Fortinet FortiGate 30G Next-Generation Firewall with SD-WAN (FG-30G)
[shortdesc] The FortiGate 30G integrates firewalling, SD-WAN, and security in one appliance, making it perfect for building secure networks at distributed enterprise sites and transforming WAN architecture at any scale. Built on a patented SD-WAN-based ASIC, this desktop appliance delivers unmatched performance and converged networking and security functions to optimize secure connections. [/shortdesc]
[properties]
| Feature | Details |
|---|---|
| Product SKU | FG-30G |
| Form Factor | Desktop |
| Firewall Throughput | 4 / 4 / 3.9 Gbps (IPv4, 1518/512/64 byte UDP) |
| Interfaces | 4x GE RJ45 Ports (including 1x WAN, 3x Internal) |
| Threat Protection | 500 Mbps |
| Power Input | 12VDC, 2A |
| Dimensions (H x W x L) | 1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm) |
| Weight | 1.3 lbs (0.6 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
[/properties]
[specifications]
| System Performance & Capacity | |
|---|---|
| IPS Throughput | 800 Mbps |
| NGFW Throughput | 570 Mbps |
| Firewall Latency | 2.87 μs |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 2,000 |
| VPN Performance | |
| IPsec VPN Throughput (512 byte) | 3.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL Inspection Throughput | 400 Mbps |
| Hardware & Environment | |
| Console Port | 1x RJ45 |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 20% to 90% non-condensing |
| Compliance & Certifications | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA, USGv6/IPv6 |
[/specifications]
[accesories]
| Accessory Type | Description |
|---|---|
| Optional | Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-30G-PA-10(-XX), (-XX=various countries code)) |
[/accesories]
The FortiGate 30G series runs on FortiOS, the industry's first converged networking and security operating system, enabling businesses to gain benefits of operational efficiency and unified protection. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate NGFW works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time.
The 30G family is built on a patented SD-WAN-based ASIC, which delivers unmatched performance over traditional CPUs with lower cost and reduced power consumption. This application-specific design further accelerates the convergence of networking and security functions to optimize secure connections and deliver a robust user experience at branch locations.
Converged Next-Generation Firewall and SD-WAN
Key Benefits
- Unparalleled Performance: Enabled by Fortinet's patented ASIC and the FortiOS operating system to deliver industry-leading throughput and faster security inspections.
- Enterprise-Grade Protection: Natively integrated FortiGuard AI-Powered Security Services protect against malicious traffic, file-based threats, and web-based attacks.
- Simplified Operations: Centralized management for networking and security with automated workflows, deep analytics, and self-healing capabilities reduces complexity.
- Integrated SD-WAN: Delivers faster application identification to avoid delays and accelerates overlay performance regardless of location.
- Compact Form Factor: Small, lightweight, and highly reliable desktop design suitable for small environments or wall-mounting.
Ideal Use Cases
- Secure Branch: Extends security to WAN, LAN, and WLAN at branch offices for unified protection and reliable connectivity.
- Perimeter Protection: Inspects and controls incoming and outgoing traffic based on defined security policies to guard against defined and unknown threats.
- Secure SD-WAN: Enables best-of-breed WAN edge with integrated SD-WAN, WAN optimization, and security from a single OS.
- Remote/Hybrid Work: Enhances hybrid working with a comprehensive SASE solution by integrating cloud-delivered SD-WAN with security service edge (SSE).
Technical Specifications Summary
- Firewall Throughput: High-throughput IPv4 firewall performance for branch networks.
- IPS Throughput: IPS performance designed for enterprise traffic mix inspection.
- Interfaces: Multiple GE RJ45 ports for WAN and internal network connectivity.
- VPN Throughput: Hardware-accelerated IPsec VPN performance for secure site connectivity.
- Power Rating: External DC power input designed for efficient branch deployments.
- Dimensions: Compact desktop form factor with a small footprint.
Upgrade Your Network Security
Deploy the FortiGate 30G today for a compact, high-performance security solution that unifies networking and protection.
