• Cisco C1200-8P-E-2G is an 8-port Gigabit PoE+ smart switch with two Gigabit copper/SFP combo uplinks, a 67W PoE budget, and silent fanless operation—ideal for compact SMB networks

[/shortdesc]

[properties]

Property	Details
Product Line	Cisco Catalyst 1200 Series
Model	C1200-8P-E-2G
Switch Type	Smart managed, Layer 2 with basic Layer 3 (static routing)
Downlink Ports	8 × 10/100/1000BASE-T (RJ-45) with PoE+
Uplink Ports	2 × Gigabit copper/SFP combo (one active per combo)
PoE Budget	67W total (up to 30W per port, 802.3af/at)
Form Factor	Compact 1U; desktop or rack-mountable
Cooling	Fanless (silent)
Dimensions (W × D × H)	268 × 185 × 44 mm (10.56 × 7.28 × 1.73 in)
Unit Weight	1.53 kg (3.37 lb)
Power Input	AC 100–240 V, 50/60 Hz (internal PSU)
Max Power Consumption	≈87.9 W @110 V with PoE (≈84.9 W @220 V)

[/properties]

[specifications]

Specification	Details
PoE Standards	IEEE 802.3af/at (PoE+); Perpetual PoE support
Layer 3 Functions	Static IPv4 routing (typical: up to 32 routes / 16 interfaces), inter-VLAN routing
Layer 2 / QoS	VLANs, IGMP snooping, 802.1p/DSCP QoS, 8 hardware queues
Security	802.1X, ACLs, port security, DHCP snooping, DoS protection
Management	Web GUI, CLI, Cisco Business Dashboard, SNMP, SSH
Jumbo Frames	Up to 9000 bytes
MAC Address Table	8,000 entries
Packet Buffer	1.5 MB (shared)
Operating Temperature	0°C to 50°C (32°F to 122°F)

[/specifications]

[accesories]

Accessory	Details
CAB-CONSOLE-RJ45	Console cable, 6 ft, RJ-45
CAB-CONSOLE-USB-C / CAB-CONSOLE-USB-C=	USB-C console cable
PWR-CLP	Power cable restraining clip
RCKMNT-CMPCT-1K=	Compact 19″ rack-mount kit for 8/16-port models
PWRADPT-WM-18-xx / PWRADPT-WM-18-NA=	18W power adapter (regional variants)

[/accesories]

Cisco Catalyst C1200-8P-E-2G 8-Port PoE+ Fanless Switch

The Cisco C1200-8P-E-2G is a compact, silent smart switch built for small offices, retail sites, and edge deployments that need reliable PoE+ power and simple management. Eight Gigabit PoE+ ports deliver power and data to IP phones, access points, and cameras, while two Gigabit combo uplinks (RJ-45/SFP) provide flexible backhaul to aggregation or fiber runs. With a 67W PoE budget, intuitive web and mobile management, and essential Layer 3 static routing for inter-VLAN traffic, this fanless 1U switch is an efficient foundation for secure, space-constrained networks.

Key Features

• Compact PoE+ delivery: 8 × 1G RJ-45 PoE+ ports sized for small sites and edge closets.
• Flexible uplinks: 2 × Gigabit copper/SFP combo ports for fiber or copper backhaul.
• Silent design: Fanless operation for noise-sensitive environments.
• Built-in security: 802.1X, ACLs, DHCP snooping, and DoS protection for safe access.
• Simplified control: Manage via web GUI, CLI, or Cisco Business Dashboard.
• Inter-VLAN routing: Basic Layer 3 static routing to segment and steer traffic.

Technical Overview

• PoE budget: 67W total; up to 30W per port (802.3af/at).
• Combo uplinks: Each combo has 1 × RJ-45 + 1 × SFP (one active at a time).
• Hardware profile: Fanless, compact 1U chassis for desktop or rack use.
• Throughput & buffers: 8k MAC table, 1.5 MB shared buffer, jumbo frames to 9kB.
• Physicals: 268 × 185 × 44 mm; 1.53 kg.
• Power draw (worst case): ≈87.9 W @110 V with PoE active.
