[shortdesc] Wi-Fi 7 tri-band 2.4 5 6 GHz, 2x2 spatial streams, 10G uplink, PoE PSE port, Bluetooth LE Zigbee [/shortdesc]

[properties]

Model	FortiAP-23JK
SKU	FAP-23JK-A
Product Type	Wireless Access Point (Wall Plate)
Wireless Standard	Wi-Fi 7 (IEEE 802.11be)
Frequency Bands	2.4 GHz, 5 GHz, 6 GHz
Spatial Streams	2x2 MU-MIMO
Radio Configuration	Tri-band (3 Wi-Fi Radios) + BLE/Zigbee
Maximum Throughput	688 Mbps (2.4 GHz), 2.88 Gbps (5 GHz), 5.76 Gbps (6 GHz)
Ethernet Interfaces	1 x 10GbE RJ45 (WAN/PoE), 2 x 1GE RJ45 (LAN), 1 x RJ45 Pass-through
PoE Support	Input: 802.3bt (Preferred), Output: 1x 802.3af PSE
IoT Technologies	Bluetooth Low Energy (BLE), ZigBee
Antenna Type	Internal
Mounting	Wall plate mountable
Color	White
Dimensions (H × W × D)	1.6 × 4.7 × 7.1 in
Weight	18.34 oz
Operating Temperature	0 °C to 45 °C (32 °F to 113 °F)
Region Code	A

[/properties]

[specifications]

Wireless LAN Standards	802.11a/b/g/n/ac/ax/be, Wi-Fi Certified 7
Modulation	BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM, OFDMA
MIMO Technology	2x2 MU-MIMO (uplink/downlink)
Authentication	EAP-AKA, EAP-FAST, EAP-GTC, EAP-SIM, EAP-TLS, EAP-TTLS, PEAPv0, PEAPv1, MS-CHAP v2
Encryption	WEP, WPA, WPA2, WPA3, TLS, TTLS
Security Features	WIDS, WIPS, Rogue AP detection, MAC filtering, Captive Portal
Processor	ARM Cortex-A53, 1.5 GHz
Memory	2 GB RAM
Maximum SSIDs	Up to 24
Wireless Clients	Up to 512 per Wi-Fi radio
Status Indicators	Power, WAN, Wi-Fi
Operating Humidity	5% to 90% non-condensing
Certifications	FCC, RoHS, UL 2043, EU Low Voltage Directive

[/specifications]

[accesories]

Included

Wall plate mounting kit included in the box

[/accesories]

Wall-Integrated Wi-Fi 7 Performance for Modern Indoor Networks

The Fortinet FortiAP-23JK Wall Plate Access Point is designed for high-density indoor deployments where performance, aesthetics, and flexibility matter. Built on Wi-Fi 7 technology, it delivers multi-gigabit wireless speeds while blending seamlessly into wall-mounted installations such as offices, hotels, classrooms, and residential units. With integrated switching ports and IoT radios, it reduces cabling complexity while extending secure connectivity to users and devices.

Key Benefits & Features

• Wi-Fi 7 tri-band architecture: Operates across 2.4 GHz, 5 GHz, and 6 GHz bands with 2x2 spatial streams per band for improved capacity and reduced latency.
• Integrated multi-port wall plate design: Includes one 10G Ethernet uplink, two active Gigabit Ethernet ports, and one RJ-45 pass-through port. One active port supports 802.3af PoE PSE to power downstream devices.
• High-density client handling: Supports up to 24 configured SSIDs and up to 512 clients per radio, optimized for shared environments.
• Built-in IoT radio support: Bluetooth Low Energy and Zigbee radios enable direct integration with IoT sensors and smart building devices.
• Enterprise wireless security: Features WIDS and WIPS, rogue AP detection, WPA3 support, and advanced authentication methods for secure access.

Ideal Use Cases

• Hotel rooms and hospitality guest networks
• Enterprise offices and meeting spaces
• University dormitories and classrooms
• Healthcare and clinical environments
• Smart buildings with IoT device integration

Technical Specifications

• Wireless standard: Wi-Fi 7 (IEEE 802.11be)
• Frequency bands: 2.4 GHz, 5 GHz, 6 GHz
• Maximum throughput: 688 Mbps (2.4 GHz), 2.88 Gbps (5 GHz), 5.76 Gbps (6 GHz)
• Ethernet interfaces: 1 x 10G RJ45 (Uplink), 2 x 10/100/1000 RJ45 (LAN), 1 x Pass-through
• PoE support: 802.3bt Input recommended; 1 x 802.3af PoE PSE output port
• IoT connectivity: Bluetooth 5.2 LE, Zigbee
• Antenna type: Internal antennas
• Mounting: Wall plate mounting kit included
• Form factor: Indoor wall mountable access point
