[shortdesc] Firewall, 1RU rackmount, 39 Gbps, 8x 10GE SFP+, 9 Gbps IPS, including 5 Year FortiCare Premium and FortiGuard Enterprise Protection [/shortdesc]

[properties]

Product SKU	FG-200G-BDL-809-60
Bundle / Subscription	FortiGate firewall + FortiCare Premium + FortiGuard Enterprise Protection, 5 Year
Form Factor	Rack Mount, 1 RU
Firewall Throughput	39 Gbps (IPv4, 1518 byte UDP) / 39 Gbps (IPv6, 1518 byte UDP)
IPS Throughput	9 Gbps
Interfaces	10x GE RJ45 (including 1x MGMT port, 1x HA port, 8x switch ports), 8x 5/2.5/GE RJ45, 8x 10GE SFP+/SFP FortiLink slots (default), 4x GE SFP slots
Power Input	100–240V AC, 50/60Hz
Dimensions (H x W x L)	1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm)
Weight	14.11 lbs (6.4 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Compliance / Certification	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6

[/properties]

[specifications]

System Performance — Enterprise Traffic Mix
NGFW Throughput	7 Gbps
Threat Protection Throughput	6 Gbps
IPv4 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
IPv6 Firewall Throughput (1518/512/64 byte, UDP)	39 / 39 / 26.5 Gbps
Firewall Latency (64 byte, UDP)	4.36 μs
Firewall Throughput (Packet per Second)	39.75 Mpps
IPsec VPN Throughput (512 byte)	36 Gbps
SSL-VPN Throughput	3 Gbps
SSL Inspection Throughput (IPS, avg. HTTPS)	7 Gbps
Application Control Throughput (HTTP 64K)	27.8 Gbps
CAPWAP Throughput (HTTP 64K)	37.5 Gbps
System Capacity
Concurrent Sessions (TCP)	11 Million
New Sessions/Second (TCP)	400,000
Firewall Policies	10,000
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	16,000
Concurrent SSL-VPN Users (Recommended Max)	500
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	900,000
Virtual Domains (Default/Maximum)	10 / 25
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total/Tunnel)	256 / 128
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Hardware & Interfaces
GE RJ45 Ports	8
GE RJ45 Management / HA Ports	1 / 1
5/2.5/GE RJ45 Ports	8
10GE SFP+/SFP FortiLink Slots (default)	8
GE SFP Slots	4
USB Port	1
Console Port	1
Trusted Platform Module (TPM)	Yes
Included Transceivers	0
Dimensions & Environment
Power Supply	Dual built-in non-hot swappable AC PSU
AC Current (Maximum)	2A @ 100VAC, 1.2A @ 240VAC
Power Consumption (Average / Maximum)	145 W / 175 W
Heat Dissipation	597.12 BTU/h
Storage Temperature	-31°F to 158°F (-35°C to 70°C)
Humidity	5% to 90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Forced Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)

[/specifications]

[accesories]

Optional Accessories (Sold Separately)
Transceivers	1 GE SFP SX (FN-TRAN-SX), 1 GE SFP LX (FN-TRAN-LX), 10 GE SFP+ RJ45 (FN-TRAN-SFP+GC), 10 GE SFP+ SR (FN-TRAN-SFP+SR), 10 GE SFP+ LR (FN-TRAN-SFP+LR), 10 GE SFP+ ER (FN-TRAN-SFP+ER), 10 GE SFP+ ZR 80km (FN-TRAN-SFP+ZR), 10 GE SFP+ BiDi 30km (FN-TRAN-SFP+BD27 and FN-TRAN-SFP+BD33), 25 GE SFP28 SR (FN-TRAN-SFP28-SR)
Cables	10 GE SFP+ Passive Direct Attach Cable 1m (FN-CABLE-SFP+1), 3m (FN-CABLE-SFP+3), 5m (FN-CABLE-SFP+5)

[/accesories]

The Fortinet FortiGate 200G Series next-generation firewall (NGFW) combines artificial intelligence (AI)-powered security and machine learning (ML) to deliver threat protection at any scale. Powered by a rich set of AI/ML security capabilities that extend into an integrated security fabric platform, the FortiGate 200G Series delivers secure networking that is broad, deep, and automated. This security fabric seamlessly extends across your entire environment, ensuring consistent policy enforcement and threat protection across all network segments. The FG-200G-BDL-809-60 bundle includes FortiCare Premium and FortiGuard Enterprise Protection for 5 years.

