[properties]

Properties	Cisco AIR-ANT5114P2M-N 5-GHz 14-dBi Directional Antenna
Description	The AIR-ANT5114P2M-N is a high-gain 5-GHz directional antenna designed for outdoor use, supporting linear dual polarization and N-type male connector interface.
Antenna Type	2-Element Patch Array
Operating Frequency	5150–5900 MHz
Gain	14 dBi (13 dBi net)
Connector	N Male
Mounting Type	Pole or Wall Mount

[/properties] [specifications]

Specifications	AIR-ANT5114P2M-N
Input Impedance	50 Ohms
Polarization	Linear, Dual
Elevation 3-dB Beamwidth	30°
Azimuth 3-dB Beamwidth	30°
Front-to-Back Ratio	> 25 dB
Sidelobe Level	< –15 dBc
Cable Type and Length	30 in. (76.2 cm), outdoor rated coax
Dimensions (L x W x H)	7.8 x 7.8 x 1.2 in. (19.8 x 19.8 x 3 cm)
Weight	21.6 oz. (0.61 kg)
Operating Temperature	-40 to 131°F (-40 to 55°C)

[/specifications] [accesories]

Included Accessories

Antenna mount bracket Elevation adjustable bracket Azimuth adjustable bracket 4x 1/4 in. 20x3/4 carriage bolts 6x 1/4 in. 20 hex nuts 6x 1/4 in. 20 spring lock washers 6x 1/4 in. 20 flat washers 2x Pipe clamps

[/accesories] The antenna operates in the 5-GHz frequency band and is designed for use in outdoor environments.
