[shortdesc] FortiGate 31G Firewall, desktop, 4x GE RJ45, SD-WAN, 570 Mbps NGFW, 30 GB SSD, including 5 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Model / SKU	FortiGate 31G / FG-31G-BDL-809-60
Form Factor	Desktop
NGFW Throughput	570 Mbps
Internal Storage	30 GB SSD
Interfaces	4x GE RJ45 (1x WAN, 2x Internal, 1x FortiLink)
Dimensions	1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm)
Weight	1.3 lbs (0.6 kg)
Operating Temp	32°F to 104°F (0°C to 40°C)
Certifications	USGv6/IPv6; Compliance: FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA

[/properties]

[specifications]

System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP)	4 / 4 / 3.9 Gbps
IPS Throughput	800 Mbps
Threat Protection Throughput	500 Mbps
Firewall Latency (64 byte UDP)	2.87 μs
IPsec VPN Throughput (512 byte)	3.5 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	400 Mbps
Application Control Throughput (HTTP 64K)	830 Mbps
System Capacity
Concurrent Sessions (TCP)	600,000
New Sessions/Second (TCP)	30,000
Firewall Policies	2,000
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	250
Hardware & Networking
Hardware Accelerated GE WAN Port	1
Hardware Accelerated GE RJ45 Ports	2
Hardware Accelerated GE RJ45 FortiLink Port	1
Console Port (RJ45)	1
Trusted Platform Module (TPM)	Yes
Power & Environment
Power Rating	12VDC, 2A (External DC Adapter)
Power Consumption (Average / Maximum)	8.1 W / 9.3 W
Heat Dissipation	31.713 BTU/hr
Operating Humidity	20% to 90% non-condensing
Operating Altitude	10,000 ft (3048 m)

[/specifications]

[accesories]

Optional	Wall Mount Kit (SP-FG60F-MOUNT-20)
Optional	AC Power Adaptor (SP-FG-30G-PA-10(-XX))

[/accesories]

The FortiGate 30G series provides a unified security and networking framework designed to transform WAN architecture at any scale. Powered by Fortinet's patented SD-WAN-based ASIC and the converged FortiOS operating system, the FortiGate 31G delivers high performance and efficiency while maintaining a compact, desktop-ready form factor. This firewall integrates SD-WAN and advanced security functions into a single platform, supporting deployment within a Hybrid Mesh Firewall architecture.

With 30 GB of onboard SSD storage and the FG-31G-BDL-809-60 entitlement, this bundle is engineered for long-term operational stability. It supports real-time SSL inspection and FortiGuard AI-Powered Security Services capabilities, helping maintain visibility into users, devices, and applications while reducing the risk of threats becoming a network bottleneck.

Secure SD-WAN and NGFW Convergence with 5-Year Protection

• Unmatched ASIC Performance: Built on a patented SD-WAN-based ASIC to accelerate the convergence of networking and security functions.
• 5-Year Bundle Entitlement: FG-31G-BDL-809-60 includes 5 Year FortiCare Premium and FortiGuard Enterprise Protection.
• Dedicated 30 GB SSD: Onboard storage capacity for the FortiGate 31G model.
• Hardware-Based Trust: Features a Trusted Platform Module (TPM) to help secure cryptographic operations.
• SSL Inspection Performance: Up to 400 Mbps SSL inspection throughput (IPS, avg. HTTPS).
• Unified Management: Supports centralized management options including FortiManager and FortiGate Cloud.
• Efficient Power Profile: 12VDC, 2A external adapter, 8.1 W average / 9.3 W maximum power consumption.

Ideal Use Cases

• Distributed Enterprise Branches: Enables secure branch connectivity with integrated SD-WAN and unified protection for LAN/WAN.
• Secure Remote and Hybrid Work: Enhances connectivity with accelerated IPsec VPN performance for direct internet access.
• Retail and Point of Sale: Helps secure applications and transactions with integrated inspection capabilities and security policy control.
• Secure Branch Expansion: Supports extending security to WAN, LAN, and WLAN environments when integrated with compatible Fortinet solutions.

Technical Specifications Summary

• IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
• IPS Throughput (Enterprise Mix): 800 Mbps
• NGFW Throughput: 570 Mbps
• Threat Protection Throughput: 500 Mbps
• IPsec VPN Throughput (512 byte): 3.5 Gbps
• SSL Inspection Throughput (IPS, avg. HTTPS): 400 Mbps
• Concurrent Sessions / New Sessions: 600,000 TCP sessions, 30,000 new sessions/second
• Interfaces: 1x GE RJ45 WAN, 2x GE RJ45, 1x GE RJ45 FortiLink, 1x RJ45 console
• Storage / TPM: 30 GB SSD, TPM: Yes
• Power / Environment: 8.1 W avg / 9.3 W max, 0°C to 40°C operating temperature, 20% to 90% non-condensing humidity
• Compliance / Certifications: FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; USGv6/IPv6

Upgrade Your Network Security

Deploy the FortiGate 31G today for high-performance firewalling and five years of FortiCare Premium and FortiGuard Enterprise Protection entitlement.
