[shortdesc]

• 12 ports, SFP28, Modular Uplinks, Network Advantage

[/shortdesc]



[properties]

Properties	C9300X-12Y-A
Description	Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage
Product Family	Cisco Catalyst 9300 Series Switches
Product Type	Switch

 [/properties] [specifications]

Specifications	C9300X-12Y-A
Product Family Configurations (Catalyst 9300X)
Modular Uplinks and Speeds	10G, 25G, 40G, mGig and 100G
Stacking Bandwidth Support	Stackwise-1T (480G when stacking with Catalyst 9300 model)
mGig Density	48x 10G
Cisco StackPower	48x 10G
Cisco StackPower	✓ (Larger Power Budget)
HW-Based Ipsec	Up to 100G Ipsec (Need to order HSEC Key for IPsec Feature.)
App hosting Capacity	✓ (2x hosting resources over Catalyst 9300 models)
Cisco C9300X-12Y  Switch Configurations
Total 10/100/1000, Multigigabit copper or SFP Fiber	12 port 25G/10G/1G SFP28
Uplink Configuration	Modular Uplinks
Default AC power supply	715W AC
Primary Power Supply	PWR-C1-715WAC-P
Default or Upgrade	Default
Available PoE	No POE
With 350W Secondary PS	No POE
With 715W secondary PS	No POE
With 1100W Secondary PS	No POE
With 1900W Secondary PS	No POE
Bandwidth specifications - C9300X-12Y
Switching capacity	1,000 Gbps
Switching capacity with stacking	2,000 Gbps
Forwarding rate	744.04 Mpps
Forwarding rate with stacking	1488 Mpps
General Specifications - C9300X-12Y
Dimensions (H x W x D) inches	Chassis only: 1.73 x 17.5 x 16.1 W/ Default Power Supply: 1.73 x 17.5 x 17.6 W/ 1100W Power Supply: 1.73 x 17.5 x 19.2
Dimensions (H x W x D) Cms	Chassis only: 4.4 x 44.5 x 40.9 W/ Default Power Supply: 4.4 x 44.5 x 44.7 W/ 1100W Power Supply: 4.4 x 44.5 x 48.8
Weight (with default power supply)	Pounds: 15.0 Kilograms: 6.80
Mean Time Between Failures – MTBF (hours)	265,650

[/specifications] [accesories] [/accesories]

Cisco Catalyst C9300X-12Y-A Switch

The Cisco Catalyst C9300X-12Y-A Switch is a high-performance network solution tailored for enterprises that demand robust security, enhanced speed, and scalable network architecture. Equipped with 12 Multigigabit Ethernet ports and support for 10G/25G uplinks, this Layer 3 switch is ideal for organizations requiring fast and reliable data transfer alongside comprehensive network management. The C9300X-12Y-A integrates advanced security features and flexible uplink options, ensuring your network is prepared for future growth.

Key Features:

• 12 x Multigigabit Ethernet Ports: Supports various speeds (100M, 1G, 2.5G, 5G, 10G) per port, ensuring high-speed and adaptable network performance.
• Modular Uplinks: Equipped with 10G/25G uplink options, offering flexibility and scalability for growing network demands.
• Advanced Layer 3 Routing: Includes support for OSPF, EIGRP, and BGP, providing sophisticated routing and traffic management.
• StackWise-480 Technology: Provides up to 480 Gbps of stacking bandwidth, ensuring high availability and simplified management across multiple switches.
• Energy-Efficient Design: Compliant with IEEE 802.3az standards, reducing power consumption while maintaining high network performance.
• Enhanced Security: Features MACsec encryption and advanced access control lists (ACLs) to protect against unauthorized access.

Technical Overview:

• Recommended for: Enterprise environments, large campuses, and data centers requiring scalable network infrastructure.
• Ports: 12 x Multigigabit Ethernet ports (100M, 1G, 2.5G, 5G, 10G) with modular uplinks supporting 10G/25G.
• Switching Capacity: 480 Gbps.
• Forwarding Rate: 357.14 Mpps.
• Layer 3 Features: OSPF, EIGRP, BGP, VLANs, and ACLs for advanced network control.
• Management: Web-based GUI, CLI, SNMP, and Cisco DNA Center for comprehensive network automation and monitoring.
• Licensing: Network Advantage.
• Security: MACsec encryption and advanced ACLs for enhanced security.
• Energy Efficiency: Meets IEEE 802.3az standards for energy-efficient operation.

You can check the related tab for the C9300X-12Y-A datasheet.
