[shortdesc] 5 MP resolution, AI-powered analytics, Lightfinder 2.0, Forensic WDR, OptimizedIR 40 m, IK10 IP66 NEMA 4X [/shortdesc]

[properties]

Model	AXIS P3287-LVE
Product Type	Outdoor 5 MP AI-powered dome camera with audio analytics
Image Sensor	1/2.8" progressive scan RGB CMOS; 2.0 µm pixel size
Lens	Varifocal 3.0–8.5 mm, F1.38–2.58 , IR-corrected with P-Iris, remote zoom and focus
Field of View	Horizontal 104°–34°; vertical 76°–26°
Day/Night	Automatic IR-cut filter
Minimum Illumination	Color 0.1 lux at 50 IRE, F1.38; B/W 0.03 lux at 50 IRE, F1.38; 0 lux with IR on
Shutter Speed	1/30500 s to 2 s
Wide Dynamic Range	Forensic WDR up to 120 dB (scene dependent)
Image Enhancements	Lightfinder 2.0, OptimizedIR, 2D/3D noise reduction
Video Resolutions	2592 × 1944 (4:3); 2560 × 1440 (16:9); 1920 × 1200 (16:10)
Maximum Frame Rate	Up to 25/30 fps (50/60 Hz) in all supported resolutions
IR Illumination	Built-in OptimizedIR with long-life 850 nm IR LEDs
IR Range	Approx. 40 m (130 ft) or more depending on the scene
Casing and Rating	IP66-, NEMA 4X- and IK10-rated outdoor-ready housing with hard-coated polycarbonate dome
Operating Conditions	−40 °C to 50 °C (−40 °F to 122 °F); 10–100% RH, condensing
Storage Conditions	−40 °C to 65 °C (−40 °F to 149 °F); 5–95% RH, non-condensing
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Power Consumption	Max 12.6 W, typical 4.7 W (heater off, IR off)
Edge Storage	microSD/microSDHC/microSDXC card slot with SD encryption; support for NAS recording
Mounting	Mounting bracket with junction box holes (double-gang, single-gang, and 4" octagon)
Effective Projected Area (EPA)	0.023 m² (0.075 ft²)
Weight	860 g (1.9 lb)

[/properties]

[specifications]

System on Chip	Axis ARTPEC-9 with deep learning processing unit (DLPU)
Video Compression	H.264 Baseline/Main/High; H.265 Main; AV1; Motion JPEG
Video Streaming	Up to 20 configurable video streams; Axis Zipstream for AV1/H.264/H.265; VBR, ABR, MBR; low latency mode
Multi-view / PTZ	Up to 7 individually cropped view areas; digital PTZ with presets, guard tour and control queue
Signal-to-Noise Ratio	Greater than 55 dB
Image Settings	Saturation, contrast, brightness, sharpness, white balance, exposure modes/zones, defog, barrel distortion correction, rotation 0°/90°/180°/270° including corridor format, mirroring, overlays, privacy masks
Network Protocols	IPv4/IPv6, HTTP/HTTPS, HTTP/2, TLS, FTP/SFTP, CIFS/SMB, SMTP, SNMP v1/v2c/v3, DNS/DDNS, NTP/PTP/NTS, RTSP/RTP/SRTP, TCP, UDP, IGMP, DHCP, ARP, mDNS (Bonjour), UPnP, LLDP, CDP, MQTT, secure syslog, QoS (DiffServ)
System Integration	VAPIX® and ACAP APIs; ONVIF® Profiles G, M, S, T; compatible with AXIS Camera Station and many third-party VMS
Event Triggers	Analytics events, device status, edge storage status, I/O, schedules, average bitrate, day/night mode, tampering
Event Actions	Recording to SD card or network share, HTTP/HTTPS/TCP and email notifications, MQTT publish, overlay text, control of I/O, lights, status LED, media uploads via FTP/SFTP/HTTP/HTTPS/network share and email
Included Analytics	AXIS Object Analytics, AXIS Image Health Analytics, AXIS Audio Analytics, AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection
Supported Analytics	AXIS Perimeter Defender, AXIS License Plate Verifier and other ACAP apps
AXIS Object Analytics	Classification of humans and vehicles (cars, buses, trucks, bikes, other); scenarios such as line crossing, object in area, time in area, counting, occupancy, tailgating detection, PPE monitoring (beta), motion in area, motion line crossing
AXIS Audio Analytics	Adaptive audio detection with sound pressure level monitoring; classification of screams, shouts, glass break and speech; event metadata for detections
Cybersecurity / Edge Security	Axis Edge Vault platform with secure boot, signed OS, encrypted filesystem, secure keystore (CC EAL 6+ / FIPS 140-3 Level 3), Axis device ID, signed video
Network Security	IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), MACsec, IEEE 802.1AR, HTTPS with HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 certificate-based PKI, host-based firewall
Approvals and EMC	UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC; EMC compliance including CISPR 32 Class A, CISPR 35, EN 55032 Class A, EN 55035, EN 50121-4, EN 61000-6-1/6-2
Safety and Environmental	CAN/CSA, IEC/EN/UL 62368-1; IEC/EN 62471 (risk group exempt); environmental tests per IEC 60068 series; ingress protection IP66, impact rating IK10, NEMA 250 Type 4X
I/O and Connectors	RJ45 10BASE-T/100BASE-TX PoE; terminal block with one configurable supervised input/digital output (12 V DC, max 25 mA)
IR Illumination Details	OptimizedIR, 850 nm wavelength; designed for coverage up to 40 m (130 ft) or more depending on scene
Environmental Sensors	Support for environmental sensors via portcast technology accessories
Storage Options	microSD/microSDHC/microSDXC with SD card encryption; recording to network-attached storage (NAS)
DORI Distances	Detect: 60 m (wide) / 170 m (tele); Observe: 24 m / 67 m; Recognize: 12 m / 34 m; Identify: 6 m / 17 m (per EN-62676-4)

