[shortdesc] 2 MP resolution, ARTPEC-9 AI SoC, 3.4–9.8 mm varifocal lens, OptimizedIR 40 m, IK10 IP66 outdoor-ready, PoE-powered [/shortdesc]

[properties]

Model	AXIS P3285-LVE 10 mm
Product Type	Outdoor 2 MP AI-powered dome network camera
Image Sensor	1/2.8" progressive scan RGB CMOS; pixel size 2.9 µm
System-on-Chip	ARTPEC-9 with deep learning processing unit (DLPU)
Lens	Varifocal 3.4–9.8 mm, F1.4–2.7, IR-corrected, P-Iris, remote zoom and focus
Field of View	Horizontal 100°–32°; vertical 52°–18°
Minimum Focus Distance	1 m (3.28 ft)
Day/Night	Automatic IR-cut filter
Minimum Illumination	Color 0.08 lux at 50 IRE, F1.4; B/W 0.02 lux at 50 IRE, F1.4; 0 lux with IR on
IR Illumination	OptimizedIR, 850 nm IR LEDs; range 40 m (130 ft) or more depending on scene
Max Resolution	1920 × 1080 (16:9)
Max Frame Rate	Up to 50/60 fps (50/60 Hz) in all supported resolutions
Wide Dynamic Range	Forensic WDR, up to 120 dB depending on scene
Low-light Technology	Lightfinder 2.0
Video Compression	H.264 (Baseline/Main/High), H.265 (Main), AV1, Motion JPEG
Housing Rating	IP66, NEMA 4X, IK10 impact-resistant
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3; max 10 W, typical 3.4 W (heater off, IR off)
Operating Conditions	−40 °C to 50 °C (−40 °F to 122 °F); humidity 10–100% RH (condensing); start-up −30 °C (−22 °F)
Storage Conditions	−40 °C to 65 °C (−40 °F to 149 °F); humidity 5–95% RH (non-condensing)
Edge Storage	microSD/microSDHC/microSDXC card support with SD card encryption; recording to NAS
Cybersecurity Features	Axis Edge Vault, secure boot, signed OS, encrypted file system, secure keystore

[/properties] [specifications]

Image & Optics	1/2.8" RGB CMOS; 2.9 µm pixel size; varifocal 3.4–9.8 mm F1.4–2.7 lens; IR-corrected; P-Iris; remote zoom/focus
Shutter Speed	1/37000 s to 25 s
Camera Adjustment	Pan ±190°; tilt -45° to +80°; rotation ±95°
Video Streams	Up to 20 configurable streams; Axis Zipstream in AV1/H.264/H.265; VBR/ABR/MBR; low-latency mode
Multi-view Streaming	Up to 7 individually cropped view areas
Noise Reduction	2D spatial and 3D temporal noise reduction
Image Settings	Adjustable saturation, contrast, brightness, sharpness, white balance, exposure, day/night threshold, local contrast, defog, barrel distortion correction, rotation and mirroring, privacy masks, overlays
Pan/Tilt/Zoom Features	Digital PTZ, preset positions, guard tour, control queue
Network Protocols	IPv4/IPv6, HTTP/HTTPS, TLS, FTP/SFTP, CIFS/SMB, SMTP, mDNS, UPnP, SNMP v1/v2c/v3, DNS, NTP/PTP, RTSP/RTP/SRTP, TCP/UDP/IGMP, DHCP, MQTT, secure syslog, ARP, LLDP, CDP
System Integration	Open API (VAPIX, ACAP); ONVIF Profiles G, M, S, T; compatible with AXIS Camera Station and major VMS
Events & Actions	Triggers from device status, edge storage, I/O, schedules, video analytics; actions include I/O control, IR and LED control, notifications, overlays, recording, SNMP traps, media upload
Included Analytics	AXIS Object Analytics, AXIS Image Health Analytics, AXIS Audio Analytics, AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection
AXIS Object Analytics	Detection/classification of humans and vehicles (cars, buses, trucks, bikes, other); scenarios such as line crossing, object or time in area, counting, occupancy, tailgating detection, PPE monitoring (beta), motion-based rules; up to 10 scenarios
AXIS Audio Analytics	Measures sound pressure and adaptive audio; classifies screams, shouts, glass break and speech; provides audio event metadata
Approvals & EMC	UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC; EMC per CISPR 32/35 Class A, EN 55035/55032, EN 50121-4, EN 61000-6-1/6-2; railway IEC 62236-4
Safety & Environment	IEC/EN/UL 62368-1; IEC/EN 62471 risk group exempt; environmental tests IEC 60068 series; IP66, IK10, NEMA 4X
Network Security	IEEE 802.1X, MACsec, HTTPS/HSTS, TLS 1.2/1.3, Network Time Security, X.509 certificates, host-based firewall
Connectors & I/O	RJ45 10BASE-T/100BASE-TX PoE; 4-pin terminal block for 1 supervised input and 1 digital output (12 V DC out, max 25 mA)
IR Performance	OptimizedIR 850 nm; reach 40 m (130 ft) or more depending on scene
Operating Altitude
Dimensions
Weight	Approx. 850 g (1.9 lb)

