[shortdesc] Firewall, 1RU, 39/39/26.5 Gbps IPv4/IPv6, 8x10GE SFP+, 8x5/2.5GE, 480GB SSD, including 1 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Product SKU	FG-201G-BDL-809-12
Bundle / Subscription	Firewall appliance + FortiCare Premium + FortiGuard Enterprise Protection, 1 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	39 / 39 / 26.5 Gbps (IPv4/IPv6 1518/512/64 byte, UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45 (including 1x MGMT port, 1x HA port, 8x switch ports), 8x 5/2.5/GE RJ45, 8x 10GE SFP+ slots, 4x GE SFP slots
Internal Storage	1x 480 GB SSD
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.33 lbs (6.5 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10/GE SFP+/SFP FortiLink Slots (default)	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 176 W
Heat Dissipation	600.54 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	GE SFP SX/LX, 10GE SFP+ RJ45/SR/LR/ER/ZR, 10GE SFP+ 30km BiDi (BD27/BD33), 25GE SFP28 SR
Cables	10 GE SFP+ Passive Direct Attach Cable (1m, 3m, 5m)

[/accesories]

The Fortinet FG-201G-BDL-809-12 bundle includes a firewall appliance plus FortiCare Premium and FortiGuard Enterprise Protection for 1 Year.

The Fortinet FortiGate 201G Series firewall combines AI-powered security and machine learning to deliver scalable threat protection for modern enterprises. A key differentiator for the FortiGate 201G is its integrated 480GB onboard SSD, which provides essential local storage for logging and efficient data handling directly on the appliance. By consolidating security functions into a single platform powered by FortiOS, the FortiGate 201G simplifies management while providing deep visibility into applications, users, and devices.

At the core of the FortiGate 201G are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated ASICs offload resource-intensive tasks to deliver high performance, including 9 Gbps of IPS throughput and 6 Gbps of Threat Protection throughput. With integrated capabilities for Zero-Trust Network Access (ZTNA) and Secure SD-WAN, the FortiGate 201G reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with Integrated Storage and AI Protection

• Integrated Local Storage: Includes a 480GB SSD for local logging and efficient data handling directly on the appliance.
• High-Performance Security: Delivers 39 / 39 / 26.5 Gbps firewall throughput (IPv4/IPv6 1518/512/64 byte, UDP) using custom NP7Lite and CP10 processors.
• AI-Powered Security: Combines AI-powered security and machine learning to deliver scalable threat protection for modern networks.
• Deep Visibility: Provides granular insight into users, devices, and applications, including full SSL inspection with TLS 1.3 support.
• Integrated SD-WAN: Unifies security and networking to transform WAN edges, ensuring superior quality of experience for hybrid work models.
• Scalable Segmentation: Supports dynamic and VXLAN segmentation to reduce lateral movement and strengthen security across distributed environments.
• Universal ZTNA: Enforces consistent access policies and verifies users automatically, regardless of location or application hosting.

• Enterprises Requiring Local Logging: Ideal for organizations needing onboard storage for compliance-related logging and retention.
• Hybrid Mesh Firewalls: Deploy consistent security across distributed networks, ensuring seamless policy enforcement.
• Secure SD-WAN: Perfect for connecting branch offices and remote locations with secure, high-performance wide area networking.
• Campus Edge Protection: Secures user access and IoT devices with deep visibility and automated control.
• Encrypted Traffic Inspection: Suitable for environments requiring real-time SSL inspection with strong performance.

• IPS Throughput: 9 Gbps
• NGFW Throughput: 7 Gbps
• Threat Protection Throughput: 6 Gbps
• IPv4/IPv6 Firewall Throughput (1518/512/64 byte, UDP): 39 / 39 / 26.5 Gbps
• IPsec VPN Throughput (512 byte): 36 Gbps
• SSL Inspection Throughput (IPS, avg. HTTPS): 7 Gbps
• Concurrent Sessions (TCP): 11 Million
• Ports: 8x GE RJ45 switch, 1x GE RJ45 MGMT, 1x GE RJ45 HA, 8x 5/2.5/GE RJ45, 8x 10GE SFP+/SFP slots, 4x GE SFP slots
• Onboard Storage: 1x 480 GB SSD
• Power: Dual built-in non-hot swappable AC PSU, 145 W avg / 176 W max, 100–240V AC 50/60Hz

Upgrade Your Network Security

Equip your enterprise with the AI-driven performance and integrated storage of the FortiGate FG-201G-BDL-809-12 today.
