[shortdesc] Firewall, 1RU rackmount, 480GB onboard SSD, NP7Lite/CP10 acceleration, 10GE SFP+ & 5GE RJ45, 39 Gbps, including 3 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Product SKU	FG-201G-BDL-809-36
Bundle / Subscription	FortiGate firewall plus FortiCare Premium + FortiGuard Enterprise Protection, 3 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	39 / 39 / 26.5 Gbps (IPv4, 1518/512/64 byte, UDP) / 39 / 39 / 26.5 Gbps (IPv6, 1518/512/64 byte, UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45, 8x 5GE RJ45, 8x 10GE SFP+/SFP FortiLink slots, 4x GE SFP
Internal Storage	1x 480 GB SSD
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.33 lbs (6.5 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10/GE SFP+/SFP Slots	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 176 W
Heat Dissipation	600.54 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certification	USGv6/IPv6

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	GE SFP SX/LX, 10GE SFP+ RJ45/SR/LR/ER/ZR, 10GE SFP+ 30km BiDi (BD27/BD33), 25GE SFP28 SR
Cables	10 GE SFP+ Passive Direct Attach Cable (1m, 3m, 5m)

[/accesories]

The Fortinet FG-201G-BDL-809-36 bundle includes FortiGate firewall plus FortiCare Premium + FortiGuard Enterprise Protection for 3 Years.

The Fortinet FortiGate 201G Series next-generation firewall (NGFW) combines AI-powered security and machine learning to deliver scalable threat protection for modern enterprises. A key differentiator for the FortiGate 201G is its integrated 480GB onboard SSD storage. By consolidating security functions into a single platform powered by FortiOS, the FortiGate 201G simplifies management while providing deep visibility into applications, users, and devices.

At the core of the FortiGate 201G are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated ASICs offload resource-intensive tasks to deliver industry-leading performance, including 9 Gbps of IPS throughput and 6 Gbps of Threat Protection throughput. With integrated capabilities for Zero-Trust Network Access (ZTNA) and Secure SD-WAN, the FortiGate 201G reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with Integrated Storage and AI Protection

• Integrated Onboard Storage: Includes 480GB onboard SSD storage.
• High-Performance Security: Delivers up to 39 Gbps firewall throughput and 9 Gbps IPS performance using NP7Lite and CP10 processors.
• AI-Powered Protection: Utilizes AI/ML-powered security capabilities and FortiGuard services to enhance threat protection.
• Deep Visibility: Provides real-time SSL inspection, including TLS 1.3, for visibility into users, devices, and applications.
• Integrated SD-WAN: Unifies security and networking to transform WAN edges and support hybrid working models.
• Scalable Segmentation: Supports dynamic segmentation and VXLAN segmentation to bridge physical and virtual domains with Layer 4 firewall rules.
• Universal ZTNA: Automatically controls, verifies, and facilitates user access to applications to reduce lateral threats.

• Enterprises Requiring Onboard Storage: Suitable for deployments that need integrated SSD storage on the appliance.
• Hybrid Mesh Firewalls: Deploy consistent security across distributed networks with unified policy enforcement.
• Secure SD-WAN: Connect branch offices and remote locations with secure, high-performance WAN connectivity.
• Campus Edge Protection: Secure user access and IoT devices with deep visibility and coordinated protection.
• Encrypted Traffic Inspection: Use SSL inspection performance up to 7 Gbps (IPS, avg. HTTPS) for encrypted traffic visibility.

• NGFW Throughput: 7 Gbps
• Threat Protection Throughput: 6 Gbps
• IPv4/IPv6 Firewall Throughput (1518/512/64 byte, UDP): 39 / 39 / 26.5 Gbps
• IPsec VPN Throughput (512 byte): 36 Gbps
• SSL-VPN Throughput: 3 Gbps
• Firewall Latency (64 byte, UDP): 4.36 μs
• Concurrent Sessions (TCP): 11 Million
• New Sessions/Second (TCP): 400,000
• Network Interfaces: 10x GE RJ45, 8x 5GE RJ45, 8x 10GE SFP+/SFP, 4x GE SFP
• Onboard Storage: 1x 480 GB SSD
• Power Consumption (Average / Maximum): 145 W / 176 W

Upgrade Your Network Security

Equip your enterprise with the AI-driven performance and integrated storage of the FortiGate FG-201G-BDL-809-36 today.
