[properties]

Properties	Cisco AIR-ANT24020V-R 2.4-GHz Omnidirectional Antenna
Description	Indoor diversity omnidirectional antenna operating in the 2.4–2.5 GHz range for Cisco Aironet devices
Compatibility	2.4-GHz Cisco Aironet devices with RP-TNC connectors
Product Type	Diversity Omnidirectional Antenna

[/properties]

[specifications]

Specifications	AIR-ANT24020V-R
Frequency Range	2400–2500 MHz
VSWR	1.5:1
Peak Gain	2.2 dBi
Polarization	Linear
Azimuth Plane	Omnidirectional
Elevation Beamwidth	97°
Dimensions (L x W x D)	6.9 in x 3 in x <1 in (17.5 cm x 7.6 cm x <2.5 cm)
Cable	3 ft. (91.4 cm) plenum-rated, UV-stable
Connector	RP-TNC
Operating Environment	Indoor use only
Temperature Range	32°F to 131°F (0°C to 55°C)

[/specifications]

[accesories]

Included Accessories	Mounting hardware kit: 2 recessed ceiling T-rail spacers, 2 channel ceiling rail adapters, 2 Phillips screws
Suggested Cable	High-quality, low-loss coaxial cable (short length recommended to minimize signal loss)

[/accesories]

Cisco Aironet 2.4-GHz access point antennas are compatible with all Cisco RP-TNC-equipped access points. Coupling the appropriate antenna and access point allows for efficient coverage in any facility, as well as better reliability at higher data rates.