[/specifications] [accesories]

Included	Camera, weathershield, installation guide, terminal block connector, connector guard, cable gasket, owner authentication key
Optional – Installation	AXIS T8415 Wireless Installation Tool
Optional – Mounting	AXIS TP3206-E Recessed Mount; AXIS TP3103-E Pendant Kit
Optional – Storage	AXIS Surveillance Cards

[/accesories]

AI-Optimized 2 MP Dome Security for Demanding Outdoor Sites

The AXIS P3285-LVE 10 mm is a rugged outdoor-ready 2 MP dome camera built on the ARTPEC-9 system-on-chip with deep learning processing for advanced edge analytics. It delivers sharp 1080p video up to 60 fps (50/60 Hz) with Forensic WDR and Lightfinder 2.0 for reliable identification in complex lighting. OptimizedIR up to 40 m and preinstalled AXIS Audio Analytics help you detect critical events even in complete darkness or when there is no clear visual cue.

Key Benefits & Features

• AI-powered object and audio analytics: AXIS Object Analytics classifies and tracks humans and vehicles, while AXIS Audio Analytics detects events like screams, shouts and glass break to reduce missed incidents and false alarms.
• Superior 2 MP low-light imaging: 1/2.8" CMOS sensor with 2 MP resolution, Forensic WDR and Lightfinder 2.0 ensures clear forensic detail in backlit entrances, tunnels and high-contrast scenes, day or night.
• Rugged outdoor-rated design: IK10 vandal resistance and IP66/NEMA 4X protection keep the dome operational in harsh weather, dust and impacts, with reliable performance from -40 °C to 50 °C.
• Flexible varifocal optics and long-range IR: Remote zoom and focus 3.4–9.8 mm lens with 100–32 degree horizontal field of view and OptimizedIR up to 40 m let you fine-tune coverage for gates, yards and perimeters.
• Hardened cybersecurity with Axis Edge Vault: Hardware-based secure keystore, signed OS, secure boot and signed video protect device identity, configurations and evidence integrity in enterprise deployments.

Ideal Use Cases

• Perimeter and fence-line protection for logistics yards, warehouses and industrial plants.
• Entrances, loading bays and parking areas that need reliable 24/7 identification.
• Critical infrastructure and utilities requiring hardened, cybersecure video surveillance.
• Transportation hubs, terminals and platforms with challenging mixed lighting.
• City surveillance and campus security where AI analytics optimizes operator attention.

Technical Specifications

• Image sensor: 1/2.8" progressive scan RGB CMOS, 2 MP.
• Resolution & frame rate: 1920 x 1080 up to 50/60 fps in all resolutions.
• Lens: Varifocal 3.4–9.8 mm, F1.4–2.7, IR-corrected with remote zoom and focus, P-Iris control.
• Field of view: Horizontal 100–32 degrees, vertical 52–18 degrees.
• IR illumination: OptimizedIR with 850 nm LEDs, range up to 40 m or more for the 10 mm lens.
• Low-light performance: Color 0.08 lux, B/W 0.02 lux at 50 IRE, 0 lux with IR on.
• Video technologies: H.264/H.265/AV1 with Axis Zipstream, Forensic WDR up to 120 dB, Lightfinder 2.0.
• Analytics: AXIS Object Analytics, AXIS Audio Analytics, AXIS Image Health Analytics and AXIS Scene Metadata preinstalled.
• Durability: IK10, IP66 and NEMA 4X-rated casing; operating temperature -40 °C to 50 °C.
• Power & connectivity: PoE IEEE 802.3af/802.3at Type 1 Class 3, RJ45 10/100BASE-TX, microSD/microSDHC/microSDXC edge storage.

Upgrade to AI-Powered Security Today

Deploy the AXIS P3285-LVE 10 mm to harden your perimeter, cut investigation time and capture trusted 2 MP evidence around the clock. Order today to modernize your outdoor video surveillance with AI at the edge.
