Fortinet FortiGate 31G Next-Generation Firewall (Hardware plus 1Yr FortiCare Premium and FortiGuard Enterprise Protection)
[shortdesc] FortiGate 31G Firewall, desktop, 4x GE RJ45, SD-WAN, up to 4/4/3.9 Gbps IPv4, including 1 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]
[properties]
| Model / SKU | FortiGate 31G (FG-31G-BDL-809-12) |
| Form Factor | Desktop |
| Firewall Throughput | 4 / 4 / 3.9 Gbps (IPv4, 1518/512/64 byte UDP) |
| NGFW Throughput | 570 Mbps |
| Internal Storage | 30 GB SSD |
| Network Interfaces | 4x GE RJ45 (1x WAN, 3x Internal; 1x FortiLink default) |
| Dimensions | 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm) |
| Weight | 1.3 lbs (0.6 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) | |
|---|---|
| IPS Throughput | 800 Mbps |
| Threat Protection Throughput | 500 Mbps |
| System Performance | |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 4 / 4 / 3.9 Gbps |
| IPsec VPN Throughput (512 byte) | 3.5 Gbps |
| Firewall Latency (64 byte UDP packets) | 2.87 μs |
| Firewall Throughput (Packets Per Second) | 5.85 Mpps |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 400 Mbps |
| Application Control Throughput (HTTP 64K) | 830 Mbps |
| System Capacity | |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 2,000 |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| Maximum FortiSwitches Supported | 8 |
| Maximum FortiAPs (Total / Tunnel) | 16 / 8 |
| Hardware & Networking | |
| GE RJ45 WAN Port | 1 |
| GE RJ45 Internal Ports | 2 |
| GE RJ45 FortiLink Port | 1 |
| Console Port (RJ45) | 1 |
| Trusted Platform Module (TPM) | Included |
| Environmental & Power | |
| Power Consumption (Average / Maximum) | 8.1 W / 9.3 W |
| Heat Dissipation | 31.713 BTU/hr |
| Operating Altitude | 10,000 ft (3,048 m) |
| Humidity | 20% to 90% non-condensing |
| Certifications | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; USGv6/IPv6 |
[/specifications]
[accesories]
| Included | External DC Power Adapter (100-240V AC, 50/60 Hz) |
| Optional | Wall Mount Kit (Pack of 20): SP-FG60F-MOUNT-20 |
| Optional | AC Power Adaptor (Pack of 10): SP-FG-30G-PA-10(-XX) |
[/accesories]
The FortiGate 31G is engineered to transform WAN architecture at distributed enterprise sites by converging networking and security into a single, high-performance appliance. Powered by Fortinet's patented SD-WAN-based ASIC and the converged FortiOS operating system, this firewall delivers unmatched performance over traditional CPUs with lower power consumption. The 31G model includes 30GB of onboard storage.
This bundle includes a 1-year contract for FortiCare Premium and FortiGuard Enterprise Protection services. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time. Its application-specific design accelerates SSL inspection and IPsec VPN performance to help maintain a robust user experience at branch locations.
Advanced Secure SD-WAN and AI-Powered Threat Protection
- Patented ASIC Acceleration: Built on a patented SD-WAN-based ASIC to accelerate networking and security functions with high efficiency.
- Unified Security Fabric: Works seamlessly with FortiGuard AI-Powered Security Services for coordinated, automated threat protection.
- Enterprise Protection Bundle: Includes a 1-year contract for FortiCare Premium and FortiGuard Enterprise Protection (FG-31G-BDL-809-12).
- Internal Storage: Includes 30GB SSD onboard storage.
- Operational Efficiency: Simplifies operations with FortiOS, centralized visibility, and automated workflows for networking and security.
- Hardware-Based Security: Hardens the platform with a Trusted Platform Module (TPM) for cryptographic key generation, storage, and authentication.
- Reliable Connectivity: Supports High Availability (Active-Passive and Active-Active) configurations to help minimize downtime.
Ideal Use Cases
- Perimeter Protection: Inspect and control incoming and outgoing traffic based on defined security policies with integrated security services.
