AXIS FA1105 Sensor Unit (0913-001)
[shortdesc]
- Highly discreet indoor surveillance in 1080p, Flexible, highly discreet design for indoor use, Standard lens with 1080p resolution, Wide 111 degree horizontal field of view, Forensic WDR
[/shortdesc]
[properties]
| Properties | AXIS FA1105 |
| Description | AXIS FA1105 Sensor Unit is a highly discreet indoor surveillance in 1080p. The thumb-sized unit is ideal for discreet indoor surveillance applications in stores, banks and airports, and when integrated in machines. |
| Product Family | Axis Cameras |
| Product Type | Sensor Unit |
| Main units | AXIS FA51 Main Unit: Single-channel main unit with HDMI output |
| AXIS FA51-B Main Unit: Single-channel barebone with HDMI | |
| AXIS FA54 Main Unit: High-performance multi-view surveillance with Forensic WDR | |
| Image sensor | 1/3” (effective) progressive scan RGB CMOS |
| Lens | Fixed iris |
| Wide dynamic range | Forensic WDR |
| HTTPS encryption | – |
| IEEE 802.1X | – |
| Built-in IR | – |
| Local storage (memory card slot) | – |
| Outdoor Ready | – |
| Vandal rating | – |
| IP rating | IP3X |
| Dimensions | 29 mm (1 2/16 in) ø 20 mm (13/16 in) |
| Weight | 16 g (0.04 lb) |
| Operating Temperature | -20 °C to 50 °C (-4 °F to 122 °F) |
[/properties][specifications]
| Specifications | AXIS FA1105 |
| Min illumination/ light sensitivity (Color) | 0.2 lux |
| Max video resolution | 1920x1080 |
| Max frames per second | 25/30 |
| Day and Night functionality | – |
| Electronic image stabilization | – |
| Focal length | 2.8 mm |
| Varifocal lens | No |
| Aperture | 2.0 |
| Horizontal field of view | 111 ° |
| Vertical field of view | 61 ° |
| Lens mount | M12 |
| Replaceable lens | Yes |
| Zipstream | - |
| H.264 | - |
| H.265 | - |
| Motion JPEG | - |
| Audio Support | - |
| Sustainability | PVC free |
[/specifications][accesories]
| Included accessories | |
| 8 m black cable, locking nuts, mounting brackets, Installation Guide | |
| Optional accessories | |
| AXIS F7315 | Cable White 15 m |
| AXIS F8212 | Trim Ring |
| AXIS F8204 | Mounting Band |
[/accesories]
AXIS FA1105 Sensor Unit (0913-001)
The AXIS FA1105 is well-suited for inconspicuous surveillance purposes within indoor settings such as retail stores and financial institutions, as well as when integrated into machinery. Its compact design allows for installation in confined spaces, with minimal visibility of the mounting hardware, whether on a wall, ceiling, or metal panel. This device consistently supports Forensic WDR, ensuring the visibility of details even in challenging lighting conditions, such as backlight scenarios where individuals are positioned against a bright background.
Quick Specs:
- Flexible, highly discreet design for indoor use
- Standard lens with 1080p resolution
- Wide 111 horizontal field of view
- Forensic WDR
Please see the related tabs for the 0913-001 datasheet and compatible accessories.
| Feature | AXIS FA1080-E Thermal Sensor Unit | AXIS FA1105 Sensor Unit | AXIS FA1125 Sensor Unit | AXIS FA3105-L Eyeball Sensor Unit | AXIS FA4090-E Thermal Sensor Unit | AXIS FA4115 Dome Sensor Unit |
|---|---|---|---|---|---|---|
| Horizontal field of view | 35.4 / 63 | 111 | 91 | 103 | 35.4 | 99-53 |
| Built-in IR | - | - | - | ✔ | - | - |
| Thermal sensitivity (NETD) | <100 mK | - | - | - | <100 mK | - |
