[shortdesc] FortiGate 400F-DC firewall, DC-powered 1RU rackmount, 8x 10GE SFP+, 10 Gbps NGFW, including 1 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]

[properties]

Model / SKU	FG-400F-DC-BDL-950-12
Bundle / Subscription	BDL-950: Appliance + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (1 Year)
Form Factor	Rack Mount, 1 RU
Firewall Throughput	79.5 / 78.5 / 70 Gbps (IPv4 & IPv6, 1518 / 512 / 64 byte, UDP)
NGFW Throughput	10 Gbps
Interfaces	18x GE RJ45, 8x GE SFP, 8x 10GE SFP+
Power Input	48-60VDC
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.11 lbs (6.4 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance
IPS Throughput	12 Gbps
Threat Protection Throughput	9 Gbps
Firewall Latency (64 byte, UDP)	4.19 μs / 2.5 μs (ULL ports)
Firewall Throughput (Packet per Second)	105 Mpps
IPsec VPN Throughput (512 byte)	55 Gbps
SSL-VPN Throughput	3.6 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	8 Gbps
Application Control Throughput (HTTP 64K)	28 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
System Capacity
Concurrent Sessions (TCP)	7.8 Million
New Sessions/Second (TCP)	500,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
Concurrent SSL-VPN Users (Recommended Max)	5,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	96 (FortiOS 7.6.1+; otherwise 72)
Maximum Number of FortiAPs (Total/Tunnel)	512 / 256
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
Hardware Accelerated GE RJ45 Interfaces	16
GE RJ45 Management Ports	2
Hardware Accelerated GE SFP Slots	8
Hardware Accelerated 10GE SFP+ Slots	4
Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots	4
USB Ports	1
RJ45 Console Port	1
Onboard Storage	0
Trusted Platform Module (TPM)	Yes
Dimensions & Environment
Power Supply	Dual DC power supplies
DC Current (Maximum)	12A
Power Consumption (Average / Maximum)	154.8 W / 189.2 W
Heat Dissipation	645.58 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB

[/specifications]

[accesories]

Included Accessories
Included Transceivers	2x SFP (SX 1 GE)
Optional Accessories (Sold Separately)
DC Power Supply	SP-FG400F-DC-PS
Transceivers	FN-TRAN-LX (1 GE SFP LX), FN-TRAN-GC (1 GE SFP RJ45), FN-TRAN-SX (1 GE SFP SX); FN-TRAN-SFP+GC (10 GE SFP+ RJ45), FN-TRAN-SFP+SR (10 GE SFP+ Short Range), FN-TRAN-SFP+LR (10 GE SFP+ Long Range), FN-TRAN-SFP+ER (10 GE SFP+ Extended Range), FN-TRAN-SFP+ZR (10 GE SFP+ 80KM extreme long range)
Cables	FN-CABLE-SFP+1 (10 GE SFP+ Passive Direct Attach Cable, 1m), FN-CABLE-SFP+3 (3m), FN-CABLE-SFP+5 (5m)

[/accesories]

The Fortinet FortiGate FG-400F-DC-BDL-950-12 bundle includes a FortiGate 400F-DC firewall appliance with FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for 1 Year. The FortiGate 400F series next-generation firewall combines AI-powered security and machine learning to deliver scalable threat protection with deep visibility into applications, users, and devices. Powered by Fortinet SPU acceleration (NP7 and CP9), the FortiGate 400F-DC delivers 10 Gbps of NGFW throughput and ultra-low latency performance for demanding deployments.

With integrated Secure SD-WAN and universal ZTNA capabilities, this appliance helps reduce complexity in hybrid IT networks while maintaining consistent policy enforcement and advanced protection. It includes 8x 10GE SFP+ slots (including 4 ultra-low latency slots), 8x GE SFP slots, and 18x GE RJ45 interfaces, and supports dual hot swappable DC power supplies for redundancy in DC-powered environments.

Technical Specifications Summary

• Security Performance (Enterprise Mix with Logging): 12 Gbps IPS throughput, 10 Gbps NGFW throughput, 9 Gbps threat protection throughput.
• Firewall Throughput & Packet Rate: 79.5 / 78.5 / 70 Gbps (IPv4/IPv6, 1518 / 512 / 64 byte UDP), 105 Mpps firewall throughput.
• Latency: 4.19 μs / 2.5 μs firewall latency (64 byte UDP), including Ultra Low Latency (ULL) ports.
• VPN Performance & Scale: 55 Gbps IPsec VPN throughput (512 byte), 2,000 gateway-to-gateway IPsec tunnels, 50,000 client-to-gateway IPsec tunnels.
• SSL & Remote Access: 3.6 Gbps SSL-VPN throughput, 5,000 concurrent SSL-VPN users (recommended maximum, tunnel mode).
• SSL Inspection & Application Control: 8 Gbps SSL inspection throughput (IPS, avg. HTTPS), 28 Gbps application control throughput (HTTP 64K), 65 Gbps CAPWAP throughput (HTTP 64K).

• Session Capacity: 7.8 million concurrent sessions (TCP), 500,000 new sessions/second (TCP).
• Policy & Virtualization: 10,000 firewall policies, 10 / 25 virtual domains (default / maximum).
• High Availability: Active-Active, Active-Passive, clustering configurations.

• Interfaces: 16 hardware accelerated GE RJ45, 2x GE RJ45 MGMT/HA, 8 hardware accelerated GE SFP, 4 hardware accelerated 10GE SFP+, 4 hardware accelerated 10GE SFP+ Ultra Low Latency slots.
• Power & Thermal: Dual DC power supplies, 12A max DC current, 154.8 W average / 189.2 W maximum power consumption, 645.58 BTU/h heat dissipation.
• Physical & Compliance: 1RU rack mount, 1.75 x 17.0 x 15.0 in (44.45 x 432 x 380 mm), 14.11 lbs (6.4 kg), 32°F to 104°F (0°C to 40°C), FCC Part 15 Class A / RCM / VCCI / CE / UL/cUL / CB, USGv6/IPv6.

Upgrade Your Network Security

Deploy the FortiGate FG-400F-DC-BDL-950-12 for high-performance protection in your DC-powered environment.