- Secure SD-WAN: Integrates SD-WAN with security and unified management from a single FortiOS operating system.
- Secure Branch: Extends protection to WAN, LAN, and WLAN when integrated with FortiSwitch and FortiAP for unified connectivity.
- Distributed Sites and Branch Offices: Designed for distributed enterprise sites with a compact desktop form factor and integrated networking and security.
Technical Specifications Summary
- IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
- IPS Throughput (Enterprise Traffic Mix): 800 Mbps
- NGFW Throughput (Enterprise Traffic Mix): 570 Mbps
- Threat Protection Throughput (Enterprise Traffic Mix): 500 Mbps
- IPsec VPN Throughput (512 byte): 3.5 Gbps
- Concurrent Sessions (TCP): 600,000
- New Sessions/Second (TCP): 30,000
- Interfaces: 4x GE RJ45 (1x WAN, 2x GE RJ45, 1x FortiLink default), 1x Console (RJ45)
- Internal Storage: 30 GB SSD
- Power Consumption (Average/Maximum): 8.1 W / 9.3 W
- Dimensions (H x W x L): 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm)
Upgrade Your Network Security
Deploy the FortiGate 31G today for high-performance protection and unified management across distributed enterprise sites and branch locations.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Fortinet FortiGate 31G Next-Generation Firewall (Hardware plus 1Yr FortiCare Premium and FortiGuard Enterprise Protection)
Fortinet FortiGate 31G Next-Generation Firewall (Hardware plus 1Yr FortiCare Premium and FortiGuard Enterprise Protection)
[shortdesc] FortiGate 31G Firewall, desktop, 4x GE RJ45, SD-WAN, up to 4/4/3.9 Gbps IPv4, including 1 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]
[properties]
| Model / SKU | FortiGate 31G (FG-31G-BDL-809-12) |
| Form Factor | Desktop |
| Firewall Throughput | 4 / 4 / 3.9 Gbps (IPv4, 1518/512/64 byte UDP) |
| NGFW Throughput | 570 Mbps |
| Internal Storage | 30 GB SSD |
| Network Interfaces | 4x GE RJ45 (1x WAN, 3x Internal; 1x FortiLink default) |
| Dimensions | 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm) |
| Weight | 1.3 lbs (0.6 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) | |
|---|---|
| IPS Throughput | 800 Mbps |
| Threat Protection Throughput | 500 Mbps |
| System Performance | |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 4 / 4 / 3.9 Gbps |
| IPsec VPN Throughput (512 byte) | 3.5 Gbps |
| Firewall Latency (64 byte UDP packets) | 2.87 μs |
| Firewall Throughput (Packets Per Second) | 5.85 Mpps |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 400 Mbps |
| Application Control Throughput (HTTP 64K) | 830 Mbps |
| System Capacity | |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 2,000 |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| Maximum FortiSwitches Supported | 8 |
| Maximum FortiAPs (Total / Tunnel) | 16 / 8 |
| Hardware & Networking | |
| GE RJ45 WAN Port | 1 |
| GE RJ45 Internal Ports | 2 |
| GE RJ45 FortiLink Port | 1 |
| Console Port (RJ45) | 1 |
| Trusted Platform Module (TPM) | Included |
| Environmental & Power | |
| Power Consumption (Average / Maximum) | 8.1 W / 9.3 W |
| Heat Dissipation | 31.713 BTU/hr |
| Operating Altitude | 10,000 ft (3,048 m) |
| Humidity | 20% to 90% non-condensing |
| Certifications | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; USGv6/IPv6 |
[/specifications]
[accesories]
| Included | External DC Power Adapter (100-240V AC, 50/60 Hz) |
| Optional | Wall Mount Kit (Pack of 20): SP-FG60F-MOUNT-20 |
| Optional | AC Power Adaptor (Pack of 10): SP-FG-30G-PA-10(-XX) |
[/accesories]
The FortiGate 31G is engineered to transform WAN architecture at distributed enterprise sites by converging networking and security into a single, high-performance appliance. Powered by Fortinet's patented SD-WAN-based ASIC and the converged FortiOS operating system, this firewall delivers unmatched performance over traditional CPUs with lower power consumption. The 31G model includes 30GB of onboard storage.
