[shortdesc]FG-3700F-BDL-809-12 NGFW, 2RU, 400GE QSFP-DD and 50GE SFP56, NP7/CP9 SPUs, 80 Gbps NGFW, FortiCare Premium + FortiGuard Enterprise Protection, 1 Year.[/shortdesc]

[properties]

Product Series	FortiGate 3700F Series
Model / SKU	FG-3700F-BDL-809-12
Bundle / Subscription	Hardware + FortiCare Premium + FortiGuard Enterprise Protection (1 Year)
Form Factor	Rack Mount, 2 RU
Firewall Throughput	589 Gbps (1518/512 byte UDP)
NGFW Throughput	80 Gbps
Threat Protection Throughput	75 Gbps
Network Interfaces	4x 400 GE QSFP-DD slots, 4x ULL SFP28 slots, 20x 50 GE SFP56 slots (18x ports + 2x HA ports), 2x 10GE RJ45 Management Ports
Power Supplies	Dual AC (Hot Swappable)
Dimensions	88.9 x 443 x 607.1 mm (3.5 x 17.44 x 23.9 inches)
Weight	21.4 kg (47.1 lbs)

[/properties]

[specifications]

System Performance
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	589 / 589 / 420 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	589 / 589 / 420 Gbps
Firewall Latency (64 byte, UDP)	3.56 μs / 1.45 μs (ULL)
Firewall Throughput (Packet per Second)	630 Mpps
IPsec VPN Throughput (512 byte)	160 Gbps
SSL-VPN Throughput	16 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	55 Gbps
Application Control Throughput (HTTP 64K)	190 Gbps
Hardware & Interfaces
400GE/200GE/100GE/40GE Ports	4x QSFP-DD Slots
50GE/25GE/10GE Ports	18x SFP56 Slots
25GE/10GE/GE ULL Ports	4x SFP28 Slots
HA Ports (50GE/25GE/10GE/1GE)	2x SFP56 Slots
Management Ports	2x 10 GE / GE RJ45
USB Ports	1 / 1 (Client / Server)
Console Port	1x Console
Environment & Power
Power Supply	100–240 VAC, 60/50 Hz
Power Consumption (Average / Maximum)	590 W / 1140 W

[/specifications]

[accesories]

Included Transceivers	2x SFP+ (SR 10 GE)
Optional Accessories	Rack Mount Sliding Rails (SP-FG3040B-RAIL), AC Power Supply (FG-7040E-PS-AC), Various Transceivers (1GE to 400GE), DAC and AOC Cables

[/accesories]

The FortiGate 3700F Series delivers hyperscale firewall capabilities for enterprise data centers and hybrid IT environments in a compact 2U form factor. Powered by Fortinet’s NP7 and CP9 SPUs, it supports diverse high-speed connectivity including 400 GE QSFP-DD slots.

It enables security-driven networks as the foundation of a Hybrid Mesh Firewall architecture across data center and hybrid IT. This bundle includes FortiCare Premium and FortiGuard Enterprise Protection for 1 Year.

Hyperscale Security with 400GE Connectivity for the Modern Data Center

• NP7 and CP9 SPUs for hardware-accelerated security processing.
• 400 GE QSFP-DD slots for high-speed data center connectivity.
• 50 GE SFP56, ULL SFP28, and 10GE RJ45 management ports.
• 589 / 589 / 420 Gbps IPv4 firewall throughput (1518/512/64 UDP).
• 160 Gbps IPsec VPN throughput and 16 Gbps SSL-VPN.
• Dual AC hot-swappable power supplies support 1+1 redundancy.

Upgrade Your Network Security

Secure your hyperscale environment with Fortinet FG-3700F-BDL-809-12 today.
