[shortdesc] 2 MP 1080p indoor dome, ARTPEC-9 AI SoC, Lightfinder 2.0, Forensic WDR, OptimizedIR 40 m range, IK10 IP54-rated housing [/shortdesc]

[properties]

Model	AXIS P3275-LV
Product Type	Indoor 2 MP AI-powered dome camera
Image Sensor	1/2.8" progressive scan RGB CMOS; 2.9 µm pixel size
Lens	Varifocal 3.4–9.8 mm, F1.4–2.7; IR corrected; remote zoom and focus; P-Iris control
Field of View	Horizontal 100°–32°; vertical 52°–18°
Minimum Focus Distance	1 m (3.28 ft)
Day / Night	Automatic IR-cut filter
Minimum Illumination	Color: 0.08 lux at 50 IRE, F1.4; B/W: 0.02 lux at 50 IRE, F1.4; 0 lux with IR illumination on
Shutter Speed	1/37000 s to 2 s
Camera Adjustment	Pan ±190°; tilt -45° to +80°; rotation ±95°
System-on-Chip	ARTPEC-9 with deep learning processing unit (DLPU)
Memory	2 GB RAM; 8 GB Flash
Video Compression	H.264 (Baseline, Main, High); H.265 (Main); AV1; Motion JPEG; Axis Zipstream in AV1, H.264, and H.265
Maximum Resolution	1920 × 1080 (2 MP)
Maximum Frame Rate	Up to 50/60 fps (50/60 Hz) in all resolutions
Multi-view Streaming	Up to 20 unique configurable video streams; up to 7 individually cropped view areas
Low-light / WDR	Lightfinder 2.0; Forensic WDR up to 120 dB depending on scene
IR Illumination	OptimizedIR with 850 nm IR LEDs; range 40 m (130 ft) or more depending on scene
Audio Support	Two-way audio; configurable simplex/half duplex/full duplex via edge-to-edge or portcast; input for external microphone or line; output via speaker pairing or portcast
Audio Codecs	24-bit LPCM; AAC-LC 8/16/32/48 kHz; G.711 PCM 8 kHz; G.726 ADPCM 8 kHz; Opus 8/16/48 kHz
Network Interface	RJ45 10BASE-T/100BASE-TX PoE
Network Protocols	IPv4, IPv6 USGv6, HTTP/2, HTTPS, TLS, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP/RTP/SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog, Link-Local address (ZeroConf)
Edge Storage	microSD/microSDHC/microSDXC card support with AES-XTS-Plain64 256-bit encryption; recording to NAS
I/O	Terminal block for one configurable supervised input/digital output (12 V DC output, max load 25 mA); I/O connectivity via portcast accessories
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Power Consumption	Max 10 W; typical 3.4 W (heater off, IR off)
Operating Conditions	Temperature 0 °C to 50 °C (32 °F to 122 °F); humidity 10–85% RH (non-condensing)
Storage Conditions	Temperature -40 °C to 65 °C (-40 °F to 149 °F); humidity 5–95% RH (non-condensing)
Casing	Plastic casing with polycarbonate hard-coated dome; IP54- and IK10-rated; white NCS S 1002-B
IP Rating	IP54
IK Rating	IK10
Weight	800 g (1.8 lb)

[/properties]

[specifications]

Image Sensor & Optics	1/2.8" progressive scan RGB CMOS; varifocal 3.4–9.8 mm, F1.4–2.7; IR-corrected; P-Iris; minimum focus 1 m
Field of View	Horizontal 100°–32°; vertical 52°–18°
Shutter	Electronic shutter speed 1/37000 s to 2 s
Video Compression & Streaming	H.264, H.265, AV1, Motion JPEG; Axis Zipstream in AV1/H.264/H.265; up to 20 unique configurable streams; controllable frame rate and bandwidth; VBR/ABR/MBR H.264/H.265/AV1; low-latency mode
Supported Resolutions	16:9: 1920×1080; 16:10: 1280×800; 4:3: 1440×1080
Maximum Frame Rate	Up to 50/60 fps (50/60 Hz) in all supported resolutions
Multi-view & PTZ	Up to 7 individually cropped view areas; digital PTZ with presets, guard tour and control queue
Image Enhancements	Lightfinder 2.0; Forensic WDR up to 120 dB; 2D/3D noise reduction; defog; barrel distortion correction; rotation 0°/90°/180°/270° including corridor format; mirroring; privacy masks; dynamic text and image overlays
Audio Features	Automatic gain control; 10-band graphic equalizer for audio input; configurable simplex/half duplex/full duplex; speaker pairing and portcast support
Audio Interfaces	Input for external unbalanced microphone with optional 5 V power; unbalanced line input; digital input via portcast; audio output via speaker pairing or portcast
Audio Encoding	24-bit LPCM; AAC-LC 8/16/32/48 kHz; G.711 PCM 8 kHz; G.726 ADPCM 8 kHz; Opus 8/16/48 kHz with configurable bitrate
Network Protocols	IPv4/IPv6 USGv6, ICMP, HTTP/HTTPS/HTTP/2, TLS, FTP/SFTP, CIFS/SMB, SMTP, mDNS, UPnP, SNMP v1/v2c/v3, DNS/DNSv6, DDNS, NTP/PTP/NTS, RTSP/RTP/SRTP/RTSPS, TCP, UDP, IGMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, secure syslog, link-local address
System Integration	Open API (VAPIX, metadata, AXIS Camera Application Platform); one-click cloud connection; ONVIF Profiles G, M, S, T; SIP support for VoIP (P2P or PBX); compatible with AXIS Camera Station and third-party VMS
Event Triggers	Audio detection; device status (temperature, casing open, IP changes, network lost, system ready); digital audio status; edge storage status; I/O and virtual inputs; schedule; video events including day/night, tampering, bitrate degradation
Event Actions	Day/night mode; defog; I/O control; IR and LED control; MQTT publish; HTTP/HTTPS/TCP/email notifications; SD card and network share recording; configuration erase; SNMP traps; image/video clip upload via FTP/SFTP/HTTP/HTTPS/network share/email
Analytics – Included	AXIS Object Analytics; AXIS Image Health Analytics; AXIS Scene Metadata; AXIS Live Privacy Shield; AXIS Video Motion Detection
AXIS Object Analytics	Detects/classifies humans and vehicles (cars, buses, trucks, bikes, other); scenarios for line crossing, object in area, time in area, crossline counting, occupancy, tailgating, PPE monitoring (beta), motion in area/line; up to 10 scenarios with trajectories and bounding boxes
AXIS Image Health & Scene Metadata	Detects blocked/redirected image, blur and underexposure; provides metadata for humans, faces, vehicles, license plates and object attributes including colors and position
Cybersecurity Platform	Axis Edge Vault with secure element (CC EAL 6+, FIPS 140-3 Level 3); signed OS; secure boot; encrypted filesystem (AES-XTS-Plain64 256-bit); secure keystore; Axis device ID; signed video
Network Security	IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2); IEEE 802.1AE MACsec (PSK/EAP-TLS); IEEE 802.1AR; HTTPS/HSTS; TLS 1.2/1.3; Network Time Security (NTS); X.509 certificate PKI; host-based firewall
Approvals & Certifications	UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC; EMC: CISPR 32/35 Class A, EN 55032/55035, EN 50121-4, EN 61000-6-1/-6-2; Safety: CAN/CSA/IEC/EN/UL 62368-1 ed. 3

