[shortdesc] Firewall, 2RU rack mount, 4x 400 GE QSFP-DD, IPS 63 Gbps, NGFW 47 Gbps, threat protection 45 Gbps [/shortdesc]

[properties]

Product Series	FortiGate 3200F Series
Model / SKU	FG-3200F
Form Factor	Rack Mount, 2RU
Firewall Throughput (IPv4)	387 Gbps (1518 byte, UDP)
NGFW Throughput	47 Gbps
Threat Protection Throughput	45 Gbps
Interfaces Summary	4x 400 GE QSFP-DD, 10x 50 GE SFP56 + 2x 50 GE SFP56 HA, 4x 25 GE SFP28 ULL, 2x 10 GE/GE RJ45 Mgmt
Power Supplies	Dual AC Power Supplies (1+1 Redundancy)
Dimensions (H x W x L)	3.5 x 17.44 x 23.9 inches (88.9 x 443 x 607.1 mm)
Weight	43.9 lbs (20 kg)

[/properties]

[specifications]

System Performance - Enterprise Traffic Mix
IPS Throughput	63 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	387 / 385 / 178.5 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	387 / 385 / 178.5 Gbps
Firewall Latency (64 byte, UDP)	3.42 μs / 1.45 μs (ULL)
Firewall Throughput (Packet per Second)	267.75 Mpps
Concurrent Sessions (TCP)	70 Million
New Sessions/Second (TCP)	800,000
Firewall Policies	200,000
IPsec VPN Throughput (512 byte)	105 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
SSL-VPN Throughput	11 Gbps
Concurrent SSL-VPN Users (Recommended Max)	30,000
SSL Inspection Throughput (IPS, avg HTTPS)	29 Gbps
Application Control Throughput (HTTP 64K)	109 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
Virtual Domains (Default/Maximum)	10 / 500
High Availability Configurations	Active-Active, Active-Passive, Clustering
Interfaces and Modules
Hardware Accelerated 400 GE QSFP-DD / 200 GE QSFP56 / 100 GE QSFP28 / 40 GE QSFP+ Slots	4
Hardware Accelerated 50 GE SFP56 / 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots	10
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP ULL Slots	4
Hardware Accelerated 50 GE SFP56 / 25 GE SFP28 / 10 GE SFP+ HA1/HA2 Slots	2
10 GE / GE RJ45 Management Ports	2
USB 3.0 Port	1
Console RJ45 Port	1
Onboard Storage	NA
Dimensions and Power
AC Power Supply	100-240VAC, 60/50 Hz
Power Consumption (Average/Maximum)	520 W / 865 W
Current (Maximum)	12A@100V, 9A@240V
Heat Dissipation	2955 BTU/h
Redundant Power Supplies	Yes (Default dual AC PSU for 1+1 Redundancy)
Operating Environment and Certifications
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	71 dBA
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Included	2x AC power supplies
Optional Accessories	Rack Mount Sliding Rails (SP-FG3040B-RAIL), Spare Power Supply (SP-FG3800D-PS), Various Transceiver Modules (1 GE to 400 GE), Direct Attach Cables (25 GE to 400 GE)

[/accesories]

The Fortinet FortiGate 3200F Series provides high-performance, hyperscale security for data centers and hybrid IT environments. By consolidating security functions into a single platform, the FG-3200F simplifies management and reduces costs while delivering deep visibility into users, devices, and applications. It protects against sophisticated cyberattacks, ransomware, and zero-day threats through AI-powered FortiGuard Services and real-time SSL inspection, including TLS 1.3.

Engineered with Fortinet's patented SPU NP7 and CP9 processors, the FortiGate 3200F ensures that security does not become a network bottleneck. It offers massive throughput capacities, including 387 Gbps for IPv4 firewalls and 63 Gbps for IPS, alongside ultra-low latency. With integrated support for 400 GE connectivity via QSFP-DD slots, this appliance is designed to handle the demanding bandwidth requirements of modern core networks and security segmentation.

Hyperscale Security with 400 GE Connectivity

Key Benefits:

• Unparalleled Performance: Delivers up to 387 Gbps firewall throughput and 47 Gbps NGFW throughput powered by custom SPU NP7 and CP9 processors.
• High-Speed Connectivity: Features multiple 400 GE QSFP-DD and 100/200 GE slots to simplify network designs and eliminate the need for additional bridging devices.
• Advanced Threat Protection: Utilizes AI/ML-powered FortiGuard Services to block unknown malware, ransomware, and zero-day attacks in real time.
• Ultra-Low Latency: Specific ULL slots and hardware acceleration provide minimal latency (down to 1.45 μs) for sensitive applications and elephant flows.
• Seamless Segmentation: Dynamic VXLAN segmentation adapts to any network topology, bridging physical and virtual domains with Layer 4 firewall rules.
• Operational Efficiency: Consolidates networking and security into a single Hybrid Mesh Firewall architecture, reducing footprint and power consumption.

Ideal Use Cases:

• Enterprise Data Centers: securing core networks with high-throughput segmentation and threat protection.
• Hybrid IT Environments: Weaving security deep into the datacenter and across distributed edges.
• Mobile Security (4G/5G): Providing SPU-accelerated CGNAT and protection for Gi/sGi and N6 interfaces.
• High-Frequency Trading: Leveraging ultra-low latency ports for delay-sensitive financial transactions.
• Secure SD-WAN: Transforming WAN edges with unified security and management at scale.

Technical Specifications Summary:

• IPS Throughput (Enterprise Mix): 63 Gbps
• NGFW Throughput (Enterprise Mix): 47 Gbps
• Threat Protection Throughput (Enterprise Mix): 45 Gbps
• IPv4 Firewall Throughput (1518/512/64 byte, UDP): 387 / 385 / 178.5 Gbps
• IPsec VPN Throughput (512 byte): 105 Gbps
• SSL Inspection Throughput (IPS, avg HTTPS): 29 Gbps
• Firewall Latency (64 byte, UDP): 3.42 μs / 1.45 μs (ULL)
• Concurrent Sessions (TCP): 70 Million
• Interfaces: 4x 400 GE QSFP-DD (supports 400/200/100/40 GE), 10x 50 GE SFP56, 2x 50 GE SFP56 HA, 4x 25 GE SFP28 ULL, 2x 10 GE/GE RJ45 Mgmt
• Power (Avg/Max): 520 W / 865 W (100–240VAC, 60/50 Hz)
• Dimensions (H x W x L): 3.5 x 17.44 x 23.9 inches (88.9 x 443 x 607.1 mm)
• Weight: 43.9 lbs (20 kg)

Upgrade Your Network Security

Equip your data center with the FortiGate 3200F for industry-leading protection and 400 GE speed.
