[shortdesc] 5MP resolution, ARTPEC-9 processing, Lightfinder 2.0, Forensic WDR, IK10/IP54, OptimizedIR 40 m, AI analytics [/shortdesc]

[properties]

Model	AXIS P3277-LV
Product Type	Indoor 5 MP AI-powered Dome Camera
Image Sensor	1/2.8” progressive scan RGB CMOS
Pixel Size	2.0 µm
Lens	Varifocal 3.0–8.5 mm, F1.38–2.58; IR-corrected; Remote zoom & focus; P-Iris
Horizontal FOV	104°–34°
Vertical FOV	76°–26°
Minimum Illumination	Color: 0.1 lux at 50 IRE, F1.38; B/W: 0.03 lux; 0 lux with IR
Shutter Speed	1/30500 s to 1/25 s (matches max 25 fps)
Pan/Tilt/Rotate	Pan ±190°; Tilt –45° to +80°; Rotation ±95°
Video Resolution	2592×1944 (4:3); 2560×1440 (16:9); 1920×1200 (16:10)
Frame Rate	Up to 25/30 fps (50/60 Hz) in all resolutions
WDR	Forensic WDR up to 120 dB
IR Illumination	OptimizedIR, 850 nm, up to 40 m
Power	PoE IEEE 802.3af/at Type 1 Class 3
Power Consumption	Max 12.6 W; Typical 4.7 W
Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature	−40 °C to 65 °C (−40 °F to 149 °F)
Operating Humidity	10–85% RH (non-condensing)
Ingress / Impact Rating	IP54, IK10
Dimensions	See datasheet dimension drawing
Weight	810 g (1.8 lb)

[/properties]

[specifications]

Video Compression	H.264 Baseline/Main/High; H.265 Main; AV1; Motion JPEG
Video Streaming	Up to 20 streams; Zipstream; VBR/ABR/MBR; Low-latency mode
Multi-view Streaming	Up to 7 cropped view areas
SNR	>55 dB
Image Settings	Saturation, contrast, brightness, sharpness, WB, BLC, tone mapping, exposure, rotation, overlays, privacy masks
PTZ	Digital PTZ; Presets; Guard tour
Audio Input/Output	Mic/line in; Portcast audio; External mic power; Duplex audio
Audio Encoding	24-bit LPCM; AAC-LC; G.711; G.726; Opus
Network Protocols	IPv4/IPv6, HTTPS, TLS, QoS, FTP/SFTP, CIFS/SMB, SMTP, UPnP, SNMP, DNS, DDNS, NTP/NTS, RTSP/RTP/SRTP, TCP/UDP, IGMP, MQTT
System Integration	VAPIX, ACAP, ONVIF G/M/S/T, SIP, AXIS Camera Station support
Event Triggers	Audio detection, temperature, casing open, network loss, motion, tampering, I/O, schedules
Event Actions	Day/Night shift, Defog, IR control, I/O toggle, Notifications, Recordings, Overlay text, SNMP traps
Built-in Analytics	AXIS Object Analytics, Image Health Analytics, Scene Metadata, Live Privacy Shield
Optional Analytics	Perimeter Defender, License Plate Verifier
Cybersecurity	Axis Edge Vault; Secure keystore; Signed OS; Secure boot; Encrypted filesystem
Onboard Storage	microSD/microSDHC/microSDXC; SD encryption
I/O	1 configurable supervised input/output (12 V, max 25 mA)
Network Interface	RJ45 10/100 Mbps PoE
Approvals	UL/cUL, CE, FCC, UKCA, KC, RCM, VCCI, EAC, IK10, IP54
DORI	Detect: 60–170 m; Observe: 24–67 m; Recognize: 12–34 m; Identify: 6–17 m

[/specifications]

[accesories]

Included in the Box	Camera; Installation guide; Terminal block connector; Connector guard; Cable gasket; Owner authentication key
Optional – Portcast	AXIS T61 MkII Audio and I/O Interface Series; AXIS D6210 Air Quality Sensor
Optional – Installation	AXIS T8415 Wireless Installation Tool
Optional – Mounting	AXIS TP3205 Recessed Mount; AXIS T94K01D Pendant Kit
Optional – Storage	AXIS Surveillance Cards

[/accesories]

Advanced Indoor Security Powered by AI Precision

The AXIS P3277-LV Dome Camera delivers outstanding 5 MP image quality in any lighting environment, backed by the cutting-edge ARTPEC-9 system-on-chip for accelerated deep-learning analytics. With Lightfinder 2.0, Forensic WDR up to 120 dB, and long-range OptimizedIR (up to 40 m), this dome camera ensures clear, actionable video 24/7. Designed for demanding indoor surveillance, it combines strong Axis Edge Vault cybersecurity, robust IK10 vandal resistance and IP54 ingress protection, and intelligent AI analytics for professional deployments.

Key Benefits & Features

• Superior 5 MP Image Quality: Capture detailed footage with 5 MP resolution, Lightfinder 2.0, and Forensic WDR up to 120 dB for clarity in challenging light.
• AI-Powered Video Analytics: Built on ARTPEC-9 with a deep learning processing unit (DLPU), enabling advanced human and vehicle classification, tracking, and behavior detection via AXIS Object Analytics.
• OptimizedIR for Zero-Light Scenes: Integrated 850 nm IR LEDs provide a powerful range of up to 40 m (130 ft) or more, ensuring visibility even in total darkness.
• Robust Cybersecurity: Axis Edge Vault hardware platform safeguards device identity, utilizing a secure keystore, secure boot, signed OS, and encrypted storage for maximum protection.
• Flexible Installation & Adjustment: Features like remote zoom/focus, P-Iris control, corridor format support (90°, 270°), and full pan/tilt/rotation adjustments streamline professional setup.

Ideal Use Cases

• Indoor retail environments requiring high-detail forensic imaging and AI-powered analytics for loss prevention.
• Corporate offices demanding strict cybersecurity and privacy protection with features like AXIS Live Privacy Shield.
• Healthcare or education facilities needing AI-driven event detection and robust, tamper-resistant hardware (IK10).
• Transportation hubs with variable lighting and heavy foot traffic, benefiting from WDR and Object Analytics.
• Critical infrastructure requiring highly durable, vandal- and impact-resistant, IK10-rated hardware.

Technical Specifications

• Image Sensor: 1/2.8” progressive scan RGB CMOS.
• Resolution: Up to 2592×1944.
• Lens: Varifocal 3.0–8.5 mm, remote zoom & focus, P-Iris.
• Minimum Illumination: 0.1 lux color, 0.03 lux B/W, 0 lux with IR.
• IR Range: 40 m or more (OptimizedIR).
• WDR: Forensic WDR up to 120 dB.
• Video Compression: H.264, H.265, AV1, Motion JPEG.
• Frame Rate: Up to 25/30 fps in all resolutions.
• Audio: Mic/line-in, duplex streaming, AAC/LPCM/Opus encoding.
• Network: IPv4/IPv6, ONVIF Profiles G/M/S/T, HTTPS/TLS.
• Power: PoE IEEE 802.3af/at Type 1 Class 3, max 12.6 W.
• Operating Conditions: 0 °C to 50 °C, IK10 & IP54 rated.

Upgrade Your Indoor Surveillance Today

Order now to deploy advanced AI-powered protection with Axis reliability.
