[shortdesc]FG-3201F-BDL-809-12 Next-Generation Firewall, four 400GE QSFP-DD, dual 960GB SSDs, NP7/CP9 SPUs, 47 Gbps NGFW, FortiCare Premium + FortiGuard Enterprise Protection, 1 Year.[/shortdesc]

[properties]

Model	FG-3201F-BDL-809-12
Bundle / Subscription	Hardware + FortiCare Premium + FortiGuard Enterprise Protection (1 Year)
Form Factor	Rack Mount, 2RU
Firewall Throughput (IPv4)	387 / 385 / 178.5 Gbps (1518 / 512 / 64 byte UDP)
Threat Protection Throughput	45 Gbps
Network Interfaces	4x 400GE QSFP-DD, 10x 50GE SFP56 (data), 2x 50GE SFP56 (HA1/HA2), 4x 25GE SFP28 ULL, 2x 10GE RJ45 Mgmt
Internal Storage	2x 960GB SSD
Dimensions (H x W x L)	3.5 x 17.44 x 23.9 inches (88.9 x 443 x 607.1 mm)
Weight	45.5 lbs (20.7 kg)
Power Input	100–240VAC, 60/50 Hz

[/properties]

[specifications]

Performance / Throughput
IPS Throughput	63 Gbps
NGFW Throughput	47 Gbps
Threat Protection Throughput	45 Gbps
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	387/385/178.5 Gbps
Firewall Latency (64 byte, UDP)	3.42 μs / 1.45 μs*
Firewall Throughput (Packet per Second)	267.75 Mpps
Concurrent Sessions (TCP)	70 Million
New Sessions/Second (TCP)	800,000
Interfaces / Ports
USB 3.0 Port	1
Console RJ45 Port	1
VPN / NGFW Relevant
IPsec VPN Throughput (512 byte)	105 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
SSL-VPN Throughput	11 Gbps
Concurrent SSL-VPN Users (Tunnel Mode)	30,000
SSL Inspection Throughput (IPS, avg HTTPS)	29 Gbps
Dimensions / Weight / Form Factor
Height x Width x Length (inches)	3.5 x 17.44 x 23.9
Height x Width x Length (mm)	88.9 x 443 x 607.1
Weight	45.5 lbs (20.7 kg)
Form Factor (supports EIA/non-EIA standards)	Rack Mount, 2RU
Power / Consumption
AC Power Supply	100–240VAC, 60/50 Hz
Power Consumption (Average/Maximum)	527 W / 870 W
Current (Maximum)	12A@100V, 9A@240V
Heat Dissipation	2971 BTU/h

[/specifications]

[accesories]

Optional Accessories

Rack Mount Sliding Rails (SP-FG3040B-RAIL), Spare AC Power Supply (SP-FG3800D-PS), various SFP/QSFP Transceiver Modules and Cables

[/accesories]

The FortiGate 3201F enables organizations to build security-driven networks with the foundation of a Hybrid Mesh Firewall architecture across data center and hybrid IT environments. Powered by FortiOS, it consolidates networking and security into a single platform for consistent visibility and control.

Purpose-built SPU acceleration supports high-speed inspection and segmentation without adding operational complexity. Integrated onboard storage strengthens local logging and reporting workflows for large-scale deployments.

Secure Networking with 400GE Hyperscale Connectivity and Onboard Storage

• AI-Powered Security: FortiGuard AI-Powered Security Services for real-time threat protection.
• Ultra-Low Latency: Dedicated ULL ports support firewall latency as low as 1.45 μs*.
• Integrated ZTNA: Integrated ZTNA enforcement controls and verifies user access.
• Massive Scale: High session capacity supports 70 million concurrent TCP sessions.
• SSL Visibility: Hardware acceleration boosts SSL inspection and application visibility.
• Resilient Hardware: 2RU design with dual AC PSUs for 1+1 redundancy.

Upgrade Your Network Security

Deploy FG-3201F-BDL-809-12 with FortiCare Premium + FortiGuard Enterprise Protection (1 Year).