At the core of the FortiGate 200G are Fortinet’s patented SPU processors, including the NP7Lite network processor and CP10 content processor. These dedicated processors offload resource-intensive tasks to deliver high performance, including 9 Gbps of IPS throughput and 6 Gbps of Threat Protection throughput. With integrated capabilities for universal zero-trust network access (ZTNA) and secure SD-WAN, the FortiGate 200G reduces complexity and risk in hybrid IT networks while maintaining ultra-low latency for critical applications.

Secure Networking with AI-Powered Threat Protection

• High-Performance Security: Delivers up to 39 Gbps firewall throughput with ultra-low latency (4.36 μs) powered by NP7Lite and CP10 acceleration.
• AI-Powered Protection: Uses AI/ML-powered security services to protect against modern attack vectors, including unknown and zero-day threats.
• Deep Visibility: Provides visibility into applications, users, and devices with real-time SSL inspection (including TLS 1.3) without impacting performance.
• Integrated SD-WAN: Delivers secure SD-WAN with unified security and management for WAN edge transformation and operational efficiency.
• Scalable Segmentation: Supports dynamic segmentation and low-latency VXLAN segmentation to reduce complexity and help prevent lateral movement across the network.
• Universal ZTNA: Automatically controls, verifies, and facilitates user access to applications with consistent access policy enforcement.
• Hardware-Backed Security: Includes a Trusted Platform Module (TPM) designed to harden the appliance by generating, storing, and authenticating cryptographic keys.

• Next Generation Firewall (NGFW): Secures web, content, and devices with AI-powered security services and deep visibility beyond traditional firewall techniques.
• Secure SD-WAN: Unifies networking and security to transform and secure WANs with a unified framework for hybrid working models and cloud-first WAN use cases.
• Universal ZTNA: Controls access to applications regardless of user location or application hosting, enforcing policy prior to granting access.
• Segmentation: Enables dynamic segmentation and VXLAN segmentation to deliver end-to-end security across hybrid environments and multi-cloud networks.
• Hybrid Mesh Firewall Architecture: Supports consistent policy enforcement and threat protection across all network segments in distributed environments.

• Firewall Performance: IPv4/IPv6 throughput (1518/512/64 byte UDP) 39 / 39 / 26.5 Gbps; latency (64 byte UDP) 4.36 μs; 39.75 Mpps.
• Security Throughput: IPS (Enterprise Mix) 9 Gbps; NGFW 7 Gbps; Threat Protection 6 Gbps.
• VPN & SSL: IPsec VPN (512 byte) 36 Gbps with 2,000 site-to-site and 16,000 client tunnels; SSL-VPN 3 Gbps with 500 recommended concurrent users; SSL inspection (IPS, avg. HTTPS) 7 Gbps with 900,000 concurrent sessions.
• Interfaces: 10x GE RJ45 (including 1x MGMT port, 1x HA port, 8x switch ports), 8x 5/2.5/GE RJ45, 8x 10GE SFP+/SFP FortiLink (default), 4x GE SFP, plus USB and console.
• Capacity: 11 million concurrent sessions; 400,000 new sessions/second; 10,000 firewall policies; VDOMs 10 (default) / 25 (max).
• Power & Thermal: 100–240V AC input; 145 W average / 175 W max; heat dissipation 597.12 BTU/h; dual built-in non-hot swappable AC PSU (1+1 redundancy).
• Physical/Environment/Certs: 1 RU (1.75 x 17.0 x 15.0 in / 44.45 x 432 x 380 mm), 14.11 lbs (6.4 kg); operating 0°C to 40°C; humidity 5%–90% non-condensing; compliance includes FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; certification USGv6/IPv6.

Upgrade Your Network Security

Equip your enterprise with the AI-driven performance of the FG-200G-BDL-809-60 today.
