[shortdesc] Firewall, 1RU rackmount, 10/5/10GE ports, NP7Lite+CP10, 9 Gbps IPS, including 3 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]

[properties]

Product SKU	FG-200G-BDL-950-36
Bundle / Subscription	Firewall + FortiCare Premium + FortiGuard Unified Threat Protection (UTP), 3 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	39 Gbps (IPv4, 1518 byte UDP) / 39 Gbps (IPv6, 1518 byte UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45 (including 1x MGMT port, 1x HA port, 8x switch ports), 8x 5/2.5/GE RJ45, 8x 10GE SFP+/SFP FortiLink Slots (default), 4x GE SFP
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.11 lbs (6.4 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Certifications	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance — Enterprise Traffic Mix
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10GE SFP+/SFP FortiLink Slots (default)	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 175 W
Heat Dissipation	597.12 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	1 GE SFP SX (FN-TRAN-SX), 1 GE SFP LX (FN-TRAN-LX), 10 GE SFP+ RJ45 (FN-TRAN-SFP+GC), 10 GE SFP+ SR (FN-TRAN-SFP+SR), 10 GE SFP+ LR (FN-TRAN-SFP+LR), 10 GE SFP+ ER (FN-TRAN-SFP+ER), 10 GE SFP+ ZR 80km (FN-TRAN-SFP+ZR), 10 GE SFP+ BiDi 30km (FN-TRAN-SFP+BD27 and FN-TRAN-SFP+BD33), 25 GE SFP28 SR (FN-TRAN-SFP28-SR)
Cables	10 GE SFP+ Passive Direct Attach Cable 1m (FN-CABLE-SFP+1), 3m (FN-CABLE-SFP+3), 5m (FN-CABLE-SFP+5)

[/accesories]

The Fortinet FortiGate 200G Series next-generation firewall (NGFW) combines AI-powered security and machine learning to deliver scalable threat protection for modern enterprises. By consolidating security functions into a single platform powered by FortiOS, the FortiGate 200G simplifies management while providing deep visibility into applications, users, and devices. This solution integrates seamlessly with the Fortinet Security Fabric, ensuring consistent policy enforcement across hybrid environments, from the campus edge to the data center. The FG-200G-BDL-950-36 bundle includes FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for 3 years.

At the core of the FortiGate 200G are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated ASICs offload resource-intensive tasks to deliver industry-leading performance, including 9 Gbps of IPS throughput and 6 Gbps of Threat Protection throughput. With integrated capabilities for Zero-Trust Network Access (ZTNA) and Secure SD-WAN, the FortiGate 200G reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with AI-Powered Threat Protection

• High-Performance Security: Delivers up to 39 Gbps firewall throughput with ultra-low latency (4.36 μs) powered by NP7Lite and CP10 acceleration.
• AI-Powered Protection: Utilizes machine learning to detect and block known, unknown, and zero-day threats in real time.
• Deep Visibility: Provides granular insight into users, devices, and applications, including real-time SSL inspection (TLS 1.3) without impacting performance.
• Integrated SD-WAN: Unifies security and networking to transform WAN edges, ensuring superior quality of experience for hybrid work models.
• Scalable Segmentation: Supports dynamic and VXLAN segmentation to prevent lateral movement and bridge physical and virtual domains.
• Universal ZTNA: Enforces consistent access policies and verifies users automatically, regardless of location or application hosting.
• Hardware-Backed Security: Includes a Trusted Platform Module (TPM) and dedicated hardware protections designed to harden the appliance against tampering and compromise.

• Next-Generation Firewall (NGFW): Suitable for deployments requiring consolidated security with deep visibility into applications, users, and devices.
• Hybrid Mesh Firewall Architecture: Helps extend consistent policy enforcement and threat protection across network segments.
• Secure SD-WAN: Designed to transform and secure WAN edges with unified security and management.
• Universal ZTNA: Controls access to applications regardless of user location or application hosting.
• Segmentation: Supports dynamic segmentation and VXLAN segmentation to help reduce lateral threats across hybrid IT networks.

• Technical Specifications Summary — Firewall Performance: IPv4 and IPv6 firewall throughput (1518/512/64 byte UDP) 39 / 39 / 26.5 Gbps; latency (64 byte UDP) 4.36 μs; firewall throughput 39.75 Mpps.
• Security Throughput: IPS (Enterprise Mix) 9 Gbps; NGFW 7 Gbps; Threat Protection 6 Gbps.
• VPN & SSL: IPsec VPN (512 byte) 36 Gbps; SSL-VPN 3 Gbps (500 recommended concurrent users); SSL inspection (IPS, avg. HTTPS) 7 Gbps; SSL inspection CPS (IPS, avg. HTTPS) 7100; SSL inspection concurrent sessions (IPS, avg. HTTPS) 900,000.
• Interfaces: 8x GE RJ45 ports plus 1x GE RJ45 management and 1x GE RJ45 HA; 8x 5/2.5/GE RJ45; 8x 10GE SFP+/SFP FortiLink slots (default); 4x GE SFP slots; 1x USB; 1x console.
• Capacity: 11 million concurrent sessions; 400,000 new sessions/second; 10,000 firewall policies; IPsec VPN tunnels 2,000 (gateway-to-gateway) and 16,000 (client-to-gateway); VDOMs 10 (default) / 25 (max).
• Power & Thermal: 100–240V AC input (50/60Hz); AC current (max) 2A @ 100VAC, 1.2A @ 240VAC; power consumption 145 W average / 175 W maximum; heat dissipation 597.12 BTU/h; dual built-in non-hot swappable AC PSU.
• Physical/Environment/Compliance: 1 RU (1.75 x 17.0 x 15.0 in / 44.45 x 432 x 380 mm), 14.11 lbs (6.4 kg); operating 0°C to 40°C; storage -35°C to 70°C; humidity 5%–90% non-condensing; noise LPA 48 dBA / LWA 55 dBA; operating altitude up to 10,000 ft (3048 m); compliance FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; certification USGv6/IPv6.

Upgrade Your Network Security

Equip your enterprise with the AI-driven performance of the FG-200G-BDL-950-36 today.
