Fortinet FG-3201F-BDL-950-60 Next-Generation Firewall
[shortdesc]FG-3201F-BDL-950-60 Next-Generation Firewall, four 400GE QSFP-DD, dual 960GB SSDs, NP7/CP9 SPUs, 47 Gbps NGFW, FortiCare Premium + FortiGuard Unified Threat Protection (UTP), 5 Year.[/shortdesc]
[properties]
| Model | FG-3201F-BDL-950-60 |
| Bundle / Subscription | Hardware + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (5 Year) |
| Form Factor | Rack Mount, 2RU |
| Firewall Throughput (IPv4) | 387 / 385 / 178.5 Gbps (1518 / 512 / 64 byte UDP) |
| Threat Protection Throughput | 45 Gbps |
| Network Interfaces | 4x 400GE QSFP-DD, 10x 50GE SFP56 (data), 2x 50GE SFP56 (HA1/HA2), 4x 25GE SFP28 ULL, 2x 10GE RJ45 Mgmt |
| Internal Storage | 2x 960GB SSD |
| Dimensions (H x W x L) | 3.5 x 17.44 x 23.9 inches (88.9 x 443 x 607.1 mm) |
| Weight | 45.5 lbs (20.7 kg) |
| Power Input | 100ā240VAC, 60/50 Hz |
[/properties]
[specifications]
| System Performance - Enterprise Traffic Mix | |
| IPS Throughput | 63 Gbps |
| NGFW Throughput | 47 Gbps |
| System Performance and Capacity | |
| IPv6 Firewall Throughput (1518/512/86 byte, UDP) | 387 / 385 / 178.5 Gbps |
| Firewall Latency (64 byte, UDP) | 3.42 Ī¼s / 1.45 Ī¼s* |
| Concurrent Sessions (TCP) | 70 Million |
| New Sessions/Second (TCP) | 800,000 |
| IPsec VPN Throughput (512 byte) | 105 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 40,000 |
| Client-to-Gateway IPsec VPN Tunnels | 200,000 |
| SSL-VPN Throughput | 11 Gbps |
| Concurrent SSL-VPN Users (Tunnel Mode) | 30,000 |
| Hardware Specifications | |
| USB 3.0 Port | 1 |
| Console RJ45 Port | 1 |
| Dimensions and Power | |
| Power Consumption (Average/Maximum) | 527 W / 870 W |
| Current (Maximum) | 12A@100V, 9A@240V |
| Heat Dissipation | 2971 BTU/h |
| Redundant Power Supplies | Yes (Default dual AC PSU for 1+1 Redundancy) |
[/specifications]
[accesories]
| Optional Accessories | Rack Mount Sliding Rails (SP-FG3040B-RAIL), Spare AC Power Supply (SP-FG3800D-PS), various SFP/QSFP Transceiver Modules and Cables |
[/accesories]
The FortiGate 3201F supports security-driven networks for hyperscale data centers and hybrid IT environments. This bundle SKU includes Hardware + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (5 Year).
Purpose-built SPU NP7 and CP9 processors and onboard SSD storage support high-speed inspection plus local logging. Four 400GE QSFP-DD slots help maintain performance in demanding deployments.
Secure Networking with 400GE Hyperscale Connectivity and Onboard Storage
- SPU Acceleration: NP7/CP9 SPUs accelerate inspection for high-speed traffic.
- Hyperscale Ports: Four 400GE QSFP-DD slots simplify core connectivity.
- Onboard Storage: Dual 960GB SSDs support local logging and reporting.
- VPN Capacity: 105 Gbps IPsec throughput supports large site VPNs.
- Session Scale: Supports up to 70 Million concurrent TCP sessions.
- Resilient Power: Dual AC PSUs enable 1+1 redundancy.
Upgrade Your Network Security
Deploy FG-3201F-BDL-950-60 with FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (5 Year).
