[shortdesc]

• 2nd generation: Extremely discreet pinhole sensor, Only compatible with 2nd generation main units and cables, Extremely discreet design, 92° horizontal field of view, Forensic WDR, IP66/IP67 rated

[/shortdesc]

[properties]

Properties	AXIS F7225-RE
Description	AXIS F7225-RE Pinhole Sensor allows for extremely discreet surveillance where only the sensor is visible externally. It is only compatible with 2nd generation main units and cables.
Product Family	Axis Cameras
Product Type	Sensor
Image sensor	1/2.8” progressive scan RGB CMOS
Wide dynamic range	Forensic WDR
PoE Class	–
Connectors	SMA connector (uses Axis 2nd generation SMA–FAKRA cables)
Built-in IR	–
Local storage (memory card slot)	–
Outdoor Ready	Yes
Vandal rating	–
IP rating	IP66, IP67
Dimensions	45 x 25 x 20 mm (1.8 x 0.98 x 0.79 in)
Weight	26 g (0.06 lb)
Operating Temperature	-30 °C to 55 °C (-22 °F to 131 °F)
Sustainability	PVC and BFR/CFR free

[/properties][specifications]

Specifications	AXIS F7225-RE
Min illumination/ light sensitivity (Color)	0.3 lux
Min illumination/ light sensitivity (B/W)	-
Max video resolution	1920x1080
Max frames per second	50/60
Day and Night functionality	–
Electronic image stabilization	–
Focal length	3.7 mm
Varifocal lens	No
Aperture	2.5
Horizontal field of view	92 °
Vertical field of view	45 °
Lens mount	M12
Replaceable lens	Yes
Audio Support	–

[/specifications][accesories]

Optional accessories
AXIS TU6002	Right-angle SMA Adaptor
AXIS TU6004-E	2nd generation Indoor and outdoor rated cable for AXIS F Series modular cameras
AXIS TU6005	2nd generation Plenum Cable
AXIS TU6007-E	2nd generation Indoor and outdoor rated cable for AXIS F Series modular cameras
AXIS F8202	Straight Mounting Bracket
AXIS F92A01	Height Strip Housing

[/accesories]

AXIS F7225-RE Pinhole Sensor (02363-001)

The AXIS F7225-RE Pinhole sensor is designed to seamlessly integrate into tight spaces, such as within machinery or ATMs. It is intended to be used in combination with AXIS F91 central units, which helps to reduce the overall costs related to installation and configuration. The sensor can support four HDTV 1080p video streams at 30 frames per second or 720p video streams at up to 60 frames per second. When used with AXIS F9111 main unit, it delivers HDTV 1080p video streams at 60 fps or 720p video streams at up to 180 fps.

Quick Specs:

• Only compatible with 2^nd generation main units and cables
• Forensic WDR
• 92° horizontal field of view
• Up to 180fps at 720p

Please see the related tabs for the 02363-001 datasheet and compatible accessories.

Feature	AXIS F2105-RE Standard Sensor	AXIS F2115-R Varifocal Sensor	AXIS F2135-RE Fisheye Sensor	AXIS F4105-LRE Dome Sensor	AXIS F4105-SLRE Dome Sensor	AXIS F7225-RE Pinhole Sensor
Outdoor Ready	✔	–	✔	✔	✔	✔
Horizontal field of view	108	107.4 - 56.3	185	110	110	92
