[shortdesc] Firewall, 34 Gbps NGFW, 33 Gbps Threat Protection, 6x 100GE QSFP28 slots, 2x 960GB SSD, rack mount 2 RU [/shortdesc]

[properties]

SKU	FG-3001F
Form Factor	Rack Mount, 2 RU
NGFW Throughput	34 Gbps
Threat Protection Throughput	33 Gbps
Interfaces Summary	6x 100 GE QSFP28 / 40 GE QSFP+ slots, 16x 25 GE SFP28 / 10 GE SFP+ / GE SFP slots (includes 2x HA slots), 16x 10 GE / 5 GE / 2.5 GE / GE RJ45 ports, 2x 10 GE / GE RJ45 management ports
Internal Storage	2x 960GB SSD
Power Input	100–240V AC, 50/60 Hz
Dimensions (H x W x L)	88.9 x 443 x 556 mm (3.5 x 17.44 x 21.89 inches)
Weight	17.3 kg (38.2 lbs)

[/properties]

[specifications]

System Performance
IPS Throughput	36 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	397 / 389 / 221 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	397 / 389 / 221 Gbps
Firewall Latency (64 byte, UDP)	3.92 µs
Firewall Throughput (Packet per Second)	331.5 Mpps
IPsec VPN Throughput (512 byte)	105 Gbps
SSL-VPN Throughput	11 Gbps
SSL Inspection Throughput	29 Gbps
Application Control Throughput	115 Gbps
CAPWAP Throughput	65 Gbps
System Capacity
Concurrent Sessions (TCP)	70 Million / 230 Million
New Sessions/Second (TCP)	870,000 / 3 Million
Firewall Policies	200,000
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
Concurrent SSL-VPN Users (Recommended Max)	30,000
Hardware & Interfaces
Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots	6
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots	16 (includes 2x HA Slots)
Hardware Accelerated 10 GE / 5 GE / 2.5 GE / GE RJ45 Ports	16
10 GE / GE RJ45 Management Ports	2
USB Ports (Client / Server)	1 / 1
Console Port	1
Trusted Platform Module (TPM)	Yes
Dimensions & Weight
Environment & Power
Power Consumption (Average / Maximum)	420 W / 690 W
AC Current (Maximum)	12A @ 100V, 9A @ 240V
Heat Dissipation	2356 BTU/h
Redundant Power Supplies	Yes (Default dual AC PSU for 1+1 Redundancy)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-35°C to 70°C (-31°F to 158°F)
Humidity	5% to 90% non-condensing
Noise Level	69 dBA
Forced Airflow	Front to Back
Operating Altitude	Up to 3,048 m (10,000 ft)
Compliance & Certifications
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories

Rack Mount Sliding Rails (SP-FG3040B-RAIL), AC Power Supply (SP-FG3800D-PS), DC Power Supply (SP-FG3800D-DC-PS), Transceiver Modules (1 GE SFP LX/SX/RJ45, 10 GE SFP+ SR/LR/ER/BD27/BD33/ZR, 25 GE SFP28 SR/LR, 40 GE QSFP+ SR/SR-BiDi/LR/ER, 100 GE QSFP28 SR/LR/CWDM4/BiDi/ER), 25 GE SFP28 Passive Direct Attach Cables (FN-CABLE-SFP28-1/3/5)

[/accesories]

The FortiGate 3001F Series enables organizations to build security-driven networks, forming the foundation of a robust Hybrid Mesh Firewall architecture. This approach weaves security deep into the datacenter and across hybrid IT environments, protecting any edge at any scale. Powered by Fortinet's patented SPU (Security Processing Unit) and vSPU processors, the FG-3001F delivers high performance with integrated AI/ML-based FortiGuard Services to provide coordinated, automated, end-to-end threat protection.

Designed for flexibility and hyperscale, the FortiGate 3001F includes 2x 960GB SSD onboard storage to support local logging and operational needs directly on the appliance. It features the industry's first integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution, automatically controlling and verifying user access to applications. With multiple high-speed interfaces including 100 GE QSFP28 and 25 GE SFP28 slots, this firewall ensures that security does not become a performance bottleneck, even in high-traffic enterprise networks.

High Performance with Flexibility and Integrated Storage

• Unmatched Threat Protection: Delivers 33 Gbps of Threat Protection throughput and 34 Gbps of NGFW throughput to secure business-critical applications against ransomware, malware, and zero-day attacks.
• Hyperscale Scalability: Supports up to 230 million concurrent TCP sessions and 3 million new sessions per second, making it ideal for large-scale enterprise and carrier-grade deployments.
• Integrated Storage: Comes equipped with 2x 960GB SSDs for local logging and operational needs.
• High-Speed Connectivity: Features 6x 100 GE QSFP28 / 40 GE QSFP+ slots and 16x 25 GE SFP28 / 10 GE SFP+ / GE SFP slots (includes 2x HA slots) to simplify network designs and reduce the need for additional bridging devices.
• Energy Efficient Design: Utilizes Fortinet’s custom SPU NP7 and CP9 processors to help reduce power consumption and footprint while maintaining high performance.
• Comprehensive SSL Inspection: Provides 29 Gbps of SSL inspection throughput (including TLS 1.3) to maintain visibility into encrypted traffic without compromising network speed.
• Unified Management: Managed via FortiOS, offering a consolidated view of networking and security policies to reduce complexity and improve operational efficiency.

• Hybrid Mesh Firewall: Seamlessly secure data centers, campus networks, and hybrid clouds with consistent policy enforcement.
• Hyperscale Data Centers: Handle massive traffic volumes and elephant flows with hardware-accelerated performance and ultra-low latency.
• Segmentation: Implement dynamic VXLAN segmentation to bridge physical and virtual domains and prevent lateral threat movement.
• Secure SD-WAN: Transform WAN architectures with integrated SD-WAN capabilities that deliver superior quality of experience and effective security posture.
• Mobile Security (4G/5G): Utilize CGNAT and IPv6 migration options (NAT44, NAT64/DNS64) for secure connectivity in mobile carrier networks.

• IPS Throughput: 36 Gbps
• NGFW Throughput: 34 Gbps
• Threat Protection Throughput: 33 Gbps
• IPv4/IPv6 Firewall Throughput (UDP): 397 / 389 / 221 Gbps (1518/512/64 or 86 byte), 3.92 µs latency (64 byte)
• IPsec VPN Throughput (512 byte): 105 Gbps
• SSL-VPN: 11 Gbps, up to 30,000 concurrent users (recommended max)
• SSL Inspection: 29 Gbps, 29,000 CPS, 7.5 Million concurrent sessions
• Sessions: 70 Million / 230 Million concurrent (TCP), 870,000 / 3 Million new sessions/second (TCP)
• Application Control / CAPWAP: 115 Gbps application control throughput, 65 Gbps CAPWAP throughput
• Interfaces: 6x 100 GE QSFP28 / 40 GE QSFP+ slots, 16x 25 GE SFP28 / 10 GE SFP+ / GE SFP slots (includes 2x HA), 16x 10 GE / 5 GE / 2.5 GE / GE RJ45 ports, 2x 10 GE / GE RJ45 management ports
• Onboard Storage: 2x 960GB SSD
• Power, Physical, Compliance: 100–240V AC, 420 W avg / 690 W max, rack mount 2 RU, 88.9 x 443 x 556 mm, 17.3 kg, FCC Part 15 Class A/RCM/VCCI/CE/UL/cUL/CB, USGv6/IPv6
