[shortdesc] Firewall, dual DC power (48–60VDC), NP7/CP9 SPU acceleration, 18x GE RJ45, 8x GE SFP, 8x 10GE SFP+, 10 Gbps NGFW [/shortdesc]

[properties]

Product SKU	FG-400F-DC
Form Factor	Rack Mount, 1 RU
Firewall Throughput	79.5 / 78.5 / 70 Gbps (IPv4 & IPv6, 1518 / 512 / 64 byte, UDP)
NGFW Throughput	10 Gbps
Interfaces	18x GE RJ45, 8x GE SFP, 8x 10GE SFP+
Power Input	48-60VDC
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.11 lbs (6.4 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance
IPS Throughput	12 Gbps
Threat Protection Throughput	9 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	79.5 / 78.5 / 70 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	79.5 / 78.5 / 70 Gbps
Firewall Latency (64 byte, UDP)	4.19 μs / 2.5 μs (Latency based on Ultra Low Latency (ULL) ports)
Firewall Throughput (Packet per Second)	105 Mpps
IPsec VPN Throughput (512 byte)	55 Gbps
SSL-VPN Throughput	3.6 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	8 Gbps
Application Control Throughput (HTTP 64K)	28 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
System Capacity
Concurrent Sessions (TCP)	7.8 Million
New Sessions/Second (TCP)	500,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
Concurrent SSL-VPN Users (Recommended Max)	5,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	96 (FortiOS 7.6.1+; otherwise 72)
Maximum Number of FortiAPs (Total/Tunnel)	512 / 256
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
Hardware Accelerated GE RJ45 Interfaces	16
GE RJ45 Management Ports	2
Hardware Accelerated GE SFP Slots	8
Hardware Accelerated 10GE SFP+ Slots	4
Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots	4
USB Ports	1
RJ45 Console Port	1
Onboard Storage	0
Trusted Platform Module (TPM)	Yes
Dimensions & Environment
Power Supply	Dual DC power supplies
DC Current (Maximum)	12A
Power Consumption (Average / Maximum)	154.8 W / 189.2 W
Heat Dissipation	645.58 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB

[/specifications]

[accesories]

Included Accessories
Included Transceivers	2x SFP (SX 1 GE)
Optional Accessories (Sold Separately)
DC Power Supply	SP-FG400F-DC-PS
Transceivers	FN-TRAN-LX (1 GE SFP LX), FN-TRAN-GC (1 GE SFP RJ45), FN-TRAN-SX (1 GE SFP SX); FN-TRAN-SFP+GC (10 GE SFP+ RJ45), FN-TRAN-SFP+SR (10 GE SFP+ Short Range), FN-TRAN-SFP+LR (10 GE SFP+ Long Range), FN-TRAN-SFP+ER (10 GE SFP+ Extended Range), FN-TRAN-SFP+ZR (10 GE SFP+ 80KM extreme long range)
Cables	FN-CABLE-SFP+1 (10 GE SFP+ Passive Direct Attach Cable, 1m), FN-CABLE-SFP+3 (3m), FN-CABLE-SFP+5 (5m)

[/accesories]

The Fortinet FortiGate 400F-DC is designed for high-performance deployments with DC power infrastructure, combining AI-powered security and machine learning for comprehensive threat protection at scale. Powered by Fortinet's patented NP7 and CP9 SPUs, the FortiGate 400F-DC delivers 10 Gbps of NGFW throughput and 12 Gbps of IPS throughput with ultra-low latency to support performance-sensitive traffic.

With integrated Secure SD-WAN and universal ZTNA capabilities, this appliance helps reduce complexity and risk in hybrid IT networks. It features 8x 10GE SFP+ slots, including 4 dedicated ultra-low latency slots, plus 18x GE RJ45 and 8x GE SFP interfaces to support flexible connectivity and segmentation. Dual redundant DC power supplies help maintain continuous operation for mission-critical environments.

Technical Specifications Summary

• Enterprise Threat Performance: IPS throughput 12 Gbps, Threat Protection throughput 9 Gbps, SSL inspection throughput 8 Gbps (IPS, avg. HTTPS).
• Firewall Throughput: IPv4 and IPv6 up to 79.5 / 78.5 / 70 Gbps (1518 / 512 / 64 byte, UDP), 105 Mpps firewall throughput.
• Ultra-Low Latency: Firewall latency 4.19 μs / 2.5 μs (Latency based on Ultra Low Latency (ULL) ports).
• VPN Performance & Scale: IPsec VPN throughput 55 Gbps (512 byte), 2,000 gateway-to-gateway tunnels, 50,000 client-to-gateway tunnels.
• SSL-VPN Capacity: SSL-VPN throughput 3.6 Gbps, 5,000 concurrent SSL-VPN users (recommended max).
• Connectivity: 18x GE RJ45 (16 accelerated plus 2x GE RJ45 management ports), 8x GE SFP slots, 8x 10GE SFP+ slots (4 accelerated plus 4 accelerated ultra low latency).
• Power & Physical: Dual DC power supplies, 48-60VDC input, 12A maximum DC current, 154.8 W average / 189.2 W maximum power consumption, 1RU chassis.
• Environmental & Compliance: Operating temperature 32°F to 104°F (0°C to 40°C), storage temperature -31°F to 158°F (-35°C to 70°C), compliance FCC Part 15 Class A/RCM/VCCI/CE/UL/cUL/CB, certifications USGv6/IPv6.

• Next Generation Firewall (NGFW): AI-powered security services and real-time SSL inspection for visibility into users, devices, and applications.
• Secure SD-WAN: FortiGate WAN Edge with unified security and management framework for SD-WAN use cases.
• Universal ZTNA: Controls and verifies user access to applications with enforced policy prior to granting access.
• Segmentation: Dynamic segmentation to prevent lateral movement across the network with coordinated protection.

• Firewall Throughput: 79.5 / 78.5 / 70 Gbps (IPv4 & IPv6, 1518 / 512 / 64 byte, UDP)
• IPS Throughput: 12 Gbps
• Power Input: 48-60VDC
• Interfaces: 18x GE RJ45, 8x GE SFP, 8x 10GE SFP+
• VPN Throughput: 55 Gbps (IPsec, 512 byte)
• Concurrent Sessions: 7.8 Million
• Power Supply: Dual DC power supplies

Upgrade Your Network Security

Deploy the FortiGate 400F-DC for high-performance protection in your DC-powered environment.