This bundle includes a 1-year contract for FortiCare Premium and FortiGuard Enterprise Protection services. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time. Its application-specific design accelerates SSL inspection and IPsec VPN performance to help maintain a robust user experience at branch locations.
Advanced Secure SD-WAN and AI-Powered Threat Protection
- Patented ASIC Acceleration: Built on a patented SD-WAN-based ASIC to accelerate networking and security functions with high efficiency.
- Unified Security Fabric: Works seamlessly with FortiGuard AI-Powered Security Services for coordinated, automated threat protection.
- Enterprise Protection Bundle: Includes a 1-year contract for FortiCare Premium and FortiGuard Enterprise Protection (FG-31G-BDL-809-12).
- Internal Storage: Includes 30GB SSD onboard storage.
- Operational Efficiency: Simplifies operations with FortiOS, centralized visibility, and automated workflows for networking and security.
- Hardware-Based Security: Hardens the platform with a Trusted Platform Module (TPM) for cryptographic key generation, storage, and authentication.
- Reliable Connectivity: Supports High Availability (Active-Passive and Active-Active) configurations to help minimize downtime.
Ideal Use Cases
- Perimeter Protection: Inspect and control incoming and outgoing traffic based on defined security policies with integrated security services.
- Secure SD-WAN: Integrates SD-WAN with security and unified management from a single FortiOS operating system.
- Secure Branch: Extends protection to WAN, LAN, and WLAN when integrated with FortiSwitch and FortiAP for unified connectivity.
- Distributed Sites and Branch Offices: Designed for distributed enterprise sites with a compact desktop form factor and integrated networking and security.
Technical Specifications Summary
- IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
- IPS Throughput (Enterprise Traffic Mix): 800 Mbps
- NGFW Throughput (Enterprise Traffic Mix): 570 Mbps
- Threat Protection Throughput (Enterprise Traffic Mix): 500 Mbps
- IPsec VPN Throughput (512 byte): 3.5 Gbps
- Concurrent Sessions (TCP): 600,000
- New Sessions/Second (TCP): 30,000
- Interfaces: 4x GE RJ45 (1x WAN, 2x GE RJ45, 1x FortiLink default), 1x Console (RJ45)
- Internal Storage: 30 GB SSD
- Power Consumption (Average/Maximum): 8.1 W / 9.3 W
- Dimensions (H x W x L): 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm)
Upgrade Your Network Security
Deploy the FortiGate 31G today for high-performance protection and unified management across distributed enterprise sites and branch locations.
Original: $788.00
-65%$788.00
$275.80Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
[shortdesc] FortiGate 31G Firewall, desktop, 4x GE RJ45, SD-WAN, up to 4/4/3.9 Gbps IPv4, including 1 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]
[properties]
| Model / SKU | FortiGate 31G (FG-31G-BDL-809-12) |
| Form Factor | Desktop |
| Firewall Throughput | 4 / 4 / 3.9 Gbps (IPv4, 1518/512/64 byte UDP) |
| NGFW Throughput | 570 Mbps |
| Internal Storage | 30 GB SSD |
| Network Interfaces | 4x GE RJ45 (1x WAN, 3x Internal; 1x FortiLink default) |
| Dimensions | 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm) |
| Weight | 1.3 lbs (0.6 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) | |
|---|---|
| IPS Throughput | 800 Mbps |
| Threat Protection Throughput | 500 Mbps |
| System Performance | |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 4 / 4 / 3.9 Gbps |
| IPsec VPN Throughput (512 byte) | 3.5 Gbps |
| Firewall Latency (64 byte UDP packets) | 2.87 μs |
| Firewall Throughput (Packets Per Second) | 5.85 Mpps |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 400 Mbps |
| Application Control Throughput (HTTP 64K) | 830 Mbps |
| System Capacity | |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 2,000 |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| Maximum FortiSwitches Supported | 8 |
