[shortdesc] Firewall, 4x 400GE QSFP-DD, 18x 50GE SFP56, 2x 1.92TB SSD, up to 589 Gbps, integrated ZTNA [/shortdesc]

[properties]

Product Name	FortiGate 3701F
SKU	FG-3701F
Form Factor	Rack Mount, 2 RU
Firewall Throughput	589 / 589 / 420 Gbps (IPv4 1518/512/64, IPv6 1518/512/86 byte, UDP)
Internal Storage	2x 1.92TB SSD
Interfaces Summary	4x 400GE QSFP-DD (also supports 200GE QSFP56/100GE QSFP28/40GE QSFP+), 18x 50GE SFP56 (also supports 25GE SFP28/10GE SFP+/1GE SFP), 4x ULL ports (25GE SFP28/10GE SFP+/GE SFP), 2x HA1/HA2 ports (50GE SFP56/25GE SFP28/10GE SFP+/1GE), 2x 10GE/GE RJ45 management
Dimensions	3.5 x 17.44 x 23.9 in (88.9 x 443 x 607.1 mm)
Weight	48.7 lbs (22.1 kg)
Power Input	100–240 VAC, 60/50 Hz

[/properties]

[specifications]

System Performance
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	589 / 589 / 420 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	589 / 589 / 420 Gbps
Firewall Latency (64 byte, UDP)	3.56 μs / 1.45 μs (ULL)
Firewall Throughput (Packet per Second)	630 Mpps
IPS Throughput	86 Gbps
NGFW Throughput	80 Gbps
Threat Protection Throughput	75 Gbps
IPsec VPN Throughput (512 byte)	160 Gbps
SSL-VPN Throughput	16 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	55 Gbps
Application Control Throughput (HTTP 64K)	190 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
System Capacity
Concurrent Sessions (TCP)	140 Million
New Sessions/Second (TCP)	930,000
Firewall Policies	200,000
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
Concurrent SSL-VPN Users (Recommended Max, Tunnel Mode)	30,000
SSL Inspection Concurrent Sessions (IPS, avg. HTTPS)	15 Million
Virtual Domains (Default/Maximum)	10 / 500
Maximum Number of FortiSwitches Supported	300
Maximum Number of FortiAPs (Total/Tunnel)	4096 / 2048
Maximum Number of FortiTokens	20,000
Interfaces and Modules
Hardware Accelerated 400GE QSFP-DD / 200GE QSFP56 / 100GE QSFP28 / 40GE QSFP+ Ports	4
Hardware Accelerated 50 GE SFP56 / 25 GE SFP28 / 10 GE SFP+ Ports	18
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP ULL Ports	4
Hardware Accelerated 50 GE SFP56 / 25 GE SFP28 / 10 GE SFP+ / 1 GE HA1/HA2 Ports	2
10GE / GE RJ45 Management Ports	2
USB Ports (Client/Server)	1 / 1
Console Port	1
Dimensions and Power
Power Consumption (Average / Maximum)	600 W / 1150 W
AC Current (Maximum)	12A@100V, 9A@240V
Heat Dissipation	3921 BTU/h
Redundant Power Supplies	Default dual AC PSU for 1+1 Redundancy (Hot Swappable)
Power Supply Efficiency Rating	80Plus Compliant
Operating Environment and Certifications
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	70.4 dBA
Forced Airflow	Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Included

2x SFP+ (SR 10 GE) Transceivers

Optional

Rack Mount Sliding Rails (SP-FG3040B-RAIL), AC Power Supply (FG-7040E-PS-AC), 1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), 40 GE QSFP+ Transceivers (SR, BiDi, LR, ER), 50 GE SFP56 Transceivers (SR), 100 GE QSFP28 Transceivers (SR, LR, CWDM4, BiDi, DR, ER), 200 GE QSFP56 Transceivers (FR4, SR4), 400 GE QSFP-DD Transceivers (LR4, FR4, DR4+, DR4, SR8), Direct Attach Cables (SFP28, SFP56, QSFP28, QSFP56, QSFP-DD)

[/accesories]

The FortiGate 3701F Series is designed for organizations requiring a hyperscale security solution that integrates seamlessly into hybrid IT environments. By consolidating networking and security into a single platform, this firewall reduces complexity while offering deep visibility into applications, users, and threats. It supports a Hybrid Mesh Firewall architecture, weaving security deep into the data center and across distributed networks to protect any edge at any scale. The device is powered by Fortinet’s proprietary SPU technology, ensuring that critical security functions such as SSL inspection and threat protection do not become performance bottlenecks.

