• The AXIS Din PS56 240W Power Supply is a UL-certified 56V DC power source designed for AXIS Surveillance cabinets, providing reliable performance even in extreme temperatures.

[/shortdesc]

[specifications] [/specifications]

AXIS Din PS56 240W Power Supply (01726-001)

The AXIS Din PS56 240W Power Supply is a compact and high-efficiency power solution designed for use in AXIS Surveillance cabinets. It delivers 56V DC output and is capable of powering DC-operated PoE switches, making it an ideal choice for surveillance and security systems. With a wide operating temperature range from -25°C to 70°C (-13°F to 158°F), this power supply ensures reliable operation even in harsh environments. Its compact design allows for easy installation and maintenance.

Key Features:

• Reliable Power Supply: Provides 56V DC output for PoE switches and surveillance systems.
• Wide Operating Temperature: Functions in extreme temperatures ranging from -25°C to 70°C (-13°F to 158°F).
• High Efficiency: Designed for cost-effective energy consumption with low maintenance.
• Adjustable Voltage Output: Output voltage adjustable between 30V and 56V via potentiometer.
• Compact and Durable: Space-saving design ensures easy installation in surveillance cabinets.
• UL Certified: Meets strict safety and performance standards.

Technical Specifications:

• Output Power: 240W
• Output Voltage: 56V DC (adjustable from 30V to 56V)
• AC Input Voltage Range: 85-277V AC
• DC Input Voltage Range: 80-370V DC
• Input Frequency: 45-65 Hz
• AC Current Consumption: 1.5A @ 230V AC / 3A @ 115V AC
• DC Current Consumption: 1.5A @ 370V DC / 3A @ 120V DC
• Operating Temperature: -25°C to 70°C (-13°F to 158°F)
