[shortdesc]Firewall, 33 Gbps threat protection, 6x 100GE QSFP28, 16x 25GE SFP28, 2RU rack mount[/shortdesc]

[properties]

Product Series	FortiGate 3000F Series
SKU	FG-3000F
Form Factor	Rack Mount, 2 RU
Threat Protection Throughput	33 Gbps
Interfaces	6x 100 GE QSFP28 / 40 GE QSFP+, 16x 25 GE SFP28 / 10 GE SFP+ / GE SFP (including 2x HA Slots), 16x 10 GE / 5 GE / 2.5 GE / GE RJ45, 2x 10 GE / GE RJ45 Management Ports
Power Input	100-240V AC, 50/60 Hz
Dimensions (H x W x L)	3.5 x 17.44 x 21.89 inches (88.9 x 443 x 556 mm)
Weight	37.3 lbs (16.9 kg)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance - Enterprise Traffic Mix
IPS Throughput	36 Gbps
NGFW Throughput	34 Gbps
System Performance & Capacity
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	397 / 389 / 221 Gbps
IPv6 Firewall Throughput (1518/512/86 byte, UDP)	397 / 389 / 221 Gbps
Firewall Latency (64 byte, UDP)	3.92 μs
Firewall Throughput (Packet per Second)	331.5 Mpps
Concurrent Sessions (TCP)	70 Million / 230 Million*
New Sessions/Second (TCP)	870,000 / 3 Million*
Firewall Policies	200,000
IPsec VPN Throughput (512 byte)	105 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	40,000
Client-to-Gateway IPsec VPN Tunnels	200,000
SSL-VPN Throughput	11 Gbps
Concurrent SSL-VPN Users (Recommended Max, Tunnel Mode)	30,000
SSL Inspection Throughput (IPS, avg. HTTPS)	29 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)	29,000
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	7.5 Million
Application Control Throughput (HTTP 64K)	115 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
Virtual Domains (Default / Maximum)	10 / 500
Maximum Number of FortiSwitches Supported	300
Maximum Number of FortiAPs (Total / Tunnel)	4096 / 2048
Maximum Number of FortiTokens	20,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots	6
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots	16 (include 2x HA Slots)
Hardware Accelerated 10 GE / 5 GE / 2.5 GE / GE RJ45 Ports	16
10 GE / GE RJ45 Management Ports	2
USB Ports	1 / 1 (Client / Server)
Console Port	1
Trusted Platform Module (TPM)	Included
Dimensions & Power
Power Consumption (Average / Maximum)	425 W / 680 W
Heat Dissipation	2321 BTU/h
Redundant Power Supplies	Default dual AC PSU for 1+1 Redundancy (Hot Swappable)
Operating Environment & Certifications
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	69 dBA
Forced Airflow	Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)

[/specifications]

[accesories]

Included Transceivers	2x SFP+ (SR 10 GE)
Optional Accessories	Rack Mount Sliding Rails, AC Power Supply, DC Power Supply, Various Transceiver Modules (1 GE, 10 GE, 25 GE, 40 GE, 100 GE)

[/accesories]

The FortiGate 3000F Series enables organizations to build security-driven networks, forming the foundation of a robust Hybrid Mesh Firewall architecture. By weaving security deep into the data center and across hybrid IT environments, it protects any edge at any scale. This high-performance appliance is powered by Fortinet's patented Security Processing Unit (SPU) technology, specifically the NP7 Network Processor and CP9 Content Processor, to deliver unparalleled speed and efficiency.

With integrated Zero Trust Network Access (ZTNA) enforcement, the FortiGate 3000F automatically controls, verifies, and facilitates user access to applications, reducing lateral threats. The device supports hyperscale security to secure any edge, providing industry-leading performance for VPN, VXLAN termination, and hardware logging. Its versatile interface options, including multiple 100 GE QSFP28 and 25 GE SFP28 slots, ensure seamless integration into high-bandwidth core networks.

Hyperscale Security and Unparalleled Performance for the Enterprise

• Extreme Performance: Delivers up to 397 / 389 / 221 Gbps IPv4 firewall throughput (1518 / 512 / 64 byte, UDP) and 33 Gbps threat protection throughput, powered by custom SPU NP7 and CP9 processors.
• High-Speed Connectivity: Features 6x 100 GE QSFP28 / 40 GE QSFP+ slots and 16x 25 GE SFP28 / 10 GE SFP+ / GE SFP slots (including 2x HA slots) to support data center aggregation and high-bandwidth requirements.
• Integrated ZTNA: The industry's first NGFW with integrated Zero Trust Network Access enforcement to securely control user access to applications.
• Scalable Segmentation: Supports ultra-scalable, low-latency VXLAN segmentation to bridge physical and virtual domains.
• Operational Efficiency: Consolidates networking and security into a single platform powered by FortiOS, reducing complexity and TCO.
• Energy Efficient: Designed with energy-efficient ASICs to lower power consumption and heat dissipation compared to traditional CPUs.

• Enterprise Data Centers: Ideal for high-speed core firewalls requiring 100 GE connectivity and hyperscale inspection.
• Internal Segmentation: Prevents lateral movement of threats by segmenting network zones with high-performance inspection.
• Hybrid Cloud Environments: Secures connectivity between on-premise infrastructure and multi-cloud environments.
• Secure Remote Access: Manages massive volumes of VPN traffic with 105 Gbps IPsec VPN throughput and 200,000 client tunnels.

• IPS Throughput (Enterprise Mix): 36 Gbps
• NGFW Throughput (Enterprise Mix): 34 Gbps
• Threat Protection Throughput (Enterprise Mix): 33 Gbps
• IPv4 Firewall Throughput (1518/512/64 byte, UDP): 397 / 389 / 221 Gbps
• Firewall Latency (64 byte, UDP): 3.92 μs
• Concurrent Sessions (TCP): 70 Million / 230 Million (requires Hyperscale Firewall License)
• New Sessions/Second (TCP): 870,000 / 3 Million (requires Hyperscale Firewall License)
• IPsec VPN Capacity: 105 Gbps (512 byte), 40,000 gateway-to-gateway tunnels, 200,000 client-to-gateway tunnels
• Interfaces: 6x 100 GE QSFP28 / 40 GE QSFP+, 16x 25 GE SFP28 (including 2x HA slots), 16x multi-Gig RJ45, 2x 10 GE / GE RJ45 management
• Onboard Storage: 2x 960GB SSD
• Power Consumption (Average / Maximum): 425 W / 680 W, 100-240V AC, 50/60 Hz
• Form Factor and Environment: 2 RU rack mount, 3.5 x 17.44 x 21.89 in (88.9 x 443 x 556 mm), 37.3 lbs (16.9 kg), 32°F to 104°F (0°C to 40°C)
