[shortdesc]

2U Switched PDU, 30A 120V Input, 16 NEMA 5-20R Outlets, Horizontal Mount, Remote Control & Monitoring

[/shortdesc]

[properties]

Brand	APC by Schneider Electric
Model	AP7902B
Product Type	NetShelter Switched Rack PDU
Form Factor	Rackmount 2U
Dimensions (H x W x D)	3.5" x 17.5" x 4.5" (89 x 445 x 114 mm)
Weight	9.9 lb (4.5 kg)
Color	Black
Number of Rack Units	2U
Mounting Mode	Rack-mounted (Horizontal)
Cooling	Not specified

[/properties]

[specifications]

PDU Type	Switched
Input Voltage	100–120 V
Output Voltage	120 V
Input Plug Type	NEMA L5-30P
Input Frequency	50/60 Hz
Line Rated Current	24 A (Max 30 A)
Load Capacity	2880 VA
Outlets	16 × NEMA 5-20R
Communication Ports	Not specified
Operating Temperature	32–113 °F (0–45 °C)
Storage Temperature	-13–149 °F (-25–65 °C)
Operating Humidity	0–95%
Storage Humidity	0–95%
Operating Altitude	0–10,000 ft
Storage Altitude	0–50,000 ft
Compliance	cUL Listed, CSA, Industry Canada, UL Listed, FCC Part 15 Class A, ICES-003, UL 60950, RoHS, REACh
Warranty	2 years repair or replace

[/specifications]

[accessories]

Cord Retention Brackets	Included in the box
Horizontal Mounting Brackets	Included in the box
User Manual	Included in the box
Installation Guide	Included in the box

[/accesories]

Overview

The APC AP7902B Switched Rack PDU is designed to provide reliable, high-density power distribution with remote on/off outlet control. Built for demanding IT environments, this 2U horizontal PDU supports up to 30A at 120V with 16 managed outlets. Engineered for efficiency, it allows administrators to monitor load levels, optimize usage, and control devices remotely for maximum uptime and operational flexibility.

Key Features & Benefits

• Switched Control: Individual outlet management enables remote power cycling and equipment reboot.
• High Capacity Design: 30A, 120V input delivers 2880 VA load capacity to critical equipment.
• 16 NEMA 5-20R Outlets: Supports multiple servers, storage, and networking devices in a rack.
• Rack-Mount Form Factor: 2U horizontal design fits seamlessly into standard enclosures.
• Load Monitoring: Provides real-time visibility into current draw for capacity planning.
• Robust Build: Durable APC construction with cord retention and mounting brackets included.

Technical Deep Dive

The AP7902B utilizes switched PDU technology, giving IT managers granular control over each connected load. This functionality is crucial for reducing downtime, as individual outlets can be power-cycled remotely without sending staff on-site.

Its 30A input capacity, combined with 16 NEMA 5-20R outlets, supports diverse rack equipment while ensuring balanced load distribution. Integrated current monitoring helps avoid circuit overload and enables proactive management of rack power usage.

The 2U rackmount design simplifies integration into existing infrastructure, while APC’s engineering standards guarantee consistent, dependable operation across enterprise IT, colocation, and edge environments.

Ideal Applications

• Enterprise server racks and IT closets
• Network and telecom infrastructure
• Colocation and data center power distribution
• Edge computing deployments requiring remote management

Frequently Asked Questions (FAQs)

Q1: How is the AP7902B installed?
A: It mounts horizontally in a 2U rack space using included brackets, with flexible front or rear positioning.

Q2: What performance can I expect?
A: The PDU supports up to 30A at 120V with 2880 VA load capacity across 16 outlets. Runtime depends on connected UPS capacity.

Q3: How can it be managed?
A: Outlets are switchable via remote interfaces, allowing remote reboot, sequencing, and monitoring of connected devices.
