[shortdesc] Firewall, 39/39/26.5 Gbps, 8x10GE SFP+ + 8x5GE RJ45, 480GB SSD, including 5 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Product SKU	FG-201G-BDL-809-60
Bundle / Subscription	Firewall appliance + FortiCare Premium + FortiGuard Enterprise Protection, 5 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	IPv4/IPv6: 39 / 39 / 26.5 Gbps (1518/512/64 byte, UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45, 8x 5GE RJ45, 8x 10GE SFP+, 4x GE SFP
Internal Storage	1x 480 GB SSD
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.33 lbs (6.5 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10/GE SFP+/SFP Slots	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 176 W
Heat Dissipation	600.54 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	GE SFP SX/LX, 10GE SFP+ RJ45/SR/LR/ER/ZR, 10GE SFP+ 30km BiDi (BD27/BD33), 25GE SFP28 SR
Cables	10 GE SFP+ Passive Direct Attach Cable (1m, 3m, 5m)

[/accesories]

The Fortinet FG-201G-BDL-809-60 bundle includes a FortiGate firewall appliance plus FortiCare Premium and FortiGuard Enterprise Protection for 5 Years.

The Fortinet FortiGate 200G Series next-generation firewall (NGFW) combines AI-powered security and machine learning (ML) to deliver threat protection at any scale. A key differentiator for the FortiGate 201G is its integrated 480GB onboard SSD storage. Powered by FortiOS, the FortiGate 200G Series delivers secure networking that is broad, deep, and automated, with deeper visibility into applications, users, and devices beyond traditional firewall techniques.

At the core of the FortiGate 200G Series are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated processors deliver high performance, including 9 Gbps IPS throughput and 6 Gbps Threat Protection throughput. With integrated capabilities for Universal ZTNA and Secure SD-WAN, the FortiGate 200G Series reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with Integrated Storage and AI Protection

• Integrated SSD Storage: Includes 1x 480 GB SSD onboard storage.
• High-Performance Security: Delivers up to 39 / 39 / 26.5 Gbps IPv4/IPv6 firewall throughput (1518/512/64 byte, UDP) and 9 Gbps IPS throughput.
• AI/ML-Powered Security: Consolidated security services designed to protect against modern attack vectors, including known, unknown, and zero-day threats.
• Deep Visibility: Provides visibility into applications, users, and devices with real-time SSL inspection (including TLS 1.3).
• Integrated Secure SD-WAN: Unifies security and networking to transform and secure WAN edges.
• Segmentation: Supports dynamic segmentation and VXLAN segmentation to help reduce lateral movement across networks.
• Universal ZTNA: Automatically controls, verifies, and facilitates user access to applications to reduce lateral threats.

• Onboard Storage Deployments: Suitable for environments that require integrated SSD storage on the appliance.
• Hybrid Mesh Firewall Architectures: Deploy consistent security across distributed networks with unified policy enforcement.
• Secure SD-WAN: Connect branch offices and remote locations with converged networking and security.
• Segmentation Use Cases: Apply dynamic and VXLAN segmentation across physical and virtual domains.
• Encrypted Traffic Inspection: Provide SSL inspection visibility (including TLS 1.3) across the attack surface.

• NGFW Throughput: 7 Gbps
• Threat Protection Throughput: 6 Gbps
• IPv4/IPv6 Firewall Throughput: 39 / 39 / 26.5 Gbps (1518/512/64 byte, UDP)
• Firewall Latency: 4.36 μs (64 byte, UDP)
• IPsec VPN Throughput: 36 Gbps (512 byte)
• SSL-VPN Throughput: 3 Gbps
• Interfaces: 10x GE RJ45, 8x 5GE RJ45, 8x 10GE SFP+, 4x GE SFP
• Onboard Storage: 1x 480 GB SSD
• Concurrent Sessions (TCP): 11 Million
• Power Consumption (Average / Maximum): 145 W / 176 W

Upgrade Your Network Security

Equip your enterprise with the performance and integrated storage of the FortiGate FG-201G-BDL-809-60 today.