[/specifications]

[accesories]

Included	Camera, installation guide, terminal block connector, connector guard, cable gasket, owner authentication key
Optional – Portcast	AXIS T61 MkII Audio & I/O Interface Series; AXIS D6210 Air Quality Sensor
Optional – Installation	AXIS T8415 Wireless Installation Tool
Optional – Mounting	AXIS TP3205 Recessed Mount; AXIS T94K01D Pendant Kit
Optional – Storage	AXIS Surveillance Cards

[/accesories]

AI-Driven 2 MP Indoor Surveillance with Built-In Cybersecurity

The AXIS P3275-LV is an indoor 2 MP network dome camera that delivers excellent 1080p image quality in challenging light thanks to Lightfinder 2.0, Forensic WDR, and OptimizedIR. Built on the powerful ARTPEC-9 system-on-chip with a deep learning processing unit (DLPU), it runs advanced AI analytics such as AXIS Object Analytics directly on the edge for real-time insights and accelerated performance. Axis Edge Vault, a hardware-based cybersecurity platform, protects device identity, cryptographic keys, and video integrity for secure, mission-critical monitoring.

Key Benefits & Features

• Excellent 2 MP Image Quality: 1/2.8" progressive scan CMOS sensor and 1920x1080 resolution deliver sharp, low-noise video at up to 60 fps for detailed indoor coverage.
• Advanced Low-Light Performance: Lightfinder 2.0 and Forensic WDR up to 120 dB preserve color and detail in high-contrast or low-light scenes, significantly improving forensic usability.
• Optimized IR for Dark Scenes: Built-in 850 nm OptimizedIR LEDs provide uniform illumination up to 40 m (130 ft) or more, enabling 0 lux performance when IR is active.
• AI-Powered Analytics on the Edge: The ARTPEC-9 SoC with a DLPU enables preinstalled AXIS Object Analytics for accurate human and vehicle detection, tracking, counting, and behavior scenarios.
• Hardened, Vandal-Resistant Design: IK10- and IP54-rated dome casing, combined with Axis Edge Vault, secure boot, and encrypted storage, supports resilient and secure indoor installations.

Ideal Use Cases

• Indoor entrances, lobbies, and corridors requiring reliable 2 MP identification-level coverage.
• Monitoring high-traffic areas where AI-based people and vehicle detection improves situational awareness.
• Security-critical environments that demand hardened hardware and strong device-level cybersecurity.
• Installations standardizing on PoE-powered IP cameras with local microSD card recording for edge storage.
• Sites needing flexible field of view with remote zoom and focus for precise scene framing.

Technical Specifications

• Image sensor: 1/2.8" progressive scan RGB CMOS, 2.9 µm pixel size.
• Resolution & Frame Rate: Up to 1920x1080 at 50/60 fps in all supported resolutions.
• Lens: Varifocal 3.4–9.8 mm, F1.4–2.7, P-Iris, IR-corrected with remote zoom and focus.
• Minimum illumination: 0.08 lux color, 0.02 lux B/W, 0 lux with IR on.
• Wide dynamic range: Forensic WDR up to 120 dB depending on scene.
• IR illumination: OptimizedIR 850 nm LEDs with range up to 40 m (130 ft) or more.
• Video compression: H.264, H.265, AV1, and Motion JPEG with Axis Zipstream in AV1, H.264, and H.265.
• Housing rating: IK10 impact-resistant, IP54-rated indoor dome casing.
• Power: PoE IEEE 802.3af/802.3at Type 1 Class 3, max 10 W, typical 3.4 W.
• Local storage: microSD/microSDHC/microSDXC card support with encrypted SD card option.

Secure Your Indoor Video Today

Deploy the AXIS P3275-LV to gain AI-powered indoor surveillance with robust cybersecurity and reliable image quality. Order today and strengthen your video security infrastructure.
