[shortdesc] Firewall, 3RU rack mount, 8x 100GE/40GE QSFP28/QSFP+, 18x 25GE/10GE SFP28 plus 2x 25GE HA, 800 Gbps firewall throughput, -48V to -60V DC [/shortdesc]

[properties]

Brand	Fortinet
Model / SKU	FG-4200F-DC
Form Factor	Rack Mount, 3 RU
Firewall Throughput	800 Gbps
Threat Protection Throughput	45 Gbps
Interfaces Summary	8x 100GE/40GE QSFP28/QSFP+ slots, 16x 25GE SFP28 plus 2x 25GE AUX, 2x 25GE HA, 2x GE RJ45 Mgmt, 1x USB, 1x Console
Power Input	-48V to -60V DC
Dimensions (H x W x L)	5.22 x 17.20 x 26.17 in (132.5 x 437 x 664.8 mm)
Weight	59.75 lbs (27.1 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	USGv6/IPv6
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB

[/properties]

[specifications]

System Performance (Enterprise Traffic Mix)
IPS Throughput	52 Gbps
NGFW Throughput	47 Gbps
System Performance & Capacity
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	800 / 788 / 400 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	800 / 788 / 400 Gbps
Firewall Latency (64 byte, UDP)	3.02 μs
Firewall Throughput (Packet per Second)	600 Mpps
Concurrent Sessions (TCP)	210 Million / 450 Million* (with Hyperscale Firewall License)
New Sessions/Second (TCP)	1 Million / 7 Million* (with Hyperscale Firewall License)
Firewall Policies	400,000
IPsec VPN Throughput (512 byte)	210 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
SSL-VPN Throughput	16 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	30,000
SSL Inspection Throughput (IPS, avg. HTTPS)	50 Gbps
Application Control Throughput (HTTP 64K)	135 Gbps
Virtual Domains (Default / Maximum)	10 / 500
Interfaces & Modules
100 GE QSFP28 / 40 GE QSFP+ Slots	8 (Hardware Accelerated)
25 GE SFP28 / 10 GE SFP+ / GE SFP Slots	16 (Hardware Accelerated)
25 GE SFP28 / 10 GE SFP+ / GE SFP HA Slots	2 (Hardware Accelerated)
25 GE SFP28 / 10 GE SFP+ / GE SFP AUX Slots	2 (Hardware Accelerated)
GE RJ45 Management Ports	2
USB Port	1
Console Port	1
Power & Environment
DC Current (Average / Maximum)	20A / 100Apk
Power Consumption (Average / Maximum)	931 W / 1291 W
Heat Dissipation	4405 BTU/h
Redundant Power Supplies	Default 1+1 Redundant, Hot Swappable
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	20% to 90% non-condensing
Noise Level	57 dBA
Physical Specifications

[/specifications]

[accesories]

Included in Box	2x DC power supplies, 2x SFP+ (SR 10 GE) Transceivers
Optional Accessories	Hyperscale Firewall License (LIC-FGT-HYPSC), Rack mount sliding rails (SP-FG3040B-RAIL), DC Power Supply (SP-FG4000F-DC-PS), Spare Fan Tray (SP-FG4K6K-FAN), Various SFP/QSFP Transceivers

[/accesories]

The Fortinet FortiGate 4200F-DC Series delivers uncompromising security and performance for large-scale enterprise data centers and service provider networks that rely on DC power infrastructure. By consolidating networking and security into a single platform, the FG-4200F-DC reduces complexity while providing deep visibility and protection. Its hyperscale architecture, driven by Fortinet's patented SPU NP7 technology, removes performance bottlenecks typically associated with software-based firewalls, enabling effective security for high-velocity traffic including elephant flows and VXLAN tunnels.

Designed for resilience and scalability, this appliance supports 210 million concurrent TCP sessions (up to 450 million with the Hyperscale Firewall License) and offers integrated Zero Trust Network Access (ZTNA) enforcement. The FortiGate 4200F-DC seamlessly weaves security into the network fabric, protecting against sophisticated threats with AI/ML-powered FortiGuard services. With a robust 3 RU form factor and redundant DC power supplies, it ensures continuous operation and business continuity for critical edge and core deployments.

Hyperscale Security for DC Power Environments

• Unmatched Throughput: Achieves 800 Gbps of firewall throughput and 52 Gbps of IPS throughput to secure high-volume traffic without latency.
• DC Power Optimization: Equipped with dual -48V to -60V DC power supplies, specifically engineered for telecommunications and data center power grids.
• High Port Density: Features 8x 100GE/40GE QSFP28/QSFP+ slots and high-density 25GE SFP28 connectivity (including HA and AUX interfaces) to simplify network architecture.
• Massive Scalability: Supports 210 million concurrent TCP sessions and 1 million new sessions per second (up to 450 million and 7 million respectively with the Hyperscale Firewall License) for carrier-grade demands.
• Hardware Acceleration: Utilizes SPU NP7 and CP9 processors to offload resource-intensive tasks like SSL inspection and IPsec VPN, ensuring consistent performance.
• Integrated Protection: Combines NGFW capabilities with automated threat protection against modern threats via FortiGuard services.
• Operational Efficiency: Consolidates networking and security into a single platform with a 3 RU design and efficient SPU acceleration.

• Service Provider Networks: Ideal for mobile security and core network protection requiring native DC power inputs.
• Hyperscale Data Centers: Secures east-west and north-south traffic flows with ultra-low latency and high-capacity session handling.
• High-Speed Segmentation: Isolates critical assets using VXLAN segmentation and hardware-accelerated inspection.
• Secure SD-WAN Hub: Acts as a high-performance hub for large distributed enterprises, ensuring secure connectivity across branches.

• IPv4 / IPv6 Firewall Throughput (1518/512/64 or 86 byte, UDP): 800 / 788 / 400 Gbps (IPv4), 800 / 788 / 400 Gbps (IPv6)
• IPS / NGFW / Threat Protection Throughput (Enterprise Mix): 52 Gbps / 47 Gbps / 45 Gbps
• IPsec VPN Throughput (512 byte) and Tunnels: 210 Gbps, 40,000 gateway-to-gateway, 200,000 client-to-gateway
• SSL-VPN and SSL Inspection: 16 Gbps SSL-VPN, 30,000 recommended max users, 50 Gbps SSL inspection throughput
• Latency and Firewall PPS: 3.02 μs (64 byte, UDP), 600 Mpps
• Session Scale and Policies: 210M / 450M concurrent sessions, 1M / 7M new sessions/sec, 400,000 firewall policies
• Virtual Domains: 10 default / 500 maximum
• Interfaces: 8x 100GE/40GE QSFP28/QSFP+, 16x 25GE SFP28, 2x 25GE HA, 2x 25GE AUX, 2x GE RJ45 Mgmt, 1x USB, 1x Console
• DC Power and Consumption: -48V to -60V DC, 20A avg / 100Apk max, 931 W avg / 1291 W max, 4405 BTU/h
• Physical and Environment: Rack mount 3 RU, 5.22 x 17.20 x 26.17 in (132.5 x 437 x 664.8 mm), 59.75 lbs (27.1 kg), 0°C to 40°C, 57 dBA
• Compliance and Certifications: FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

Upgrade Your Network Security

Deploy the FortiGate 4200F-DC for robust, hyperscale protection in your DC-powered infrastructure.
