Mikrotik CRS309-1G-8S+IN Switch

Product image 1
Product image 2
Product image 3

Mikrotik CRS309-1G-8S+IN Switch

Mikrotik CRS309-1G-8S+IN Switch

[shortdesc]
  • Desktop switch with one Gigabit Ethernet port and eight SFP+ 10Gbps ports
[/shortdesc]

[properties]

Properties MikroTik CRS309-1G-8S+IN
Description Desktop switch with one Gigabit Ethernet port and eight SFP+ 10Gbps ports
Product Family CRS Series
Product Type Ethernet Switch
Ports
10/100/1000 Ethernet ports 1
10G SFP+ ports 8
Serial port RS232
Extras CPU temperature monitor, Beeper
Dimensions 272 x 191 x 44 mm
PoE in Yes, Passive POE and 802.3af/at compliant
Number of DC inputs 1
DC jack input Voltage 12 - 57 V
Cooling type Passive
Max power consumption 23 W / 17 W (without attachemnts)
PoE in input Voltage 18-57 V

[/properties][specifications]

Specifications CRS309-1G-8S+IN
Memory 512 MB
Flash Storage size 16 MB
CPU 98DX3236 800 MHz
CPU core count 2
Switch chip model 98DX8208
OS RouterOS / SwitchOS
MTBF Approximately 200.000 hours at 25C
Temperature -40°C to 70°C tested
Certification & Approvals
Certification CE, EAC, ROHS
IP IP20

[/specifications][accesories]

Accessories
Power adapter 24 V 1.2 A
Screw kit
Rack ears

[/accesories]

MikroTik CRS309-1G-8S+IN Switch

The CRS309-1G-8S+IN is a highly efficient networking switch with a small form factor. It is equipped with eight SFP+ slots, allowing for the installation of 10 Gbit modules in each slot. This configuration enables a total switching capacity of 162 Gbps and a non-blocking throughput of 81 Gbps. The device is equipped with a dual-core 800 MHz CPU, 512 MB RAM, a management Ethernet port with PoE power input, RS232 serial port, a grounding terminal, and supports dual boot functionality, allowing users to select their preferred operating system between RouterOS and SwOS.

Quick Specs:

  • 1 Gigabit Ethernet ports
  • 8x 10G SFP ports
  • Passive PoE and 802.3 af/at compliant

Please see the related tabs for the CRS309-1G-8S+ datasheet and compatible accessories.

$92.75

Original: $265.00

-65%
Mikrotik CRS309-1G-8S+IN Switch—

$265.00

$92.75
