[shortdesc] Firewall, 1RU, 480GB SSD, 8x10GE SFP+, 8x5GE RJ45, 39/39/26.5 Gbps, including 5 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]

[properties]

Product SKU	FG-201G-BDL-950-60
Bundle / Subscription	FortiGate 201G firewall plus FortiCare Premium and FortiGuard Unified Threat Protection (UTP), 5 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	39 / 39 / 26.5 Gbps (IPv4/IPv6 1518/512/64 byte, UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45 (including 1x MGMT, 1x HA, 8x switch ports), 8x 5GE RJ45, 8x 10GE SFP+, 4x GE SFP
Internal Storage	1x 480 GB SSD
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.33 lbs (6.5 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10/GE SFP+ FortiLink Slots (default)	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 176 W
Heat Dissipation	600.54 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certification	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	GE SFP SX/LX, 10GE SFP+ RJ45/SR/LR/ER/ZR, 10GE SFP+ 30km BiDi (BD27/BD33), 25GE SFP28 SR
Cables	10 GE SFP+ Passive Direct Attach Cable (1m, 3m, 5m)

[/accesories]

The Fortinet FG-201G-BDL-950-60 bundle includes a FortiGate 201G firewall with FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for 5 Years.

The Fortinet FortiGate 201G Series next-generation firewall (NGFW) combines AI-powered security and machine learning to deliver scalable threat protection for modern enterprises. A key differentiator for the FortiGate 201G is its integrated 480GB onboard SSD, which provides local storage for logging and reporting. By consolidating security functions into a single platform powered by FortiOS, the FortiGate 201G simplifies management while providing deep visibility into applications, users, and devices.

At the core of the FortiGate 201G are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated ASICs offload resource-intensive tasks to deliver industry-leading performance, including 9 Gbps of IPS throughput and 6 Gbps of Threat Protection throughput. With integrated capabilities for Zero-Trust Network Access (ZTNA) and Secure SD-WAN, the FortiGate 201G reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with Integrated Storage and AI Protection

• Integrated Local Storage: Includes a 480GB SSD for local logging and reporting directly on the appliance.
• High-Performance Security: Delivers up to 39 / 39 / 26.5 Gbps IPv4/IPv6 firewall throughput and 9 Gbps IPS throughput using NP7Lite and CP10 processors.
• AI-Powered Protection: Utilizes machine learning to detect and block known, unknown, and zero-day threats in real time.
• Deep Visibility: Provides granular insight into users, devices, and applications, including full SSL inspection with TLS 1.3 support.
• Integrated SD-WAN: Unifies security and networking to transform WAN edges, ensuring superior quality of experience for hybrid work models.
• Scalable Segmentation: Supports dynamic and VXLAN segmentation to prevent lateral movement and bridge physical and virtual domains.
• Universal ZTNA: Automatically controls, verifies, and facilitates user access to applications, reducing lateral threats by providing access only to validated users.

• Next Generation Firewall (NGFW): FortiGuard Labs AI-powered security services integrated with the NGFW protect web, content, and devices.
• Real-time SSL Inspection: SSL inspection (including TLS 1.3) provides visibility into users, devices, and applications across the attack surface.
• Secure SD-WAN: WAN Edge powered by one OS and unified security and management framework transforms and secures WANs.
• Universal ZTNA: Controls access to applications wherever users and applications are hosted for universal application of access policies.
• Segmentation: Dynamic segmentation and ultra-scalable, low latency VXLAN segmentation reduce lateral movement across the network.

• IPv4/IPv6 Firewall Throughput (1518/512/64 byte, UDP): 39 / 39 / 26.5 Gbps
• IPS Throughput (Enterprise Mix): 9 Gbps
• NGFW Throughput (Enterprise Mix): 7 Gbps
• Threat Protection Throughput (Enterprise Mix): 6 Gbps
• IPsec VPN Throughput (512 byte): 36 Gbps
• Network Interfaces: 8x GE RJ45 switch ports, 8x 5/2.5/GE RJ45, 8x 10GE SFP+ FortiLink slots, 4x GE SFP, plus 1x GE MGMT and 1x GE HA
• Onboard Storage: 1x 480 GB SSD
• Power (Average / Maximum): 145 W / 176 W; dual built-in non-hot swappable AC PSU

Upgrade Your Network Security

Equip your enterprise with the AI-driven performance and integrated storage of the FortiGate FG-201G-BDL-950-60 today.