At the core of the FortiGate 3701F are the Network Processor 7 (NP7) and Content Processor 9 (CP9). The NP7 works in line with FortiOS to deliver hyperscale firewall capabilities, ultra-low latency, and accelerated session setup for demanding, high-throughput environments. The CP9 acts as a co-processor to offload resource-intensive tasks like SSL decryption and pattern matching. This model distinguishes itself with 2x 1.92TB of internal SSD storage, providing ample capacity for local logging and data retention, which is critical for compliance and in-depth forensic analysis.

High-Performance Protection for the Hybrid Enterprise

The FortiGate 3701F delivers converged networking and security with industry-leading throughput and integrated ZTNA enforcement to secure data centers and hybrid edges.

• Hyperscale Performance: Delivers up to 589 / 589 / 420 Gbps of firewall throughput and 140 million concurrent sessions, ensuring the network can handle massive traffic surges without latency.
• Integrated ZTNA: Integrated Zero Trust Network Access (ZTNA) enforcement controls, verifies, and facilitates user access to applications for consistent security across distributed networks.
• Onboard Storage: Includes dual 1.92TB SSDs for reliable local storage, supporting extensive logging and reporting requirements directly on the appliance.
• Advanced Threat Protection: AI/ML-powered security services help protect against ransomware, malware, and zero-day attacks with threat intelligence updates.
• Versatile Connectivity: Equipped with 400 GE QSFP-DD ports (also supporting 200 GE QSFP56, 100 GE QSFP28, and 40 GE QSFP+) to support high-bandwidth architectures and scalability.
• Dynamic Segmentation: Adapts to network topology to help prevent lateral movement of threats using VXLAN segmentation and Layer 4 firewall rules.
• Energy Efficient: Purpose-built SPU processors help improve power efficiency and reduce footprint while maintaining high performance.

• Data Center Security: Protects high-speed data center edges with ultra-low latency and hyperscale firewall capabilities.
• Hybrid Cloud Segmentation: Secures multi-cloud environments by bridging physical and virtual domains with consistent security policies.
• Latency-Sensitive Workloads: Ultra-low latency ports (ULL) help reduce network delays for environments where microsecond-level latency matters.
• Large Enterprise Gateways: Manages high volumes of encrypted traffic with SSL inspection and threat protection performance.
• Remote Workforce Security: Facilitates secure access for distributed users through IPsec VPN and integrated ZTNA enforcement.

• Firewall Throughput: 589 / 589 / 420 Gbps (IPv4 1518/512/64 byte UDP; IPv6 1518/512/86 byte UDP)
• Security Performance: IPS 86 Gbps; NGFW 80 Gbps; Threat Protection 75 Gbps
• VPN Performance: IPsec VPN 160 Gbps (512 byte); SSL-VPN 16 Gbps; 30,000 recommended concurrent SSL-VPN users (tunnel mode)
• SSL Inspection: 55 Gbps (IPS, avg. HTTPS); SSL inspection concurrent sessions 15 Million
• Network Interfaces: 4x 400GE QSFP-DD (supports 200GE/100GE/40GE), 18x 50GE SFP56, 4x ULL ports, 2x HA1/HA2 ports, 2x 10GE/GE RJ45 management
• Physical: Rack mount 2 RU; 3.5 x 17.44 x 23.9 in (88.9 x 443 x 607.1 mm); 48.7 lbs (22.1 kg)
• Power: 100–240 VAC; 600 W / 1150 W (avg/max); 3921 BTU/h heat dissipation
• Environment & Compliance: 0°C to 40°C operating; 5% to 90% non-condensing humidity; FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; USGv6/IPv6
