Mikrotik CRS504-4XQ-IN Switch
- Your most affordable, compact, energy-efficient doorway to the world of 100 Gigabit networking. This switch is the next step in upgrading existing 10 or 25 Gigabit networks. Multiple powering options, dual hot-swap power supplies.
[properties]
| Properties | MikroTik CRS504-4XQ-IN |
| Description | Your most affordable, compact, energy-efficient doorway to the world of 100 Gigabit networking. This switch is the next step in upgrading existing 10 or 25 Gigabit networks. Multiple powering options, dual hot-swap power supplies |
| Product Family | CRS Series |
| Product Type | Ethernet Switch |
| Ports | |
| 10/100 Ethernet ports | 1 |
| 100G QSFP+ | 4 |
| Serial console port | 1 RJ45 |
| Extras | CPU temperature monitor PCB temperature monitor Voltage Monitor |
| Dimensions | 320 x 185 x 44 mm |
| Number of AC inputs | 2 |
| AC input range | 100-240 |
| Number of DC inputs | 3 (DC jack, PoE-IN, 2-pin terminal) |
| DC jack input Voltage | 36-57 V |
| 2-pin terminal input Voltage | 36-57 V |
| Frequency (Hz) | 47-63 |
| Max power consumption | 41 W |
| Max power consumption without attachments | 25 W |
| Cooling type | 2 fans |
| PoE in input Voltage | 43-57 V Passive poe or 802.3bt Class 6 |
[/properties][specifications]
| Specifications | CRS504-4XQ-IN |
| Memory | 64 MB |
| Flash Storage size | 16 MB |
| CPU | QCA9531 650 MHz |
| CPU core count | 1 |
| Switch chip model | 98DX4310 |
| OS | RouterOS (v7 only) |
| MTBF | Approximately 200.000 hours at 25C |
| Temperature | -40°C to 70°C tested |
| Certification & Approvals | |
| Certification | CE, EAC, ROHS |
| IP | IP20 |
[/specifications][accesories]
| Accessories |
| 2 x IEC cords |
| Rack ears (CRS504) |
| K10 screw kit |
[/accesories]
MikroTik CRS504-4XQ-IN Switch
The CRS504-4XQ-IN switch has been specifically engineered to cater to the needs of data centers, internet service providers, and contemporary infrastructures, providing a 100 Gigabit networking capacity. This enhanced speed attribute is of paramount importance as organizations manage increasing volumes of data and devices, necessitating swift data transmission rates.
Quick Specs:
- 1x 100 Mbit Ethernet Port
- 4x 100G QSFP28 Ports
- Dual Hot-Swap Power Supplies
- RouterOS v7
Please see the related tabs for the CRS504-4XQ-IN datasheet and compatible accessories.
