[shortdesc]FG-3000F-DC-BDL-809-36 NGFW, 100 GE QSFP28 + 25 GE SFP28, DC power, NP7/CP9 SPU, 33 Gbps threat protection, FortiCare Premium + FortiGuard Enterprise Protection, 3 Year.[/shortdesc]

[properties]

Product Series	FortiGate 3000F Series
SKU	FG-3000F-DC-BDL-809-36
Bundle / Subscription	Hardware + FortiCare Premium + FortiGuard Enterprise Protection (3 Year)
Form Factor	Rack Mount, 2 RU
Threat Protection Throughput	33 Gbps
Interfaces	6x 100 GE QSFP28/40 GE QSFP+, 16x 25 GE SFP28/10 GE SFP+/GE SFP (includes 2x HA slots), 16x 10 GE/5 GE/2.5 GE/GE RJ45, 2x 10 GE/GE RJ45 MGMT
Power Input	48-60VDC
Dimensions (H x W x L)	3.5 x 17.44 x 21.89 inches (88.9 x 443 x 556 mm)
Weight	37.3 lbs (16.9 kg)

[/properties]

[specifications]

Performance / Throughput
IPS Throughput	36 Gbps
NGFW Throughput	34 Gbps
Threat Protection Throughput	33 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	397 / 389 / 221 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	397 / 389 / 221 Gbps
Firewall Latency (64 byte, UDP)	3.92 μs
Firewall Throughput (Packet per Second)	331.5 Mpps
Concurrent Sessions (TCP)	70 Million / 230 Million*
VPN / SD-WAN / NGFW
IPsec VPN Throughput (512 byte)	105 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
SSL-VPN Throughput	11 Gbps
Concurrent SSL-VPN Users (Recommended Max, Tunnel Mode)	30,000
SSL Inspection Throughput (IPS, avg. HTTPS)	29 Gbps
Interfaces / Ports
Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots	6
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots	16 (include 2x HA Slots)
Hardware Accelerated 10 GE / 5 GE / 2.5 GE / GE RJ45 Ports	16
10 GE / GE RJ45 Management Ports	2
USB Ports (Client / Server)	1 / 1
Console Port	1
Included Transceivers	2x SFP+ (SR 10 GE)
Power / Consumption
Power Consumption (Average / Maximum)	425 W / 680 W
DC Current (Maximum)	15A@48V, 9A@240V
Heat Dissipation	2321 BTU/h
Redundant Power Supplies	Included (Default dual DC PSU for 1+1 redundancy, hot swappable)

[/specifications]

[accesories]

Included Transceivers	2x SFP+ (SR 10 GE)
Optional Accessories	Rack Mount Sliding Rails (SP-FG3040B-RAIL), DC Power Supply (SP-FG3800D-DC-PS), and transceiver modules/cables for 1 GE, 10 GE, 25 GE, 40 GE, and 100 GE connectivity

[/accesories]

The FortiGate 3000F-DC is a high-performance Next-Generation Firewall (NGFW) optimized for data centers and telecommunications environments requiring DC power. This bundle (FG-3000F-DC-BDL-809-36) includes Hardware + FortiCare Premium + FortiGuard Enterprise Protection (3 Year).

Powered by Fortinet's patented SPU NP7 and CP9 processors, it delivers 33 Gbps Threat Protection throughput with 100 GE QSFP28 connectivity for high-bandwidth cores. Flexible interfaces and dual DC power supplies support DC-powered infrastructure at scale.

Hyperscale Security with DC Power for Critical Infrastructure

• 33 Gbps threat protection throughput (Enterprise Traffic Mix).
• 6x 100 GE QSFP28 / 40 GE QSFP+ slots.
• 16x 25 GE SFP28/10 GE SFP+/GE SFP slots.
• 16x 10 GE/5 GE/2.5 GE/GE RJ45 ports.
• 48-60VDC input with default dual DC PSU.
• BDL-809 includes FortiCare Premium and Enterprise Protection, 3 Year.

Upgrade Your Network Security

Deploy the FortiGate FG-3000F-DC-BDL-809-36 for DC-powered 100 GE NGFW protection.
