[shortdesc]Fully connected LTE/Wi-Fi/Bluetooth body worn camera with GNSS tracking, 1080p recording, EIS(720p), noise suppression, IP67 durability, and up to 15 hours of operation.[/shortdesc]

[properties]

Model	AXIS W120 Body Worn Camera Black (02583-004)
Product Type	Body worn camera
Power / Battery	Li-ion 3600 mAh; up to 15 hours (720p), 13.5 hours (1080p), 29 hours standby
Weight	200 g (0.44 lb)
Operating Temperature	-20 °C to 50 °C (-4 °F to 122 °F)
Storage Temperature	-20 °C to 45 °C (-4 °F to 113 °F) (<3 months);                              23 °C to 27 °C (73 °F to 81 °F) (>3 months)
Humidity	10–100% RH (condensing), 5–95% RH (non-condensing)
Interfaces / Ports	Pogo pin pads; USB for Axis accessories & USB-C charging; Nano-SIM
Casing	IP67-rated plastic; drop tested to 2 m
Mounting	Klick Fast™ system
Color	Black (NCS S 9000-N)
Storage Capacity	64 GB internal; up to 30 hours recorded video
Throughput	Up to 100 Mbit/s to system controller
Positioning System	GPS, GLONASS, Galileo, BeiDou
Sensors	3-axis gyroscope, accelerometer, compass
Certifications	IP67, MIL-STD-810H, EMC, Safety, Wireless, Cybersecurity standards

[/properties]

[specifications]

Image Sensor	1/2.9” progressive scan RGB CMOS; 0.1 lux sensitivity
Lens	2.3 mm fixed lens; HFOV 137°; VFOV 76°; F2.1
Shutter Speed	1/20000 s to 1/25 s (50 Hz); 1/20000 s to 1/30 s (60 Hz)
Video	H.264 High Profile; 1920×1080/1280×720; 25 fps (50 Hz), 30 fps (60 Hz); WDR; EIS (720p); barrel distortion correction; Axis Zipstream
Audio	AAC-LC; built-in dual microphones; 48 kHz; 128 kbps (mono); 2×128 kbps (dual); voice enhancement
Connectivity	LTE (US/EU bands CAT4); Wi-Fi 5 a/b/g/n/ac (2.4/5 GHz); Bluetooth 5.1 LE & Classic
Security Features	Secure boot; Axis Edge Vault; signed OS; AES-XTS-Plain64 256-bit encryption; CJIS-compliant encrypted internal storage; secure keystore (CC EAL6+)
Network Security	IEEE 802.1AR; HTTPS/HSTS; TLS 1.2/1.3; WPA/WPA2-PSK
Environmental / Ruggedness	IP67; MIL-STD-810H (thermal, humidity, salt fog, immersion, shock); IEC 60068 series
Recording	Configurable prebuffer (0–120 s) and postbuffer (0–60 s)
User Interface	0.96" IPS TFT display (160×80); audio & vibration feedback; status indicators
Charging	0–40 °C (32 °F to 104 °F) allowed; 4–6.5 hour charge time depending on temperature
Wireless Compliance	FCC, IC, EN 301 standards, AS/NZS, IFT, WPC
Cybersecurity Compliance	ETSI EN 303 645; BSI IT Security Label; EN 18031-1, EN 18031-2

[/specifications]

[accesories]

Optional Accessories

Klick Fast™ mounts; AXIS TW1200 Mini Bullet Sensor; AXIS TW1201 Mini Cube Sensor; AXIS TW1906 Battery Replacement; AXIS Body Worn Assistant (Android/iOS)

[/accesories]

The AXIS W120 is a fully connected, professional-grade body worn camera engineered for reliable live streaming, forensic-quality video capture, and continuous location tracking. With LTE, Wi-Fi, and Bluetooth built into a single rugged unit, it provides real-time operational awareness and dependable evidence-quality recordings in any environment.

Designed for frontline personnel, the W120 delivers sharp 1080p video, dual-mic audio clarity with noise suppression, pre/post-buffering, and electronic image stabilization. Its 15-hour operating time, IP67 durability, GNSS positioning, and Klick Fast™ mounting system make it ideal for demanding field use.

Advanced LTE Body Worn Recording with Location Tracking

• Clear, stable footage with 1080p recording, WDR, and EIS for demanding environments
• Real-time streaming over CAT4 LTE for instant situational awareness
• Accurate positioning with GPS, GLONASS, Galileo, and BeiDou support
• Noise-suppressed audio via built-in dual microphones
• Rugged IP67 design with MIL-STD-810H durability for field deployment
• Long battery life—up to 15 hours—supports full-shift operation
• Advanced encryption and secure boot for data and device integrity

Ideal Use Cases

• Law enforcement patrol and incident response
• Private security and guarding services
• Public transportation staff and safety personnel
• Healthcare and emergency response teams
• Field inspection, utility work, and infrastructure monitoring

Technical Specifications Summary

• Image sensor: 1/2.9"""" RGB CMOS, 0.1 lux
• Lens: 2.3 mm; HFOV 137°; VFOV 76°; F2.1
• Video: H.264; up to 1080p/30 fps; WDR; EIS; Zipstream
• Audio: AAC-LC; dual microphones; noise suppression
• Connectivity: LTE CAT4; Wi-Fi 5; Bluetooth 5.1
• Security: Secure boot; Edge Vault; AES-XTS; TLS
• Environmental: IP67; MIL-STD-810H
• Battery: Li-ion 3600 mAh; up to 15 hours
• Storage: 64 GB internal; encrypted
• GNSS: GPS, GLONASS, Galileo, BeiDou

Upgrade Your Operations

Enhance field awareness and evidence reliability with the AXIS W120.
