[shortdesc] Wi-Fi 6E tri-radio ruggedized indoor/outdoor access point with 2.4 GHz, 5 GHz, and 6 GHz bands, 10 Gigabit Ethernet uplink, IP67 enclosure, Bluetooth LE and Zigbee support. [/shortdesc].

[properties]

Model	FortiAP 432G
SKU	FAP-432G-A
Product Type	Ruggedized Indoor/Outdoor Wireless Access Point
Wi-Fi Standard	Wi-Fi 6E (IEEE 802.11ax)
Frequency Bands	2.4 GHz, 5 GHz, 6 GHz
Radio Architecture	Tri-radio (3 + 1 BLE)
Spatial Streams	4x4 per client serving radio
Antenna Type	External
Number of Antennas	9 Total N-Type: 8 Wi-Fi antennas plus 1 BLE/scan antenna
Ethernet Interfaces	1 × 10GBase-T RJ45 (10G/5G/2.5G/1G/100M), 1 × Gigabit RJ45
PoE Support	IEEE 802.3bt (PoE in on 10G port)
Bluetooth / IoT	Bluetooth LE, Zigbee
Management Interface	RS-232 RJ45 Serial Port
Mounting Options	Wall mount, Pole mount
Ingress Protection	IP67
Indoor / Outdoor	Ruggedized Indoor/Outdoor

[/properties]

[specifications]

Maximum Data Rate (2.4 GHz)	Up to 1148 Mbps
Maximum Data Rate (5 GHz)	Up to 2402 Mbps
Maximum Data Rate (6 GHz)	Up to 4804 Mbps
Total Aggregate Throughput	8.35 Gbps
Wireless Protocols	802.11a/b/g/n/ac/ax
MIMO Technology	MU-MIMO, OFDMA
Simultaneous SSIDs	Up to 8 per client serving radio (7 if background scanning is enabled)
Client Capacity	Up to 512 clients per radio
Encryption Standards	WPA, WPA2, WPA3, WEP
Authentication Methods	EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-FAST, EAP-SIM, EAP-AKA, EAP-TTLS/PAP
Power Consumption (Max.)	41.2 W
Operating Temperature	-40 F to 140 F (-40 C to 60 C)
Operating Humidity	5% to 90% non-condensing
Dimensions (H × W × D)	2.74 × 9.45 × 9.45 in
Weight	7.05 lb
Compliance	FCC, CE, RoHS, Wi-Fi Alliance Certified

[/specifications]

[accesories]

Included

FortiAP 432G unit, External N-Type antennas, Integrated antenna mounting bracket, Mounting kit (wall/pole) included in the box, 60W PoE injector with reset switch included in the box

[/accesories]

Enterprise-Grade Wi-Fi 6E for Demanding Outdoor Environments

The Fortinet FortiAP-432G is a high-performance ruggedized indoor/outdoor wireless access point engineered for high-density, mission-critical deployments. Built on Wi-Fi 6E technology, it delivers tri-band connectivity across 2.4 GHz, 5 GHz, and 6 GHz to reduce congestion and maximize spectrum efficiency. Designed for seamless integration with the Fortinet Security Fabric, the FortiAP-432G extends enterprise-class security and performance directly to the wireless edge.

Key Benefits & Features

• Tri-Radio Wi-Fi 6E Architecture: Three dedicated client serving radios deliver high-capacity coverage across the 2.4 GHz, 5 GHz, and 6 GHz bands.
• High-Speed Wired Connectivity: Integrated 10GBase-T Ethernet uplink helps eliminate bottlenecks in bandwidth-intensive environments.
• Rugged Outdoor Design: IP67-rated enclosure helps protect against dust, water, and harsh environmental conditions for reliable operation.
• Advanced IoT Integration: Built-in Bluetooth LE and Zigbee radios support locationing applications and IoT connectivity.
• Enterprise-Grade Wireless Security: Supports WPA3 and advanced EAP options for secure authentication in enterprise networks.

Ideal Use Cases

• Outdoor enterprise campuses and corporate facilities
• Manufacturing plants and industrial sites
• Smart city and public infrastructure deployments
• Large venues requiring high-density outdoor Wi-Fi
• IoT-driven environments with location and sensor integration

Technical Specifications

• Wireless Standard: IEEE 802.11ax Wi-Fi 6E
• Frequency Bands: 2.4 GHz, 5 GHz, and 6 GHz
• Maximum Throughput: Up to 1148 Mbps at 2.4 GHz, 2402 Mbps at 5 GHz, and 4804 Mbps at 6 GHz
• Spatial Streams: 4x4 per client serving radio
• Ethernet Ports: 1x 10GBase-T RJ45, 1x Gigabit Ethernet RJ45
• Power: Power over Ethernet (802.3bt) support
• Environmental Rating: IP67 ruggedized indoor/outdoor
• Client Capacity: Up to 512 clients per radio

Build a Future-Ready Outdoor Wireless Network

Deploy secure, high-capacity Wi-Fi with the Fortinet FortiAP-432G and scale confidently as demands grow. Order today.