[/specifications]

[accesories]

Included in the Box	Camera, weathershield, installation guide, terminal block connector, connector guard, cable gasket, owner authentication key
Optional - Installation Tools	AXIS T8415 Wireless Installation Tool
Optional - Mounting Accessories	AXIS TP3206-E Recessed Mount; AXIS TP3103-E Pendant Kit
Optional - Storage Accessories	AXIS Surveillance Cards

[/accesories]

AI-Driven 5 MP Coverage for Demanding Outdoor Security

Axis P3287-LVE is an outdoor-ready 5 MP dome camera built on the powerful ARTPEC-9 system-on-chip for high image quality and advanced edge analytics. It combines Lightfinder 2.0, Forensic WDR and OptimizedIR to capture usable detail in challenging low light and nighttime scenes. Integrated AXIS Audio Analytics and the robust Axis Edge Vault cybersecurity platform make it a smart choice for sites that require reliable, intelligent detection and best-in-class protection for sensitive data.

Key Benefits & Features

• High-resolution 5 MP imaging: Capture sharp video up to 2592x1944 at 25/30 fps for detailed monitoring and digital zooming.
• Advanced AI video analytics: AXIS Object Analytics detects, classifies, tracks, and counts humans and vehicles for focused alerts and efficient forensic searches.
• Audio analytics for faster response: AXIS Audio Analytics listens for abnormal sound patterns such as screams, shouts, and glass breaks so you can react even without clear visuals.
• Rugged outdoor design: IK10, IP66, and NEMA 4X ratings with -40 °C to 50 °C operating range protect the camera in vandal-prone, harsh-weather locations.

Ideal Use Cases

• Outdoor surveillance for industrial sites, utilities, and critical infrastructure requiring robust cyber defense.
• Perimeter and entrance monitoring for warehouses, logistics hubs, and fenced yards utilizing AI classification.
• Public spaces, parking areas, and campuses that require people and vehicle analytics at the edge with real-time audio detection.

Technical Specifications

• Image sensor: 1/2.8" progressive scan RGB CMOS with 2.0 µm pixel size.
• Lens: Varifocal 3.0–8.5 mm, F1.38–2.58, P-Iris, IR-corrected with remote zoom and focus.
• Maximum resolution & frame rate: Up to 2592x1944 and 2560x1440 at 25/30 fps in all resolutions.
• Low-light performance: Color 0.1 lux, B/W 0.03 lux at F1.38; 0 lux with IR illumination.
• Wide dynamic range: Forensic WDR up to 120 dB depending on scene.
• IR illumination: OptimizedIR 850 nm LEDs with range up to 40 m (130 ft) or more depending on the scene.
• Power & consumption: PoE IEEE 802.3af/802.3at Type 1 Class 3, max 12.6 W, typical 4.7 W (heater and IR off).
• Environmental ratings: IP66, NEMA 4X and IK10 impact resistance with -40 °C to 50 °C operating temperature.

Strengthen Outdoor Security with Axis

Deploy the Axis P3287-LVE AI-powered 5 MP dome camera to harden perimeters, enhance analytics, and benefit from Axis Edge Vault cybersecurity. Secure your installation and order today.
