[shortdesc]All-in-one 1U rack appliance with 16 PoE ports, 8 TB storage, Intel i3, DDR5, Windows 11 IoT, and FIPS-certified TPM security.[/shortdesc]

[properties]

Model	AXIS S2216 Mk II Rack Appliance 8 TB (02809-004)
Form Factor	1U rack-mount chassis
Processor	Intel Core i3
Memory	16 GB DDR5 (2×8 GB)
Storage	8 TB (2×4 TB surveillance-class HDD), total 4 HDD slots, 2 free
RAID Support	RAID 0, 1, 10
Switch	16-port integrated PoE (260 W total PoE power budget)
Power	Max 520 W total system power, 260 W PoE dedicated, 100–240 V AC, 6.5–2.5 A, 50/60 Hz
Typical Power Consumption	110 W (excluding connected devices)
Maximum Power Consumption	130 W (excluding connected devices)
Operating Conditions	0 °C to 40 °C (32 °F to 104 °F), 10–90% RH
Storage Conditions	-40 °C to 65 °C (-40 °F to 149 °F), 10–90% RH
Dimensions	476×440×45 mm (18.7×17.3×1.8 in)
Weight	11 kg (24.3 lb)
Operating System	Windows 11 IoT Enterprise LTSC 2024
System Licenses Included	16 AXIS Camera Station Pro device licenses; 10 AXIS Audio Manager Pro licenses

[/properties]

[specifications]

System Scalability	Up to 16 video channels, up to 32 doors, total recording rate up to 256 Mbps, up to 200 audio streams, up to 1000 doors with access control only
Graphics	Intel UHD Graphics
Front Connectors	2× USB 3.2, 1× universal audio jack
Rear Connectors — Switch	16× PoE RJ45 1 Gbps, 1× SFP 1 Gbps, 1× RJ45 1 Gbps
Rear Connectors — Server	1× RJ45 1 Gbps, 2× USB 2.0, 2× HDMI 2.1
Live Video Display (Windows Client)	1× 8K @ 20 fps; 1× 4K @ 30 fps; 4×1080p @ 30 fps; 9×720p @30 fps; 16/25/36× 360p @ 15 fps; supports dual 4K monitors with limits
Live Video Display (Browser)	1×8K @ 30 fps; 1×4K @ 30 fps; 4×1080p @ 30 fps; 9×720p @ 30 fps
Playback	Supports same split layouts as live mode; multi-stream playback impacts disk load
Cybersecurity	FIPS 140-2 Level 2 TPM, secure boot, signed switch firmware, encrypted OS drive and recording drive
EMC Approvals	EN 55035, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, ICES(A), VCCI Class A, FCC Class A, RCM Class A, KS C 9835/9832
Safety Approvals	UL 62368-1, IEC/EN 62368-1, CSA C22.2 No. 62368-1
Export Control	Subject to export regulation compliance

[/specifications]

[accesories]

Included	Rack rails, power cord
Optional Accessories	Axis 4 TB and 6 TB surveillance HDDs, Axis Ethernet surge protector, Axis desktop terminals

[/accesories]

The AXIS S2216 Mk II Rack Appliance 8 TB is engineered for mid-to-large-scale installations requiring multi-channel video surveillance, integrated PoE, and secure recording. With high-bandwidth performance, RAID-expandable storage, and fully licensed AXIS Camera Station Pro, it provides a unified management and recording platform.

The appliance features a robust security architecture including secure boot, TPM-protected encryption, and digitally signed firmware—ensuring trusted deployment in sensitive environments such as enterprise, government, and critical infrastructure.

High-performance recording with enterprise-grade security

• Integrated 16-port PoE switch with 260 W budget eliminates external PoE equipment
• Fast deployment with preloaded AXIS software tools and installation wizard
• Expandable surveillance storage up to 4 HDDs with support for RAID 0/1/10
• FIPS-validated TPM provides cryptographic protection and secure boot operation
• Qualified for 16 video streams and up to 256 Mbps total recording throughput
• Supports 8K and 4K viewing for high-resolution surveillance control

• Multi-camera commercial installations
• Corporate and government security rooms
• Access-controlled facilities
• Enterprise campus monitoring
• Industrial and logistics video oversight

• CPU: Intel Core i3
• Memory: 16 GB DDR5
• Storage: 8 TB surveillance-grade HDD (2×4 TB), 4 total bays
• PoE Switch: 16 ports, 260 W PoE
• Operating Temperature: 0–40 °C (32–104 °F)
• Dimensions: 476×440×45 mm (18.7×17.3×1.8 in)
• Security: Secure Boot + FIPS 140-2 Level 2 TPM + signed firmware

Upgrade Your Operations

Deploy a secure and scalable rack-mounted recording backbone for enterprise-grade surveillance.
