[shortdesc] Firewall, 2RU rack mount, 6x 100GE QSFP28, 32x 25GE SFP28, up to 595 Gbps firewall throughput, dual AC PSU [/shortdesc]

[properties]

Model / SKU	FG-3500F
Form Factor	Rack Mount, 2 RU
Firewall Throughput	595 / 590 / 420 Gbps (IPv4, 1518/512/64 byte, UDP)
Interfaces	6x 100 GE QSFP28 / 40 GE QSFP+, 32x 25 GE SFP28 / 10 GE SFP+ / GE SFP, 2x 10 GE / GE RJ45 Management
Power Input	100-240V AC, 50/60 Hz
Dimensions (H x W x L)	3.5 x 17.4 x 21.9 inches (89 x 443 x 556 mm)
Weight	43.8 lbs (19.9 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)

[/properties]

[specifications]

System Performance
IPS Throughput	72 Gbps
NGFW Throughput	65 Gbps
Threat Protection Throughput	63 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	595 / 590 / 420 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	595 / 590 / 420 Gbps
Firewall Latency	2.98 μs
Firewall Throughput (Packet per Second)	630 Mpps
IPsec VPN Throughput (512 byte)	165 Gbps
SSL-VPN Throughput	16 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	63 Gbps
Application Control Throughput (HTTP 64K)	135 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
System Capacity
Concurrent Sessions (TCP)	140 Million / 348 Million*
New Sessions/Second (TCP)	1 Million / 5 Million*
Firewall Policies	200,000
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	30,000
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	15 Million
SSL Inspection CPS (IPS, avg. HTTPS)	60,000
Virtual Domains (Default / Maximum)	10 / 500
Maximum Number of FortiSwitches Supported	300
Maximum Number of FortiAPs (Total / Tunnel)	4096 / 2048
Maximum Number of FortiTokens	20,000
Interfaces and Modules
100 GE QSFP28 / 40 GE QSFP+ Slots	6 (Hardware Accelerated)
25 GE SFP28 / 10 GE SFP+ / GE SFP Slots	32 (Hardware Accelerated)
10 GE / GE RJ45 Management Ports	2
USB Ports (Client / Server)	1 / 1
Console Port	1
Power and Environment
Power Supply	Redundant Power Supplies (Hot Swappable), Default dual AC PSU
AC Current (Maximum)	12A@120V, 9A@240V
Power Consumption (Average / Maximum)	760 W / 1174 W
Heat Dissipation	4006 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	20% to 90% non-condensing
Noise Level	53.5 dBA
Operating Altitude	Up to 10,000 ft (3048 m)
Forced Airflow	Front to Back
Dimensions and Weight
Certifications and Compliance
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Included Transceivers	2x SFP+ (SR 10 GE)
Optional Accessories	Rack Mount Sliding Rails (SP-FG3040B-RAIL), AC Power Supply (FG-7040E-PS-AC), Transceiver Modules (FN-TRAN / FG-TRAN series), Direct Attach Cables (FN-CABLE series)

[/accesories]

The FortiGate 3500F Series enables organizations to build security-driven networks, forming the foundation of a robust Hybrid Mesh Firewall architecture. This high-performance next-generation firewall (NGFW) weaves security deep into datacenters and across hybrid IT environments, protecting any edge at any scale. Powered by Fortinet's patented SPU NP7 and CP9 processors, the FG-3500F delivers unparalleled performance with hardware acceleration for critical network functions, ensuring that security never becomes a bottleneck.

Designed for hyperscale environments, the FortiGate 3500F consolidates networking and security to deliver ultra-scalable secure networks. It features the industry's first integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution, automatically controlling and verifying user access to applications. With rich AI/ML-based FortiGuard Services and an integrated security fabric platform, this appliance delivers coordinated, automated, end-to-end threat protection across all use cases, from the data center to the hybrid cloud.

High Performance with Flexibility and Hyperscale Security

• Unparalleled Performance: Delivers up to 595 / 590 / 420 Gbps IPv4 firewall throughput (1518/512/64 byte UDP) and 72 Gbps IPS throughput, powered by SPU NP7 and CP9 processors to accelerate security functions and reduce latency.
• Hyperscale Scalability: Supports 140 million / 348 million concurrent TCP sessions and 1 million / 5 million new sessions per second (requires Hyperscale Firewall License for boosted values) for high-volume traffic environments.
• Integrated ZTNA: Integrated Zero Trust Network Access enforcement to control and verify user access to applications, reducing lateral threats and supporting a seamless user experience.
• High-Speed Connectivity: Equipped with 6x 100 GE QSFP28 / 40 GE QSFP+ slots and 32x 25 GE SFP28 / 10 GE SFP+ / GE SFP slots, plus 2x 10 GE / GE RJ45 management ports for flexible, high-density deployments.
• AI-Powered Security: AI/ML-powered security services help protect against ransomware, malware, zero-day threats, and sophisticated attacks, with coordinated protection across use cases.
• Energy Efficient: Energy-efficient SPU/ASIC design supports high inspection performance while reducing power consumption and improving total cost of ownership.

• Next Generation Firewall (NGFW): Secures enterprise networks with real-time SSL inspection (including TLS 1.3) and full visibility into users, devices, and applications.
• Data Center Segmentation: Adapts to any network topology with dynamic segmentation and ultra-scalable, low-latency VXLAN segmentation to bridge physical and virtual domains.
• Hyperscale Architectures: Consolidates networking and security with purpose-built SPUs to support massive connection counts and protect business-critical applications.
• Mobile Security (4G/5G): Provides SPU-accelerated CGNAT and IPv6 migration options, securing radio access networks and user plane traffic with high performance.

• Firewall Throughput: IPv4 (1518/512/64 byte UDP) 595 / 590 / 420 Gbps; IPv6 (1518/512/86 byte UDP) 595 / 590 / 420 Gbps
• IPS / NGFW / Threat Protection: IPS 72 Gbps; NGFW 65 Gbps; Threat Protection 63 Gbps
• Network Interfaces: 6x 100 GE QSFP28 / 40 GE QSFP+; 32x 25 GE SFP28 / 10 GE SFP+ / GE SFP; 2x 10 GE / GE RJ45 management
• VPN Performance: IPsec VPN (512 byte) 165 Gbps; SSL-VPN 16 Gbps
• SSL Inspection: 63 Gbps throughput (IPS, avg. HTTPS); 60,000 CPS; 15 million concurrent sessions
• Session Capacity: 140 million / 348 million concurrent TCP sessions; 1 million / 5 million new sessions/sec (*requires Hyperscale Firewall License)
• Power and Form Factor: 2 RU rack mount; redundant hot-swappable dual AC PSU; power consumption 760 W average / 1174 W maximum

Upgrade Your Network Security

Secure your hyperscale environment with the FortiGate 3500F today.
