AXIS P3735-PLE Panoramic Camera (02633-001)
[shortdesc]
- 4x 2 MP multidirectional panoramic camera with deep learning, 4x 2 MP at 30 fps per channel, 360° IR illumination with individually controlled LEDs, flexible mounting options, support for advanced analytics, Axis Edge Vault safeguards the device
[properties]
| Product Name | AXIS P3735-PLE Panoramic Camera |
| Product Description | 4x 2 MP multidirectional panoramic camera with deep learning, delivering excellent overviews and detailed coverage. It offers flexible mounting options including discreet recessed mounting and ceiling mounting for complete 360° coverage, plus Forensic WDR, Lightfinder, OptimizedIR, and powerful deep learning-based analytics. |
| Resolution | 4x 1920x1080 (4x 2 MP) at up to 25/30 fps (50/60 Hz) per channel in all supported resolutions for detailed imaging on every view |
| Illumination | 360° OptimizedIR illumination with individually controlled 850 nm LEDs and a range of up to 30 m (98.4 ft) or more depending on the scene, delivering clear, reflection-free footage even in low light or complete darkness |
| AI Analytics | Equipped with the ARTPEC-8 system-on-chip with deep learning processing unit (DLPU), supporting AXIS Object Analytics and other advanced deep learning-based analytics on all four channels |
| Security Features | Cybersecurity: ETSI EN 303 645, BSI IT Security Label, FIPS 140; Axis Edge Vault hardware-based cybersecurity platform with TPM 2.0 (FIPS 140-2 Level 2, CC EAL4+) and secure element (CC EAL 6+), signed OS, secure boot, encrypted filesystem, and secure keystore for hardware-based protection of cryptographic keys and device integrity |
| Ideal Applications | Flexible multidirectional surveillance where four 2 MP channels are needed to provide excellent overviews and detailed coverage, with options for discreet recessed mounting or ceiling mounting for complete 360° coverage in indoor and outdoor environments |
[/properties][specifications]
| Sensors | 4 x 1/2.8" progressive scan RGB CMOS sensors with 2.9 µm pixel size for high-quality image capture |
| Field of View | Horizontal field of view 108°–40°, vertical field of view 55°–23°, diagonal field of view 131°–46° with a 3.2–8.1 mm varifocal lens and flexible positioning of the camera heads for up to 360° scene coverage |
| IR Illumination | 360° OptimizedIR with power-efficient, long-life 850 nm IR LEDs, individually controllable per channel, with a range of 30 m (98.4 ft) or more depending on the scene for clear, reflection-free footage even in complete darkness |
| Video Compression | Multiple, individually configurable video streams in H.264 (Baseline, Main, High), H.265 (Main Profile), and Motion JPEG with Axis Zipstream technology in H.264 and H.265 to reduce bandwidth and storage while preserving important forensic details |
| Frame Rate | Up to 25/30 fps (50/60 Hz) in all resolutions across all four channels, providing smooth video capture in every view |
| Analytics | Includes AXIS Object Analytics (object classes: humans, vehicles including cars, buses, trucks, bikes, other; scenarios: line crossing, object in area, time in area, crossline counting, occupancy in area; up to 8 scenarios), AXIS Scene Metadata, AXIS Video Motion Detection, and active tampering alarm with multisensor analytics support on 4 channels |
| Edge Storage | Support for microSD/microSDHC/microSDXC card with SD card encryption (AES-XTS-Plain64 256bit) and recording to network-attached storage (NAS) |
| Environmental Rating | IP66-, IP67-, NEMA 4X- and IK09-rated aluminum and plastic casing with polycarbonate hard-coated dome for robust, outdoor-ready performance |
| Power Supply | Power over Ethernet (PoE) IEEE 802.3at Type 2 Class 4; IR illumination on: Class 4, IR illumination off: Class 3 |
| Operating Temperature | Operating conditions: -30 °C to 50 °C (-22 °F to 122 °F), humidity 10–100% RH (condensing) |
| Mounting Options | Mounting bracket with junction box holes (double-gang, single-gang, 4" square, and 4" octagon) and ½" (M20) conduit side entry, plus recessed mounting or ceiling mounting for discreet surveillance and complete 360° coverage |
| Compliance Certifications | Product markings: CSA, UL/cUL, UKCA, CE, KC, EAC, VCCI, RCM. EMC: CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2; RCM AS/NZS CISPR 32 Class A; ICES-3(A)/NMB-3(A); VCCI Class A; KS C 9835, KS C 9832 Class A; FCC Part 15 Subpart B Class A; IEC 62236-4. Safety: CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, IEC/EN 62471 risk group exempt, IS 13252, RCM AS/NZS 62368.1:2022. Environment: IEC 60068-2-1, -2-2, -2-6, -2-14, -2-27, -2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK09, ISO 21207 (Method B), MIL-STD-810H (Methods 501.7, 502.7, 505.7, 506.6, 507.6, 509.7, 512.6), NEMA 250 Type 4X, NEMA TS 2 (2.2.7–2.2.9), VDMA 24364. Network: NIST SP500-267, IPv6 USGv6. Cybersecurity: ETSI EN 303 645, BSI IT Security Label, FIPS 140. |
[/specifications]AXIS P3735-PLE Panoramic Camera offers four channels with 2 MP per channel at 30 fps, letting you capture both wide-angle and zoomed-in, detailed views. It includes Forensic WDR, Lightfinder, and 360° OptimizedIR illumination with individually controlled LEDs for clear, reflection-free footage and excellent image quality even in low light or complete darkness. This flexible camera offers various mounting options, such as recessed mounting for discreet surveillance or ceiling mounting for complete 360° coverage. With highly efficient power consumption, it ensures lower operating costs. Powered by the ARTPEC-8 SoC with a deep learning processing unit, it supports powerful analytics based on AXIS Object Analytics and other edge-based applications, while Axis Edge Vault guarantees the device’s integrity and protects it from unauthorized access.
| Feature | AXIS P3735-PLE | AXIS P3737-PLE | AXIS P3738-PLE |
|---|---|---|---|
| Max video resolution | 1920x1080 | 2592x1944 | 3840x2160 |
| Built-in IR | ✓ | ✓ | ✓ |
| Remote focus | ✓ | ✓ | ✓ |
| Remote zoom | ✓ | ✓ | ✓ |
| Local storage (memory card slot) | ✓ | ✓ | ✓ |
| Zipstream | ✓ | ✓ | ✓ |
| Power over Ethernet | ✓ | ✓ | ✓ |
| Day and Night functionality | ✓ | ✓ | ✓ |
