[shortdesc] Firewall, 1RU, 39 Gbps firewall, 8x 10GE SFP+, 8x 5GE RJ45, 480GB SSD, including 3 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]

[properties]

Product SKU	FG-201G-BDL-950-36
Bundle / Subscription	FortiCare Premium + FortiGuard Unified Threat Protection (UTP), 3 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	39 / 39 / 26.5 Gbps (IPv4/IPv6, 1518/512/64 byte, UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45 (including 1x MGMT, 1x HA, 8x switch ports), 8x 5GE RJ45, 8x 10GE SFP+ (FortiLink), 4x GE SFP
Internal Storage	1x 480 GB SSD
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.33 lbs (6.5 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	Compliance: FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; Certification: USGv6/IPv6

[/properties]

[specifications]

System Performance
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10/GE SFP+/SFP Slots	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 176 W
Heat Dissipation	600.54 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	GE SFP SX/LX, 10GE SFP+ RJ45/SR/LR/ER/ZR, 10GE SFP+ 30km BiDi (BD27/BD33), 25GE SFP28 SR
Cables	10 GE SFP+ Passive Direct Attach Cable (1m, 3m, 5m)

[/accesories]

The Fortinet FG-201G-BDL-950-36 bundle includes FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for 3 Years.

The Fortinet FortiGate 201G Series next-generation firewall (NGFW) combines AI-powered security and machine learning to deliver scalable threat protection for modern enterprises. A key differentiator for the FortiGate 201G is its integrated 480GB onboard SSD, which provides onboard storage for logging and reporting. By consolidating security functions into a single platform powered by FortiOS, the FortiGate 201G simplifies management while providing deep visibility into applications, users, and devices.

At the core of the FortiGate 201G are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated ASICs offload resource-intensive tasks to deliver high performance, including 9 Gbps of IPS throughput and 6 Gbps of Threat Protection throughput. With integrated capabilities for Zero-Trust Network Access (ZTNA) and Secure SD-WAN, the FortiGate 201G reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with Integrated Storage and AI Protection

• Integrated Local Storage: Includes a 480GB SSD for local logging and reporting directly on the appliance.
• High-Performance Security: Delivers 39 Gbps firewall throughput and 9 Gbps IPS performance using NP7Lite and CP10 processors.
• AI/ML-Powered Security Services: FortiGuard services help protect against known, unknown, and zero-day threats.
• Deep Visibility: Provides visibility into users, devices, and applications, including real-time SSL inspection (including TLS 1.3).
• Integrated SD-WAN: Unifies security and networking to transform WAN edges for hybrid working models, SD-Branch, and cloud-first WAN use cases.
• Scalable Segmentation: Supports dynamic and VXLAN segmentation to reduce lateral movement and bridge physical and virtual domains.
• Universal ZTNA: Automatically controls, verifies, and facilitates user access to applications with consistent access policies.

• Enterprises Requiring Onboard Storage: Designed for organizations that benefit from integrated SSD storage for local logging and reporting.
• Hybrid Mesh Firewalls: Deploy consistent security across distributed networks with coordinated policy enforcement and threat protection.
• Secure SD-WAN: Connect branch offices and remote locations with secure, high-performance WAN edge capabilities.
• Campus Edge Protection: Secures user access and devices with deep visibility and integrated security services.
• Encrypted Traffic Inspection: Supports SSL inspection to help provide visibility into encrypted traffic at the edge.

• Firewall Throughput (IPv4/IPv6, 1518/512/64 byte UDP): 39 / 39 / 26.5 Gbps
• IPS Throughput: 9 Gbps
• NGFW Throughput: 7 Gbps
• Threat Protection Throughput: 6 Gbps
• IPsec VPN Throughput (512 byte): 36 Gbps
• SSL-VPN Throughput: 3 Gbps
• Concurrent Sessions (TCP): 11 Million
• Network Interfaces: 10x GE RJ45 (including 1x MGMT, 1x HA, 8x switch), 8x 5GE RJ45, 8x 10GE SFP+ (FortiLink), 4x GE SFP
• Onboard Storage: 1x 480 GB SSD
• AC Power Consumption (Average / Maximum): 145 W / 176 W

Upgrade Your Network Security

Equip your enterprise with the AI-driven performance and integrated storage of the FortiGate FG-201G-BDL-950-36 today.
