Fortinet FG-40F Firewall
- 5 x GE RJ45 ports (including, 1 x WAN Port, 4 x Internal Ports)
[properties]
| Properties | FG-40F |
| Description |
5 x GE RJ45 ports (including 4 x Internal Ports, 1 x WAN Ports)
|
| Product Family |
Early Level Fortigate Firewalls
|
| Product Type | Firewall |
| GE RJ45 Internal Ports | 4 |
| GE RJ45 WAN Port | 1 |
| USB Port | 1 |
| Console (RJ45) | 1 |
| Wireless Interface | 0 |
[/properties][specifications]
|
System Performance
|
|
| Firewall Throughput (1518 / 512 / 64 byte, UDP) | 5 / 5 / 5 Gbps |
| Firewall Latency (64 byte UDP packets) | 2.97 |
| Firewall Throughput (Packets Per Second) | 7.5 Mpps |
| Concurrent Sessions (TCP) | 700.000 |
| New Sessions/Second (TCP) | 35.000 |
| Firewall Policies | 5.000 |
| IPsec VPN Throughput (512 byte packets) | 4.4 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL-VPN Throughput | 490 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum) | 200 |
| IPS Throughput | 1 Gbps |
| SSL Inspection Throughput | 310 Mbps |
| Application Control Throughput | 990 Mbps |
| NGFW Throughput | 800 Mbps |
| Threat Protection Throughput | 600 Mbps |
| CAPWAP Throughput | 3.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 16 / 8 |
| Maximum Number of FortiTokens | 500 |
| Maximum Number of FortiSwitches Supported | 8 |
| High Availability Configurations | Active/Active, Active/Passive, Clustering |
| Dimensions in. | 1.5 x 8.5 x 6.3 |
| Form Factor | Desktop |
| Power Required |
100240V AC, 6050 Hz (External DC Power Adapter)
|
| Maximum Current |
100V AC / 0.2A, 240V AC / 0.1A
|
| Power Consumption (Average / Maximum) | 7.74 W / 9.46 W |
| Operating Temperature | 32104°F (040°C) |
| Regulatory Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
|
| Certifications |
Certifications USGv6/IPv6
|
[/specifications][accesories]
| SP-RACKTRAY-02 |
Rack mount tray for all FortiGate E series and F series desktop models are backwards compatible with SP-RackTray-01. For list of compatible FortiGate products, visit our Documentation website, docs.fortinet.com
|
| SP-FG-40F-PA-10(-XX |
Pack of 10 AC power adaptors for FG/FWF-40F, come with interchangeable power plugs. (XX=various countries code)
|
| SP-FG60F-MOUNT-20 |
Pack of 20 wall mount kits for FG/FWF-40F series, FG/FWF-60F series, FG-80F, FG-81F and FG-80F-Bypass
|
[/accesories]
Fortinet FG-40F Firewall
The FortiGate 40F series provides a robust Security and SD-WAN solution in a small, fanless desktop design suitable for enterprise branch offices and mid-sized businesses. It offers protection against cyber threats through its leading secure SD-WAN capabilities, presenting a straightforward, cost-effective, and easily deployable solution. This product also features Universal ZTNA, ASIC Advantage.
Quick Specs:
- Fanless Design
- 5 x GE RJ45 ports (including 3x Internal Ports, 1x WAN Port and 1x FortiLink Port)
- Recommended for Home Networtks/Teleworker
- ISP Connection Speeds up to 310Mbps
Please see the related tabs for the FG-40F datasheet and compatible accessories.