| Maximum FortiAPs (Total / Tunnel) | 16 / 8 |
| Hardware & Networking | |
| GE RJ45 WAN Port | 1 |
| GE RJ45 Internal Ports | 2 |
| GE RJ45 FortiLink Port | 1 |
| Console Port (RJ45) | 1 |
| Trusted Platform Module (TPM) | Included |
| Environmental & Power | |
| Power Consumption (Average / Maximum) | 8.1 W / 9.3 W |
| Heat Dissipation | 31.713 BTU/hr |
| Operating Altitude | 10,000 ft (3,048 m) |
| Humidity | 20% to 90% non-condensing |
| Certifications | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; USGv6/IPv6 |
[/specifications]
[accesories]
| Included | External DC Power Adapter (100-240V AC, 50/60 Hz) |
| Optional | Wall Mount Kit (Pack of 20): SP-FG60F-MOUNT-20 |
| Optional | AC Power Adaptor (Pack of 10): SP-FG-30G-PA-10(-XX) |
[/accesories]
The FortiGate 31G is engineered to transform WAN architecture at distributed enterprise sites by converging networking and security into a single, high-performance appliance. Powered by Fortinet's patented SD-WAN-based ASIC and the converged FortiOS operating system, this firewall delivers unmatched performance over traditional CPUs with lower power consumption. The 31G model includes 30GB of onboard storage.
This bundle includes a 1-year contract for FortiCare Premium and FortiGuard Enterprise Protection services. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time. Its application-specific design accelerates SSL inspection and IPsec VPN performance to help maintain a robust user experience at branch locations.
Advanced Secure SD-WAN and AI-Powered Threat Protection
- Patented ASIC Acceleration: Built on a patented SD-WAN-based ASIC to accelerate networking and security functions with high efficiency.
- Unified Security Fabric: Works seamlessly with FortiGuard AI-Powered Security Services for coordinated, automated threat protection.
- Enterprise Protection Bundle: Includes a 1-year contract for FortiCare Premium and FortiGuard Enterprise Protection (FG-31G-BDL-809-12).
- Internal Storage: Includes 30GB SSD onboard storage.
- Operational Efficiency: Simplifies operations with FortiOS, centralized visibility, and automated workflows for networking and security.
- Hardware-Based Security: Hardens the platform with a Trusted Platform Module (TPM) for cryptographic key generation, storage, and authentication.
- Reliable Connectivity: Supports High Availability (Active-Passive and Active-Active) configurations to help minimize downtime.
Ideal Use Cases
- Perimeter Protection: Inspect and control incoming and outgoing traffic based on defined security policies with integrated security services.
- Secure SD-WAN: Integrates SD-WAN with security and unified management from a single FortiOS operating system.
- Secure Branch: Extends protection to WAN, LAN, and WLAN when integrated with FortiSwitch and FortiAP for unified connectivity.
- Distributed Sites and Branch Offices: Designed for distributed enterprise sites with a compact desktop form factor and integrated networking and security.
Technical Specifications Summary
- IPv4 Firewall Throughput (1518/512/64 byte UDP): 4 / 4 / 3.9 Gbps
- IPS Throughput (Enterprise Traffic Mix): 800 Mbps
- NGFW Throughput (Enterprise Traffic Mix): 570 Mbps
- Threat Protection Throughput (Enterprise Traffic Mix): 500 Mbps
- IPsec VPN Throughput (512 byte): 3.5 Gbps
- Concurrent Sessions (TCP): 600,000
- New Sessions/Second (TCP): 30,000
- Interfaces: 4x GE RJ45 (1x WAN, 2x GE RJ45, 1x FortiLink default), 1x Console (RJ45)
- Internal Storage: 30 GB SSD
- Power Consumption (Average/Maximum): 8.1 W / 9.3 W
- Dimensions (H x W x L): 1.6 x 5.6 x 6.3 in (40.5 x 142 x 160 mm)
Upgrade Your Network Security
Deploy the FortiGate 31G today for high-performance protection and unified management across distributed enterprise sites and branch locations.
