learn more or request a quote.
