• The AXIS TQ6501-E Outdoor Parapet Mount is a durable, IK10-rated aluminum mount designed for secure and versatile camera installations in outdoor environments

[/shortdesc]

[specifications] [/specifications]

AXIS TQ6501-E Outdoor Parapet Mount (02110-001)

The AXIS TQ6501-E Outdoor Parapet Mount is a robust and lightweight solution for mounting Axis cameras in challenging outdoor conditions. Constructed from IK10-rated aluminum, this mount is built to withstand impacts and harsh weather. It supports a wide range of Axis pendant kits and cameras with 1.5” NPS or NPT inner threads. The mount's design allows for flexible cable routing through the bottom or side conduit connections, ensuring a neat and secure installation. Its compatibility with standard pan and tilt pole-mounted camera fixings makes it ideal for surveillance in industrial, commercial, and urban environments.

Key Features:

• Durable Construction: Made from IK10-rated aluminum for enhanced impact resistance and outdoor reliability.
• Flexible Installation: Allows bottom or side conduit cable routing for clean and efficient setups.
• Wide Compatibility: Supports Axis pendant kits with 1.5” NPS/NPT threads and multiple camera models.
• Lightweight Design: Easy to handle and install while maintaining structural integrity.
• Outdoor-Ready: Suitable for harsh environments with a weather-resistant casing.

Technical Specifications:

• Supported Products: AXIS P56, Q60, Q61 Series, and AXIS M5525–E cameras (requires pendant kit).
• Material: Aluminum, IK10-rated, paintable.
• Dimensions: Height: 754 mm (29.69 in), Width: 160 mm (6.3 in), Depth: 418 mm (16.46 in).
• Weight: 5.51 lb
• Maximum Load: 40 kg (88 lb).
• Cable Routing: Bottom cable hole or side conduit hole (M20/3/4").
• Environmental Compatibility: PVC and halogen-free.
