[shortdesc] 16-port Gigabit RJ45 managed switch, 2 dedicated Gigabit SFP uplinks, Layer 3 routing, 36 Gbps switching capacity, fanless design for quiet rack-mount operation [/shortdesc]

[properties]

Model	Cisco Catalyst C1300-16T-2G
Product Type	Managed Layer 3 Gigabit Ethernet Switch
Total System Ports	18 x Gigabit Ethernet
RJ-45 Ports	16 x Gigabit Ethernet
Uplink Ports	2 x Gigabit SFP
PoE Support	No PoE
Switching Capacity	36 Gbps
Forwarding Rate	26.78 mpps
Packet Buffer	1.5 MB
MAC Address Table	16,000 addresses
Jumbo Frames	Up to 9000 bytes
Flash	1 GB SLC
CPU	ARM dual-core at 1.5 GHz
DRAM	1 GB DDR4
Power	100-240V, 50-60 Hz, internal universal power supply
Dimensions (W x D x H)	268 x 272 x 43.94 mm (10.55 x 10.69 x 1.73 in)
Weight	2.18 kg (4.80 lb)
Fan	Fanless
MTBF	912,776 hours at 25 degrees C
Rack Mountable	Yes

[/properties]

[specifications]

Layer 2 Features	802.1d STP, 802.1w RSTP, 802.1s MSTP, PVST+, RPVST+, 802.3ad LACP, VLAN, Voice VLAN, Multicast TV VLAN, Q-in-Q, Selective Q-in-Q, GVRP, GARP, UDLD, DHCP relay at Layer 2
VLAN Support	Up to 4094 VLANs; port-based, 802.1Q tag-based, MAC-based, protocol-based, and IP subnet-based VLANs
Layer 3 Features	Wire-speed IPv4 and IPv6 routing, Layer 3 interface, CIDR, RIP v2, Policy-Based Routing, DHCP server, DHCP relay at Layer 3, UDP relay
IPv4 Routes	Up to 990 dynamic and static IPv4 routes; up to 128 IP interfaces
Security	SSH v1/v2, SSL, IEEE 802.1X, web-based authentication, BPDU Guard, Root Guard, DHCP snooping, IP Source Guard, Dynamic ARP Inspection, IP/MAC/port binding, port security, RADIUS, TACACS+, storm control, DoS prevention
Access Control Lists	Up to 1024 rules; time-based ACLs supported
Quality of Service	8 hardware queues, strict priority, Weighted Round-Robin, port-based and 802.1p VLAN priority-based QoS, DSCP-based classification, rate limiting, iSCSI traffic optimization
IPv6 Support	IPv6 host mode, IPv6 over Ethernet, dual IPv6/IPv4 stack, IPv6 neighbor and router discovery, stateless address auto-configuration, DHCPv6 stateful client, IPv6 First Hop Security
Management	Cisco Business Dashboard, Cisco Business mobile app, Cisco Network Plug and Play, web user interface, SNMP v1/v2c/v3, CLI, RMON, sFlow, SCP, Smartports, Auto Smartports
Discovery Protocols	Bonjour, LLDP with LLDP-MED, Cisco Discovery Protocol
Console Port	Cisco standard RJ-45 console port and USB Type-C port
USB Port	USB Type-C port on the front panel for file and image management and console access
Buttons	Reset button
Cabling Type	UTP Category 5e or better for 1000BASE-T
LEDs	System, Link/Act, PoE, Speed
Power Consumption	System power consumption 110V=10.9W, 220V=11.2W; idle power 110V=4.6W, 220V=4.9W
Heat Dissipation	38.2 BTU/hr
Operating Temperature	23 degrees F to 122 degrees F (-5 degrees C to 50 degrees C); minimum ambient temperature for cold start is 32 degrees F (0 degrees C)
Storage Temperature	-13 degrees F to 158 degrees F (-25 degrees C to 70 degrees C)
Operating Humidity	10 percent to 90 percent, relative, noncondensing
Storage Humidity	10 percent to 90 percent, relative, noncondensing
Certifications	UL 62368, CSA 22.2, CE mark, FCC Part 15 Class A

[/specifications]

[accesories]

Included	Cisco Catalyst 1300 Series Switch; power cord included unless NO-POWER-CORD is selected while ordering; pointer card
Rack Mounting	RCKMNT-CMPCT-1K= 19-in. rack-mount bracket for C1000, C1200, C1300, compatible with all 8/12/16 port models
Console Cables	CAB-CONSOLE-RJ45 Console cable 6 feet with RJ-45; CAB-CONSOLE-USB-C Console cable USB-C type; CAB-CONSOLE-USB-C= Console cable USB-C type
Power Accessories	PWR-CLP Power cable restraining clip

[/accesories]

Build a Reliable Gigabit Network for Branch and SMB Teams

The Cisco Catalyst C1300-16T-2G provides small business and branch office networks with a secure, high-performance managed Gigabit switching foundation. Designed for simplicity and scalability, this managed Layer 3 switch integrates 16 copper Gigabit Ethernet ports and 2 dedicated Gigabit SFP uplinks to deliver dependable office connectivity for servers, workstations, and network devices.

Featuring wire-speed, nonblocking performance and comprehensive Cisco management, this switch enables IT teams to streamline monitoring, secure traffic, and maintain efficient network operations without unnecessary complexity.

Key Benefits & Features

• 16-Port Gigabit Access: High-speed connectivity for desktops, printers, and workstations via 16 10/100/1000 RJ45 Ethernet ports.
• Dedicated Fiber Uplinks: 2 Gigabit SFP ports provide flexible, high-bandwidth uplink connectivity to aggregation switches or core routers.
• Managed Layer 3 Control: Supports advanced routing features, including static and dynamic IPv4/IPv6 routing, VLAN segmentation, and complex ACLs for enhanced traffic management.
• Simplified Management: Deploy and manage your network via Cisco Business Dashboard, the intuitive mobile app, Web UI, CLI, or Cisco Network Plug and Play.
• Quiet Office Deployment: Fanless operation combined with a compact, rack-mountable form factor makes this switch ideal for open-plan offices, classrooms, and retail environments.

Ideal Use Cases

• Small to medium-sized business (SMB) network access and distribution
• High-performance connectivity for branch office servers and users
• Secure guest network isolation via VLANs and ACLs
• Quiet, low-maintenance deployment in office or classroom settings
• Cost-effective managed Layer 3 Gigabit Ethernet scaling

Technical Specifications

• Model: Cisco C1300-16T-2G
• Total System Ports: 18 x Gigabit Ethernet
• RJ45 Ports: 16 x 10/100/1000 Gigabit Ethernet
• Uplink Ports: 2 x Gigabit SFP
• Switching Capacity: 36 Gbps
• Forwarding Rate: 26.78 mpps
• Layer Support: Managed Layer 3 switching with IPv4 and IPv6 routing
• VLAN Support: Up to 4094 VLANs
• Packet Buffer: 1.5 MB
• Dimensions: 268 x 272 x 43.94 mm
• Weight: 2.18 kg
• Power: Internal 100 to 240V AC, 50 to 60 Hz
• Cooling: Fanless design

Upgrade Your Access Layer with Cisco

Choose the Cisco Catalyst C1300-16T-2G for secure, manageable Gigabit switching built to support the demands of growing business networks. Order today.
